Futek IAA105 Quick Start Manual

Digitally configurable analog amplifier with sensit lite app

Advertisement

Quick Links

IAA105
Digitally Configurable Analog Amplifier
With SENSIT
Sensor Solutions Source
Load · Torque · Pressure · Multi-Axis · Calibration · Instruments · Software
www.futek.com
Lite App
®
Quick Start Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the IAA105 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Futek IAA105

  • Page 1 Quick Start Guide IAA105 Digitally Configurable Analog Amplifier With SENSIT Lite App ® Sensor Solutions Source Load · Torque · Pressure · Multi-Axis · Calibration · Instruments · Software www.futek.com...
  • Page 2 Getting Help TECHNICAL SUPPORT For more IAA105 support, please visit: http://www.futek.com/iaa/support.aspx SM1004 FUTEK reserves the right to modify its design and specifications without notice. Please visit http://www.futek.com/salesterms for complete terms and conditions. 10 Thomas, Irvine, CA 92618 USA futek@futek.com www.futek.com...
  • Page 3: Table Of Contents

    Table of Contents Layout ........4 SENSIT Lite App .
  • Page 4: Layout

    Layout Module with integrated Bluetooth ® wireless technology Model: IAA105 DIN Clip Sensor Side Power/Output Side LED Indicator USB-C Power/Communication Front View Side View...
  • Page 5: Sensor Wiring

    Sensor Wiring SENSOR SIDE (item #GOD04252) PIN WIRING CODE FUNCTIONALITY + Excitation – S – Signal + Signal – E – Excitation Note: For 6 wire sensors, connect +Sense to +Excitation and –Sense to –Excitation. Sensor cable shield connections should be grounded on one end, either the sensor side or the IAA sensor input side, to avoid potential ground loops.
  • Page 6: Power/Output Wiring

    Note: For Sensors with Shield, use Pin 1 (Chassis) of ‘Power/Output Connections’ for Shield Connection. Power: • 5 VDC to 30 VDC or USB Powered For information on effective chassis techniques, • Power Consumption: 1.2 W (max) please visit: www.futek.com/support (Instrument Only) • Inrush Current: 400 mA (max)
  • Page 7: Led Indication

    LED Indication LED indicating Bluetooth ® wireless connection LED INDICATORS Model: IAA105 Color Functionality Solid Green LED Normal operation mode Blinking Red LED Fault condition detected Green LED indicating Bluetooth ® Blinking when advertising and solid wireless communication status when paired/connected...
  • Page 8: Sensit ® Lite App

    • A zero offset adjustment can be made to account for any fixtures and will not affect the calibrated span. • The output of the IAA105 must be monitored while adjusting.
  • Page 9 Enables restoration from a Factory (mV/V) or system-calibrated profile. • Should the sensor and amplifier be calibrated as a system at FUTEK, adjustments to the calibration profile is not required. • A system calibration can be started on the FUTEK website at:...
  • Page 10: Sensit ® Lite App-Profile Setup

    SENSIT Lite App—Profile Setup ® Automatic: Allows a profile to be setup by typing in basic sensor and desired output information. Manual: Allows further custom adjustments of calibration settings.
  • Page 11: Sensit ® Lite App-Automatic Profile Setup

    SENSIT Lite App—Automatic Profile Setup ® Sensitivity (mV/V): Enter the sensor’s mV/V rated output for when the sensor is fully loaded. Max Excitation (V): Enter max excitation to be supplied to the sensor. Offset (V): Enter the desired zero output level. Typically, 0 V. Span (V): Enter the desired amount of voltage change from Offset (V).
  • Page 12: Sensit ® Lite App-Manual Profile Setup

    • The calibration certificate lists the rated output of the sensor. • The sensor spec sheet will list the max voltage recommended for a sensor. • The output of the IAA105 must be monitored while adjusting.
  • Page 13 10 Thomas, Irvine, CA 92618 USA futek@futek.com www.futek.com...
