HANYOUNG NUX PEA Series Instruction Manual

PEA series
Photo Sensor
INSTRUCTION MANUAL
Thank you for purchasing Hanyoung Nux products.
Please read the instruction manual
carefully before using this product, and use the product correctly.
Also, please keep this instruction manual where you can see it any time.
▍ Safety information
Please read the safety information carefully before use, and use the product correctly.
The alerts declared in the manual are classified into Danger, Warning and Caution according to their importance
DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury
WARNING
CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor injury or property damage
DANGER
• The input/output terminals are subject to electric shock risk.
Never let the input/output terminals come in contact with your body or conductive substances.
WARNING
• This product is not for outdoor use (it may shorten the product lifetime and cause electric shock)
• Do not use this product in places with flammable or explosive gases
(it does not have an explosion-proof structure, so there are fire or explosion risks)
• Do not use the product in places where vibrations or shocks exceed the reference values
(it has a double insulation structure, but the components may be damaged)
CAUTION
• Applicable Pollution degree 3 of intended environment.
• Never use it on AC power.
• Be careful of wiring. It may cause explosion, fire, or machine breakdown.
• Do not use the product in a state where the product body or
cable is crashed.
• Do not disassemble, repair or modify the product.
• When the lens of the photo sensor is contaminated by foreign
substances, use a dry piece of cloth and wipe off the
substance lightly. Never use thinner or organic solvents.
• Separate high voltage cable and power line from the sensor wire.
Be cautious since using the same pipe during wiring could cause
malfunction.
• If the cable needs to be extended, use over 0.3 ㎟ and be
cautious because of a possible sudden voltage drop.
• When using the sensor under lights with high frequency, such as
fluorescent lamps or mercury lamps, block it with a light
shading plate and avoid the lens from facing the light directly.
• If multiple through-beam type photoelectric sensors are installed
▍ Specification
Sensing mode Through - beam
Relay output (AC/DC power) PEA-T30A
Model
Open collector output
PEA-T30D
(DC power)
Sensing distance 30 m
Hysteresis distance
Detecting object Ø12 mm more (Opaque)
Infrared light emitting
Light source (wavelength)
diode (855 nm)
Relay output (AC/DC power)
Power
Open collector output
voltage
(DC power)
• Transmitter Max. 1 VA,
Relay output (AC/DC power)
• Receiver Max. 2VA
Power
consumption
Open collector output • Transmitter Max. 15 mA
(DC power) • Receiver Max. 20 mA
• Relay contact output (Contact configuration 1a1b)
Relay output (AC/DC power) • Contact Capacity: 30 V d.c. 5A /
Control
250 V a.c. 5 A with resistive load
output
Open collector output • NPN or PNP open collector auto-discriminate output
(DC power) • Load current - Max. 100 mA (26.4 V d.c. standard)
Operation mode
Control output indicator light : Orange LED, Stability indicator light : Green LED
Indicator light
(However, the Green LED of the through-type emitter is a power indicator)
Auto tuning
AGC After 20 seconds of unstable light entering on button locked state to stable light entering state
Sensitivity adjustment
Common -
Protection
Open collector output Power reverse connection protection, Output short-circuit over-current protection,
circuit
(DC power)
Relay output (AC/DC power)
Response
Open collector output
time
(DC power)
Insulation Resistance
Dielectric strength
Vibration resistance
Shock resistance
Ambient illumination
Ambient temperature range Operating temperature : -20 ～ +55 ℃ , During storage : -40 ～ +70℃ (Without condensation or icing)
Ambient humidity
Protection
Relay output (AC/DC power) 265g (440g)
Weight
Open collector output
(Packing)
255g (430g)
(DC power)
Case
Texture Display
Lens
Common
Accessory
Accessory -
Connection method
Ø 6 mm, Through-beam type transmitter: 2-core, Through-beam type receiver,
Relay output (AC/DC power)
Mirror-reflection type receiver, Diffuse-reflective type receiver: 5-core, 2 m
Wiring
specification
Open collector output Ø 6 mm, Through-beam type transmitter: 2-core, Through-beam type receiver,
(DC power) Mirror-reflection type receiver, Diffuse-reflective type receiver: 5-core, 2 m
Specifications of the small-sized cable
▍ Suffix code
Model Code
PEA- ⃞ ⃞ ⃞ PEA series
T Through-beam
Sensing
M Retroreflective
mode
R Diffuse-reflective
30 30 m (Through-beam)
Sensing distance 5 5 m (Retroreflective)
2 2 m (Diffuse-reflective)
D Open collector output
Control output
A Relay contact output
HANYOUNGNUXCO.,LTD
28, Gilpa-ro 71beon-gil,
Michuhol-gu, Incheon, Korea
TEL : +82-32-876-4697
http://www.hanyoungnux.com
close together, malfunction may happen due to the
mutual interference.
