BMPRO ProSmart Install Manual

ProSmart Install Guide
ProSmart is a sensor monitor with an app to easily track multiple sensors and parameters on your adventure, whether you
travel by an RV, a boat, a 4WD or an overland vehicle, giving you a wealth of information for comfort and safe travels. Monitor
water levels in your fresh or grey water tanks, gas levels in your BBQ / propane bottles, tyre pressure (TPMS), temperatures
in the fridge, freezer or inside your vehicle, as well as your 12V battery charge, all from an easy-to-use app on your
smartphone.
1. overview
HOUSE BATTERY
WIRED TEMPERATURE SENSOR
3. mounting
To mount the SmartLink:
1. Create openings for cable
connections if necessary.
2. Mount the SmartLink to the wall
with screws.
3. Make all connections.
For caravan/RV installations, mount it at a high point to avoid
the metal chassis and tow bars, which can cause signal
interference.
To ensure optimal antenna performance, avoid placing the
SmartLink near conductive or metal objects.
Use the QR code to
download the
ProSmart app.
UP TO 4 WATER TANKS
CONNECTED AT ONCE
UP TO 40 SMARTCONNECT SENSORS
CONNECTED AT ONCE
MAXIMUM 4 DEVICES
CONNECTED AT ONCE
4.app
2. description of parts
SmartPressure
TYRE PRESSURE SENSOR
SmartSense
LPG TANK SENSOR
SmartTank
TEMPERATURE SENSOR
SmartSecure
OPEN/CLOSE SENSOR
When opening the ProSmart app for the first time, you will
1. Press Start.
2. Press Continue.
3. If required, allow access to your device's location.
4. Once the Pair your SmartLink screen displays, press the
pairing button on the SmartLink.
1. Dip Switch
2. Display Port
3. CAN Bus Port
4. Water Tank Sensor Connections
5. Product Page QR Code
6. Serial Number
7. Antenna
8. Pairing LED
9. Pairing Button
10. Wired Temperature Sensor Connections
11. 12V Input Connection
5. pairing
need to pair the SmartLink.
From the Welcome screen:
DOC PART 38646
REV 1.0
