K-1500P-W Ash
F
e
a
t
u
r
e
s
F
e
a
t
u
r
e
s
• Built in volume adjustable ringer
• No dial pad
• Hearing aid compatible amplified handset
with volume control
• Available in two colors: red or ash
• Optional VE-9x12 or VE-9x20 weatherproof box
Need More Information the VE-9x12 or VE-9x20?
?
?
Call (715) 386-4345 and select 413.
