- Page 1 OWNER’S MANUAL BatteryCheck SERIES BatteryCheck100 BatteryCheckPRO TEAMBMPRO.COM...
- Page 3 To learn more about the BMPRO range of products, please visit our website teambmpro.com TEAM BMPRO .COM...
-
Page 4: Safety Precautions
SAFETY PRECAUTIONS Please read the Safety Precautions before installing or using the BatteryCheck. Be sure to observe all precautions without fail. Failure to observe these instructions properly may result in personal damage or personal injury which, depending on the circumstances, may be serious and cause loss of life. WARNING Correct installation is the most critical factor in ensuring the safe use of the BatteryCheck. -
Page 5: Table Of Contents
DISCLAIMER BMPRO accepts no liability for any loss or damage which may occur from the improper or unsafe use of its products. Warranty is only valid if the unit has not been Copyright ©... -
Page 6: About The Batterycheck
ABOUT THE BATTERYCHECK BMPRO’s BatteryCheck is a 12V battery monitor, that allows you to check the status of your secondary battery via your smartphone with the BMPRO BatteryCheck100+PRO app. The BatteryCheck monitors a range of battery parameters via the app, using the latest built-in Bluetooth® wireless technology. -
Page 7: Identity
We recommend noting down your unique PIN in a safe place. If you do lose your PIN, please send an email to service@teambmpro.com for further details. BMPRO BATTERYCHECK100+PRO APP The BMPRO BatteryCheck100+PRO app is compatible with mobile phones operating on Apple iOS10 or greater and Android™ 4.4 or greater. -
Page 8: Description Of Parts
DESCRIPTION OF PARTS Figure 2: BatteryCheck description of parts Negative Battery Terminal/Connection New Negative Terminal Connection (connects to load) ‘+’ Positive Flying Lead and Temperature Sensor The BatteryCheck has a terminal at each end; using these two terminals, the BatteryCheck is bolted in series with the negative terminal of the battery to be monitored. -
Page 9: Installation And Usage
INSTALLATION AND USAGE INSTALLING THE BATTERYCHECK TO THE BATTERY WARNING To avoid sparking, practice standard safety precautions. Disconnect all loads from the battery before installing the BatteryCheck. Before you start, write down the 6-digit PIN found on the back of the BatteryCheck. -
Page 10: Light Indications
CONNECTING TO THE BMPRO BATTERYCHECK100+PRO APP Install the BMPRO BatteryCheck100+PRO app via Google Play™ or the Apple App Store. You can search for “BMPRO” or use the respective QR codes below. Open the app and tap the menu button in the top left corner. Select the “Add Battery”... - Page 11 You will now be in the Dashboard where you can monitor the battery’s state of charge, voltage, current, temperature, time remaining and the battery’s state of health. When prompted, enter the 6-digit PIN noted before installing the BatteryCheck to the battery. Your BatteryCheck is now ready to use.
- Page 12 BATTERY STATE OF HEALTH The BMPRO BatteryCheck100+PRO app will provide a State of Health estimate for the battery being monitored by the BatteryCheck. After installation, the initial State of Health will be set to 100% and will update over time as the BatteryCheck learns your battery.
-
Page 13: Cleaning
CLEANING Use a dry or moist cotton cloth to lightly remove any dust or dirt from the BatteryCheck. Do not use alcohol, thinners, benzene or any other chemical cleaner as these products may degrade the housing surface. Do not immerse the BatteryCheck in water. FAQS AND TROUBLESHOOTING 1. -
Page 14: Specifications
SPECIFICATIONS SPECIFICATION BATTERYCHECK100 BATTERYCHECKPRO Voltage Measurement 8 to 16V Range Voltage Measurement <20mV Resolution Current Measurement ± 100A ± 300A Range Continuous Current Rating ± 80A ± 240A Current Measurement <20mA <150mA Resolution Temperature Measurement -20 to 70°C Range Temperature Measurement 1°C Resolution Monitored Battery Capacity... -
Page 15: Warranty Terms And Conditions
7. BMPRO will not be liable for any costs, charges or expenses incurred in the process of returning a product in order to initiate a warranty claim. - Page 16 BMPRO TEAM +61 3 9763 0962 sales@teambmpro.com BMPRO 19 Henderson Rd, Knoxfield VIC 3180 Australia .COM teambmpro.com...
