Mountup MU1009 Instruction Manual

Tabletop TV Stand
Instruction Manual
MIN:
4"/100mm
MAX:
16"/400mm
CAUTION AND MAINTENANCE:
Don't allow children to climb, stand, hang, or play on any part of TV or stand.
◆
This product is intended for indoor use only. Using this product outdoors could lead to product failure
◆
and personal injury.
Incorrect installation may result in product damage or body injury.
◆
Check that the bracket is secure and safe to use at regular intervals (at least every three months).
◆
WARNING:
This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or
damaged, do not return the damaged item to your dealer; please contact our customer service team.
Never use damaged parts!
If you have any questions, please feel free to contact us via Amazon.
88lbs
40kg
Max:
22.4"/570mm
Min: 8x4"/200x100mm
Max: 32x16"/800x400mm
1
Supplied Parts and Hardware
US1.0
Base
L1 ×1
Hardware (Product)
Pads Bolt M6x12mm
A
×4
TV Screws / Spacers / Washers
Philips Screws Philips Screws
M8 x 25mm M6 x 15mm
M8 x 45mm M6 x 30mm
S1 ×4 S2
Bracket Base
L2 ×1 R1 ×1
Nut M6 Allen Key
B C D
×4 ×4
Philips Screws Philips Screws
M5 x 15mm M4 x 12mm
M4 x 30mm
×4 S3 ×4 S4 ×4
2
Bracket
R2 ×1
Wrench
E
×1 ×1
Washers Spacers
Ø 5/6/8 mm L5mm
L10mm
S5 ×4 S6 ×4
