Summary of Contents for Cube Controls GT-X2

  • Page 1 User manual...
  • Page 2 Before you start please read the manual carefully before you use the steering wheel. Any modifications, tampering, changes or unauthorized uses of the product will void the warranty. The steering wheel has no waterproof feature, please keep it away from water, rain, moisture and other items containing liquid such as vape, cups etc.
  • Page 4 800x480 LCD with touch screen Native Simhub support 21 RGB LEDs All buttons, dials and LED bars compatible with Simhub via a dedicated plugin...

  • Page 6: Table Of Contents

    Contents 1. INTRODUCING THE HARDWARE 3. CONNECTING SIMHUB 1.1 Interface 4. USEFUL TIPS 1.2 Steering Wheel Installation 1.3 Shifter Paddles Adjustment 1.4 Clutch Paddles Adjustment 1.5 Connecting the GTX-2 2. NAVIGATING THE SOFTWARE 2.1 Introduction 2.2 Inputs 2.3 RGB 2.4 Paddles 2.5 Device 2.6 About...
  • Page 7 What you will find in the box GTX-2 Steering Wheel Q-CONN USB Cable 1x Stickers 3.0 Sheet Tool Bag containing: Torx Screwdriver (red) Philips Screwdriver (black) TX10 Allen key TX20 Allen key TX25 Allen key Nylon Tweezers 3x M5x10 hex bolts 3x M5x16 hex bolts 3x M5x10 button TORX 3x M5 nut...

  • Page 8: Introducing The Hardware

    1. INTRODUCING THE HARDWARE...

  • Page 9: Interface

    1.1 Interface 3 - 4 35 - 36 Back Toggle Back Toggle Switch Switch Push: 13 Push: 45 15 - 14 encoder 25 - 26 17 - 18 19 - 20 9 up 10 left 47-46 encoder 11 down 12 right 41 up 42 left 43 down...
  • Page 10 The POV switches/funky switches/joysticks directions (up, down, left, right) are meant to work only if a “clicky” sound feedback occurs. Therefore there’s no risk to press the direction and accidentally enable the centre click button. Toggles 24 and 32 work this way: once the toggle has been activated the respective led will turn on, when the toggle has been flipped off it turns the led off.

  • Page 11: Steering Wheel Installation

    1.2 Steering wheel installation Our universal hub on the back of the wheel body allows the user to install various adapter, or even connect it directly to your FFB base. Highlighted in blue are the M5x0.8 metric holes. In grey, 5,5mm through holes. Both of them are available in 70mm or 50.8mm bolt patterns.

  • Page 12: Shifter Paddles Adjustment

    1.3 Shifter Paddles Adjustment Shifter paddles can be easily adjusted to better suit your hand size and driving preferences. NOTE: TX10 drive needed. All steering wheel screws are tightened with a tightening torque of 3.5 Nm, except for the two screws indicated in red, tightened with a tightening torque of 4 Nm.

  • Page 13: Clutch Paddles Adjustment

    1.4 Clutch Paddles Adjustment The travel of the clutch paddles can be adjusted in the same way as the shifters. Spring resistance can be adjusted by turning the screw by using the provided TX10 Allen Key (smallest L-shaped silver key) as indicated in the picture below:...

  • Page 14: Connecting The Gtx-2

    1.6 Connecting the GTX-2 Our GTX-2 has the most reliable connection we designed yet! Thanks to the Q-CONN, connecting your steering wheel have never been this easy: Just plug the Q-CONN connector on the back of the device. Having done that, remember to press the On/Off button on the back of the wheel and the operative system should immediately recognize the device.

  • Page 15: Navigating The Software

    2. NAVIGATING THE SOFTWARE...

  • Page 16: Introduction

    2.1 Introduction The CubeSet app is here and you can download it from our website. Now, thanks to our proprietary software you can configure your Steering Wheel in every little detail and most of all you can update your wheel firmware with new content that we release continuously.
  • Page 17 STARTING THE CUBESET APP Once the steering wheel is connected and recognized by the PC (see the Connecting the GTX-2 section of this guide), you can then start the CUBESET APP. If the wheel is successfully recognized by the CUBESET APP, this is what you will see at the top of the window: If the wheel is not connected to the PC or not successfully recognized, this is what you will see at the top of the window:...

