CrimeStopper SecurView SV-6710 Installation Manual

SecurView SV-6710 / SV-6711 High Resolution CCD Color Reverse Cameras

FEATURES:

High resolution Color CCD camera.
Water, Vibration, and Shock proof aluminum housing
Mounts through any smooth flat surface up to ½ thick
130 degree wide viewing angle
Mirror imaging built-in
Low light capability (1 Lux)
Custom mount in your rear bumper, valance, tailgate, liftgate or overhead locations.
Mounting Hardware & Cables Included
Universal mount chassis and bracket (Included on SV-6710 H / SV-6711 H only)

SPECIFICATIONS:

1/3 CCD
Size: 1.7 x 1.7 x 1.9"
(44 x 44 x 48mm)
Weight 4.6 Oz. (128 G)
Pixels: 512 (H) x 492 (V)
Resolution: Up to 250,000 pixels
More than 330 TV lines
Minimum Illumination: 1 LUX / F 1.2
Lens Type: Wide Angle Pinhole
Horizontal Angle: 130
Vertical Angle: 110

Installation Guide

Video Output: 1.0 V P-P composite (75 Ohm load)
Supply Voltage: +12VDC
Power Consumption: 180mA typ.
Electronic Shutter: 1/60 s – 1/100000s
White Balance: Automatic
Gamma Correction: 0.45
S/N Ratio: More than 48dB
Operating Temp: -13 to 185 F (-25 to 85 C)
Gain Control: Automatic
Digital Signal Processor w/10 Bit A/D Converter
