1.2 Steering wheel installation

Our universal hub on the back of the wheel body allows the user to install various adapter, or
even connect it directly to your FFB base.
Highlighted in blue are the M5x0.8 metric holes. In grey, 5,5mm through holes. Both of them are
available in 70mm or 50.8mm bolt patterns.
Through holes are rotated by 180°, so flipping your adapter to match the wheel hub may be
needed. Please refer to your adapter or motor manufacturer to ensure compatibility.
Inner 50.8mm
pattern
Outer 70mm
pattern