  • Page 18: Inputs

    2.2 Inputs On the INPUTS page, you can check the correct functionality of every button and encoder present in your wheel, modify the Encoder Pulse Width and calibrate the Clutches.
  • Page 19 CHECKING THE BUTTONS Nothing is easier than that: every button press or encoder rotation on the Steering Wheel will consequently light up the corresponding button/encoder showing their correct input number. ENCODER PULSE WIDTH With this slider, you will be able to set a value between 40ms and 240ms for your Encoder Pulse Width! The higher the value, the longer the pulse, ensuring the inputs are recognized by every system/simulator.
  • Page 20 The process is simple: when connecting the CSX-3 for the first time the clutches could be not correctly recognized in their full course when pressed. In this case, clicking on “CALIBRATE” will make the RAW values of the clutch appear. Pressing now the clutch full-course will make the system set the correct minimum and maximum values.

  • Page 21: Rgb

    2.3 RGB On the RGB page, you can customize every RGB LED present on the wheel in colour and brightness.
  • Page 22 RGB CUSTOMIZATION...
  • Page 23 The system here is quite straightforward: you can select your colour from the classic ones, or pick your favourite, and then add it to Custom Colours. Oh, and remember to select the Brightness level! For those of you who have their image reference on the PC, you can also use the screen colour picker to reproduce whatever colour you see on your screen.

  • Page 24: Paddles

    2.4 Paddles On the PADDLES page, you have the CLUTCHES section and the SHIFTERS section. In the CLUTCHES section, you can enable/disable the clutches and the Bite Point. For the Bite Point, you will also be able to select the Slave Clutch to be the Left or the Right one and then limit the percentage for it.
  • Page 25 CLUTCHES SECTION Once you calibrate the Clutches on the Inputs page, it is time to set the Bite Point! By default, the maximum value of the Slave Clutch can be adjusted with the respective slider. Therefore, if the clutch slider is set in the middle of its travel when fully depressing the left clutch paddle, its value will go from the minimum to half of the maximum value.
  • Page 26 This way the Launch Control will be no longer available and this is a valuable feature, especially for users with leg impairments since it allows them to be set as Throttle and Brake directly on the Steering Wheel. IMPORTANT: After each value modification, remember to press the SAVE SETTINGS button.
  • Page 27 Setting the Bite Point on the fly It is also possible to modify the Bite Point on the fly, without going back to the CubeSet app in the middle of your driving session! To do so, you will need to set an encoder of your steering wheel for this function. Nothing easier! First of all click the button under the Bite Point slider, to start the process.
  • Page 28 SHIFTERS SECTION After the first use, you may notice some missing or double shifts. This is caused by different systems incompatibilities that may diminish or increase the input duration, making the shifting incorrectly recognized. Because of this, you will need to directly intervene and calibrate the value for the two shifters separately to reach the perfect shifting.
  • Page 29 Following the instructions press and hold the corresponding shifter and then click the button. The shifter paddle is now perfectly functional! Repeat on the other one and you will be good to go. IMPORTANT: Remember to click SAVE SETTINGS after the calibration. Please also note that if you have purchased and correctly mounted the two additional paddles, you will be able to also calibrate them here! Remember to Enable them at the top of the page and follow the same exact procedure.

  • Page 30: Device

    2.5 Device On the DEVICE page, you can update your steering wheel’s Firmware and Factory Reset your wheel.
  • Page 31 UPDATING THE FIRMWARE When updating the firmware you have two choices: you can check online for updates (CHECK UPDATE) or, if you already have downloaded the new firmware update on your PC, you can select it and upload it manually (MANUAL UPDATE). CLEAR FLASH DATA If you need for whatever reason to do a Factory Reset of your steering wheel, you can now use this button and clear everything in its memory with just a click!

  • Page 32: About

    2.6 About On the ABOUT page, you can find additional information like the Firmware version your steering wheel is on or the CubeSet App version.

  • Page 33: Connecting Simhub

    3. CONNECTING TO SIMHUB...
  • Page 34 3. Connecting to SIMHUB Simhub compatibility is natively guaranteed on the GTX-2! Thanks to Simhub the RGB LEDs can be now customized to blink/change colour/switch on and off according to your SimHub configuration, making your experience with Cube Controls even deeper. NOTE: The latest compatible version of Simhub is the 8.1.2.
  • Page 35 Select your steering wheel from the list: You can now create multiple profiles and edit them with various effects and functions: thanks to the Simhub versatility, the only limit is your own imagination! IMPORTANT: The GTX-2 uses a Vocore screen, so make sure you download the correct drivers from the Simhub website to make it work properly!

  • Page 36: Useful Tips

    4. USEFUL TIPS...
  • Page 37 Make sure your rig is grounded correctly. Each wheel comes with an auxiliary USB connector that comes out from the main hub. This will be used with our Cube Controls QRX quick-release kit.
  • Page 38 www.cubecontrols.com...
