Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small
parts which may have come loose inside the carton during shipment. Identify and count all parts and
compare with the parts list below.
COMPONENT LIST
NO.
Description
Back Rest
A
Seat Cushion
B
Front Leg - L
C
Front Leg - R
D
Stretcher
E
PARTS DETALLS
This product is manufactured by JSFC for
ASSEMBLY INSTRUCTION
727 / 728-12 SIDE CHAIR
Sketch Q`TY
NO.
1pc
1
1pc
2
1pc
3
4
5
1pc
6
7
2pcs
8
9
E
HARDWARE LIST
Description
Flat Washer
Spring Washer
Bolt
Flat Washer
Spring Washer
Bolt
Allen Key
Flat Washer
Spring Washer
Nut
Wrench
Screw
Tool Required(not provided)
A
B
C
Hardware pack locations
727 / 728 - 12 SIDE CHAIR, SKU# 42407278 / 42407280
SKU
42407278 / 42407280
Dimension
5/16"*22*2mm
5/16"*12*2mm
5/16"*18*89mm
1/4"*19*2mm
1/4"*12*2mm
1/4"*20*32mm
4mm
5/16"*22*2mm
5/16"*12*2mm
5/16"*12mm
12*88mm
#4 x 45mm
D
Q'TY
8 pcs
8 pcs
4 pcs
2 pcs
2 pcs
2 pcs
1 pc
4 pcs
4 pcs
4 pcs
1 pc
4 pcs
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO JSFC 727
Summary of Contents for ROOMS TO GO JSFC 727
- Page 1 ASSEMBLY INSTRUCTION JSFC 42407278 / 42407280 727 / 728-12 SIDE CHAIR Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts which may have come loose inside the carton during shipment. Identify and count all parts and compare with the parts list below.
- Page 2 ASSEMBLY INSTRUCTION JSFC 42407278 / 42407280 727 / 728-12 SIDE CHAIR STEP 1: Attach the Seat Cushion (B) to Back Rest （ A), secure with Flat Washers, Spring Washers and Bolts (2) by using Allen Key (3). STEP 2: Attach the Seat Cushion (B) to Back Rest （ A) , secure with Flat Washers, Spring Washers and Bolts (1) by using Allen Key (3).
