Summary of Contents for HRS S3
- Page 1 S3 ISOLATION BASE A Low Noise Floor Is Fundamental...
- Page 2 This rigorous protocol, combined with precision design, results in a product that is a pleasure to install, use, change, or expand at any time. From all of us here at HRS, we truly hope you enjoy our product.
-
Page 3: Safety Instructions
Safety Instructions IMPORTANT WARNINGS! Do not place any tall objects on the HRS Isolation Base. A tall object is any object with a height that is greater than the length of the HRS Isolation Base. A tall object is also any object that has a height greater than its own width or length. Tall objects must not be placed on top of the HRS Isolation Base for any reason. -
Page 4: Setup Instructions
If you change the feet of the HRS Isolation Base, we recommend you also change the color-coded dot on the back of the HRS Isolation Base so it is easy to identify what performance setting the base is currently configured to. - Page 5 G7 Footers are threaded fully into the frame and only one foot is adjusted to prevent rocking. The G7 Feet are not designed to level the HRS Isolation Base. Leveling of the S3 Isolation Base is done by adjusting the HRS frame or other supporting structure.
- Page 6 Isolation Bases built for a specific component model have already been set up for that specific component weight distribution. If the component is centered on the custom HRS Isolation Base and the HRS logo is in the right front corner, then the loading of a custom base model is correct.
-
Page 7: Specifications
The load range can also be identified by the color of the sticker located on the back of the HRS Isolation Base frame. Just cross reference the color of the sticker to the table on the next page that corresponds to your base’s model number. The isolators are also marked with colored dots that should match the colored sticker on the back of the frame. - Page 8 S3 Isolation Base Physical Characteristics and Load Ranges Model: Dimensions: Base Weight: S3-1719 19 x 17 x 3 inches 42 lb (48.3 x 43.2 x 7.6 cm) 19.1 kg Sticker / Dot Color Load Range Orange (OR) 0 - 30 lb (0 - 13.8 kg)
-
Page 9: Care And Maintenance
Care and Maintenance The S3 Isolation Base is a very low maintenance item that will provide many years of trouble-free performance by applying these basic care instructions. Clean the surfaces of the S3 using a lint-free soft (non-abrasive) cloth. If needed, use a cloth lightly damped with water. -
Page 10: Limited Warranty
Resolution Systems by visiting https://avisolation.com/company-warranty/ and completing the limited warranty registration, within 14 days upon receipt of any HRS product. Scan QR code to register for HRS 5-year limited warranty. The limited warranty extends the 90 days to a period of 5 years from the date... - Page 11 2. The limited warranty does not cover normal recommended care and maintenance. Harmonic Resolution Systems Inc. shall not be responsible in any way for consequential or indirect damages or liabilities resulting from the use of the product covered herein, or, resulting from any breach of this warranty or any implied warranty relating to said product.
- Page 12 (MADE IN USA) All Harmonic Resolution Systems Inc. products are 100% Made In The United States of America by skilled craftsmen using only the finest materials and our personal dedication to the highest workmanship standards. ARMONIC ESOLUTION YSTEMS 2495 Main Street, Suite 227 Buffalo, NY 14214 Telephone: 716-873-1437 Web: www.AVisolation.com...