• Using inductive load (relay, coil) for the output can cause an
instantaneous increase in load by more than two times and damage
NPN TYPE
the TR of the output. Therefore, please set half of the maximum load.
• There is an over-current protecting circuit within the output side
that breaks the output when the current is higher than the rated
load current. Therefore, please set within 70% of the maximum load.
• Do not use the product in places with heavy dust or debris that
can contaminate the lenses and consequently cause malfunctions.
• The contents of this manual may be changed without prior notification
• Any use of the product other than those specified by the
manufacturer may result in personal injury or property damage.
• When using the Switching Power Supply as power source,
ground the Frame Ground (F.G.) terminal and be sure to connect
the noise-cancelling condenser between OV and F.G. terminals
• The power supply should be insulated and
limited voltage/current or Class 2, SELV power.
Retroreflective (M.S.R.)
PEA-M5A
PEA-M5D
0.1 ~ 5 m
20% or less of detection
-
Ø75 mm more (Opaque) White paper (100 x 100 mm)
Red light emitting diode Infrared light emitting diode
(660 nm)
24 - 240 V a.c. ±10 % or 24 - 240 V d.c. ±10% (Ripple max. 10 %)
12 - 24 V d.c. Class 2 ± 10% (Ripple max. 10 %)
Max. 3 VA
Max. 30 mA
PEN-A 외형도
• Electrical life: Min. 100,000 cycles
• Mechanical life : Min. 50 million cycles
(Opening/closing frequency 180 times/min))
• Residual voltage - Max. 1.5 V
Light ON / Dark ON button switch type
See How to set sensitivity and operation mode → Section ③.
B1 increases the sensitivity and B2 decreases the sensitivity
Mutual interference prevention function
Output reverse connection protection, Output short-circuit alarm
Max. 20 ㎳
Max. 1 ㎳
More than 20 MΩ (500 V d.c. mega)
1,000 V a.c. (50/60 Hz for 1 minute)
10-55Hz, sweep: 1.5mm, X·Y·Z 2 in each direction for 2 hours
500 m/s2, X·Y·Z each direction 3 times
Sunlight : max. 11,000 lx / Incandescent: max 3,000 lx
35 ～ 85 % RH (Without condensation or icing)
IP67 (IEC standard)
150g (280g)
140g (270g)
투과형
PC
확산반사형
PC
PMMA
Instructions manual, bracket, bolt (M3 X 12 ㎜)
Mirror (HY-M5)
Cable type
AWG20 (0.18 mm, 21 strands), Insulation outer diameter: 1.5 mm
Content
DC power
AC/DC power
▍ How to set sensitivity and operation mode
NO Function
① Button lock & unlock
Through-beam
Retroreflective
(M.S.R.)
Auto
③
tuning
Diffuse-
reflective
MK1501KE231114
④ Increase sensitivity
⑤ Decrease sensitivity
⑥ Operation mode change
⑦ Factory reset
⑧ AGC
■ Indicator light state
① Button lock
PEN-A 외형도
② Button unlock
PEN-A 외형도
Through-beam
Retroreflective
(M.S.R.)
