- Page 1 E1X ISOLATION BASE A Low Noise Floor Is Fundamental...
- Page 2 100% to verify the assembly fits are up to our exacting standards. This rigorous protocol, combined with precision design, results in a product that is a pleasure to install, use, change, or expand at anytime. From all of us here at HRS, we truly hope you enjoy our product.
-
Page 3: Safety Instructions
Safety Instructions IMPORTANT WARNINGS! Do not place any tall objects on the HRS Isolation Base. A tall object is any object with a height that is greater than the length of the HRS Isolation Base. A tall object is also any object that has a height greater than its own width or length. Tall objects must not be placed on top of the HRS Isolation Base for any reason. -
Page 4: Setup Instructions
Base is within the rated load range for SF Footer or is the specific component model number for LF Footers. If the SF or LF Footers of the HRS E1X Isolation Base are overloaded, the HRS isolators will hit a protective stop and significantly reduce the product performance. - Page 5 G7 Footers are threaded fully into the frame and only one is adjusted to prevent rocking. The G7 Feet are not designed to level the base frame. Leveling of the HRS E1X Isolation Base is done by adjusting the HRS audio stand or other supporting structure.
- Page 6 HRS Isolation Base. Even loading of the SF/LF Feet can also be achieved by moving the component until the HRS Isolation Base is level.
-
Page 7: Specifications
The load range can also be identified by the color of the sticker located on the back of the HRS Isolation Base frame. Just cross reference the color of the sticker to the table on the next page that corresponds to your base’s model number. The isolators are also marked with colored dots that should match the colored sticker on the back of the frame. - Page 8 Standard Model HRS E1X Isolation Base Sizes, Physical Characteristics, and Load Ranges (For custom model information please contact HRS.) Model: Dimensions: Base Weight: E1X-1419 19 x 14 x 3 inches 19 lb (48.3 x 35.6 x 7.6 cm) 8.6 kg...
- Page 9 Standard Model HRS E1X Isolation Base Sizes, Physical Characteristics, and Load Ranges (For custom model information please contact HRS.) Model: Dimensions: Base Weight: E1X-1923 23 x 19 x 3 inches 31 lb (58.4 x 48.3 x 7.6 cm) 14.5 kg...
-
Page 10: Care And Maintenance
Care and Maintenance The HRS E1X Isolation Base is a very low maintenance item that will provide many years of trouble-free performance by applying these basic care instructions. Clean the surfaces of the HRS E1X Isolation Base using a lint-free soft (non- abrasive) cloth. -
Page 11: Limited Warranty
Resolution Systems by visiting https://avisolation.com/company-warranty/ and completing the limited warranty registration, within 14 days upon receipt of any HRS product. Scan QR code to register for HRS 5-year limited warranty. The limited warranty extends the 90 days to a period of 5 years from the date... - Page 12 2. The limited warranty does not cover normal recommended care and maintenance. Harmonic Resolution Systems Inc. shall not be responsible in any way for consequential or indirect damages or liabilities resulting from the use of the product covered herein, or, resulting from any breach of this warranty or any implied warranty relating to said product.
- Page 13 (MADE IN USA) All Harmonic Resolution Systems Inc. products are 100% made in the United States of America by skilled craftsmen using only the finest materials and our personal dedication to the highest workmanship standards. ARMONIC ESOLUTION YSTEMS 2495 Main Street, Suite 227 Buffalo, NY 14214 Telephone: 716-873-1437 Web: www.AVisolation.com...