Auto
③
tuning Diffuse-
reflective
※ If auto-tuning is attempted while the light from the emitter does not enter the receiver, the Orange blinks (Error displayed for 2 seconds)
④ Increase sensitivity
⑤ Decrease sensitivity
⑥ Operation mode change
⑦ Factory reset
Save previous
execution value
Etc
Load wiring
▍ Connection diagram
■ Relay contact output
Diffuse - reflective
Relay
PEA-R2A
PEA-R2D
2 m
distance
Power supply
Circuit
(855 nm)
■ Open collector output (DC power)
투과형
확산반사형
확산반사형
Overcurrent
protection
circuit
Overcurrent
protection
circuit
Internal circuit
※ Depending on the load wiring, NPN or PNP output is automatically determined
▍ Accessories
■ Bracket
52.4
50.0
145g (260g)
▍ Output operation characteristic
140g (255g)
미러반사형
-
Output Indicator
Output indicator
Output Indicator
(Red)
(Orange)
(Red)
Control output
Control output Control output
(RELAY/TR)
(RELAY/TR)
(RELAY/TR)
stability Indicator
stability indicator stability Indicator
(Green)
(Green)
(Green)
Output indicator
Output Indicator
(Orange)
Output Indicator
(Red)
(Red)
Control output
Control output
Control output
(RELAY/TR) (RELAY/TR)
(RELAY/TR)
stability indicator stability Indicator
stability Indicator
(Green)
(Green)
(Green)
Information
Press the B1 ( ) button for more than 3 seconds to change
(lock or unlock).
If the B2 ( ) button is pressed for more than 3 seconds in the presence
of a detection object, the sensitivity is automatically set.
1) In the presence of a detection object (stable light incident)
2) Release the B2 ( ) button after pressing it for more than 3 seconds.
3) Check the Green + Orange LED cross blinking
(try again if either side is not blinking)
4) Press the B2 ( ) button once after removing the detected object
(0.5 seconds)
Press the B1 ( ) button for less than 3 seconds to increase the fine
sensitivity (1 STEP)
If the B2 ( ) button is pressed for less than 3 seconds, the
fine sensitivity decreases (1STEP)
Press the B1( ) +B2 ( ) buttons simultaneously for 5 seconds or
longer to change the operation mode (Light ON↔Dark ON)
After pressing the B1( ) +B2 ( ) buttons together for more than
50.0
5 seconds, release only B1 ( ) After 5 seconds, release the B2 (
button to reset. (Dark ON, sensitivity maximum, button unlock changes,
50.9
and diffuse reflection type becomes Light ON.)
Unstable light If it lasts more than 20 seconds,
it is adjusted to stable light incident state.
Within 3 seconds (Green blinking) →
After 3 seconds (Orange ON), release the B1 button, Green + Orange blinking (2 seconds)
※ Setting value cannot be changed when button locking or unlocking is operated
Within 3 seconds (Green + Orange blinks) →
After 3 seconds (Orange ON), release the B1 button, Green + Orange blinks (2 seconds)
Within 3 seconds (Green blinking) → After 3 seconds (Orange ON) →
When the B2 button is released, Green + Orange blinks alternately (5 seconds) → Green blinks (2 seconds)
If you press the B2 button once when there is Green + Orange blinking (0.5 seconds),
Green blinks 6 times.
Within 3 seconds (Green blinking)
NPN TYPE
Within 3 seconds (Green blinking)
Within 5 sec ( Green + Orange OFF) → After 5 sec (Green + Orange ON) → Release B1 + B2 button to
blinking Green (2 sec)
Within 5 sec (Green+Orange OFF) → After 5 sec (Green+Orange ON) → Release B1 button to blinking
Green + Orange ON (5 sec) → After 5 seconds (Green ON) → B2 button is released, Green blinks (2 seconds)
① ~ ⑦ Saved after a certain period of time after performing the operation (no arbitrary operation),
blinking Green (1 time)After saving the operation value, even if the power is turned off and on,
the previous operation value is saved (automatically saved even in case of power failure)
Before load wiring, Green and Orange blinking alternately at 0.5 second intervals
Normal operation after 2 times Green blinking for NPN load wiring
Normal operation after 2 times Orange blinking for PNP load wiring
52.4
50.0
Black N.O
White COM
Gray N.C
Brown
24 - 240 V d.c./a.c.
24 - 240 V d.c./a.c.
Blue
미러반사형
투과형
미러반사형
Brown +V
LOAD
100 mA Max.
Black OUT
12 - 24 V d.c.
100 mA Max.
LOAD
Blue 0 V
External connection example
■ Reflector (HY-M5)
18.0
LIGHT.ON operation
LIGHT.ON operation
DARK. ON operation
DARK. ON operation
Operation in button
unlocked state
detection
surface
Green Orange
LED LED
B1
button
B2
button
)
▍ Dimension
[unit : mm]
52.4
18.0
50.0 52.4
18.0
50.0
▍ How to install
7.5
1.6
