OPERATION MANUAL
Timan 3330
Type-serialnumber: 712000x00xAAAA
"Comfortably Better"
www.timan.dk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3330 and is the answer not in the manual?

Questions and answers

Summary of Contents for Timan 3330

  • Page 1 OPERATION MANUAL Timan 3330 Type-serialnumber: 712000x00xAAAA ”Comfortably Better” www.timan.dk...
  • Page 2: Table Of Contents

    CONTENTS MACHINE IDENTIFICATION DATA ..................2 INTENDED USE OF THE MACHINE ..................4 ............4 EIGHT TABLE FOR USING TOOLS AND ACCESSORIES ............5 HE PERMISSIBLE LOAD ON THE FRONT OF THE MACHINE ............6 ERMISSIBLE LOAD ON THE REAR END OF THE MACHINE ............7 AXIMUM PERMISSIBLE SIDE LOAD OF THE MACHINE NOISE (SOUND PRESSURE) AND VIBRATIONS ..............8 ..................8...
  • Page 3: Machine Identification Data

    Congratulations on your new Timan 3330 This operator's manual will assist you in the proper use, adjustment and maintenance of your new machine. Before you start to drive or work with the new machine, read this operator's manual thoroughly, in particular the section on safety rules.
  • Page 4 MACHINE IDENTIFICATION DATA Type label Identification number 712000X00X1001 Type Serial Machine number 712000 1001...
  • Page 5: Intended Use Of The Machine

    INTENDED USE OF THE MACHINE 2. INTENDED USE OF THE MACHINE Timan 3330 is a universal tool carrier that can perform many tasks depending on the type of equipment attached to it. It could, for example, cut grass, sweep, cut live fences, remove snow, salt roads etc.
  • Page 6: The Permissible Load On The Front Of The Machine

    INTENDED USE OF THE MACHINE The permissible load on the front of the machine The maximum permissible load on the lifting arms is shown in the diagram below Ingen bagvægt - Without rear weight Till. vægt front - Perm. load front Min 200kg bagvægt - Min 200kg rear weight -800 -400...
  • Page 7: Permissible Load On The Rear End Of The Machine

    900 mm away from the centre of the rear wheels - 300 mm if the measurement is taken from the rear end of the machine. Important: It is necessary to use the original Timan A/S tool frame when loading the rear end.
  • Page 8: Maximum Permissible Side Load Of The Machine

    INTENDED USE OF THE MACHINE Maximum permissible side load of the machine The maximum permissible side load of the machine is specified in the diagram below. Till. side vægt - perm. side load 1200 1600 2000 2400 2800 3200 3600 Caption: Maximum permissible side load of the machine The mass table shows point 0 between the lifting arms and on the ball joint at the rear end of the machine (if it is attached).
  • Page 9: Noise (Sound Pressure) And Vibrations

    Measurements were taken in 2 various operating situations Driving on a road at a speed of 27 km/h. Motor speed (revolutions) 3600 rpm Mowing grass with a Timan 1,35 m mowing conditioner Driving speed: 6 km/h Motor speed (revolutions) 3000 rpm Body vibration when driving on a road: a = 0.48 m/s...
  • Page 10: Machine Construction

    MACHINE CONSTRUCTION 4. MACHINE CONSTRUCTION It is an articulated machine which thus has a very small turning radius. The joint is located midway between the front and rear wheels, thus the rear wheels follow the route of the front wheels. The joint is firmly attached from the side in order to ensure greater stability when loads are being lifted.
  • Page 11: Steering Column, Operator's Grip, Cabinet And Air Switches

    STEERING COLUMN, OPERATOR'S GRIP, CABINET AND AIR SWITCHES. 5. STEERING COLUMN, OPERATOR'S GRIP, CABINET AND AIR SWITCHES. Cabin, controls, display and ceiling 1. Side panel 2. Display 3. Ignition lock 4. Accelerator 5. Steering column multi-switch 6. Ceiling...
  • Page 12: Side Panel

    STEERING COLUMN, OPERATOR'S GRIP, CABINET AND AIR SWITCHES. Side panel 1. Main starter for PTO. Both the PTO (front [5] and rear [19]) + 12V switch [22] pass through this switch. This makes it possible to start and stop the front and rear tools at the same time. Note that there is a delay of approx.
  • Page 13 STEERING COLUMN, OPERATOR'S GRIP, CABINET AND AIR SWITCHES. Used, among other things, on the sweep/suction system to adjust the rotation speed of the brushes. 9. Light switch. Step 1 position light - Step 2 headlight 10. Cruise control. When the desired travel speed is achieved with the accelerator, the switch is activated and this speed is maintained.
  • Page 14: Display

    3. Engine Warning Light. Engine fault. Error codes appear on the information display. 4. Engine oil pressure. Warning if oil pressure is too low, and an acoustic alarm. 5. Differential lock activated (not available on Timan 3330). 6. Hydraulic oil temperature. Warning if the hydraulic oil temperature gets too high.
  • Page 15: Ignition

    STEERING COLUMN, OPERATOR'S GRIP, CABINET AND AIR SWITCHES. Ignition 0: Off Position which allows the key to be inserted or removed from the start switch. When the key is in this position, the gasoline engine is stopped. I: On Ignition is on II: Start Engine start signal Foot pedals...
  • Page 16: Steering Column Multi-Switch

    STEERING COLUMN, OPERATOR'S GRIP, CABINET AND AIR SWITCHES. Steering column multi-switch 1. Flash high beam. 2. Low beam: 3. High beam: 4. Rotary wiper switch. J Intermittent wiper function. 0: No wiper function. I: Low speed wiper function. II: High speed wiper function. 5.
  • Page 17: Ceiling

    STEERING COLUMN, OPERATOR'S GRIP, CABINET AND AIR SWITCHES. Ceiling 1. Speakers. 2. Radio (see separate operating instructions). 3. Front working light. 4. Rear working light. 5. Rotating beacon on machine and tools (pin 13 in 13 pol connector) 6. Working light on tools (extra equipment pin 10 in 13 pol connector). 7.
  • Page 18: Main Circuit-Breaker, Fuses And Relays, Error Codes

    MAIN CIRCUIT-BREAKER, FUSES AND RELAYS, ERROR CODES 6. MAIN CIRCUIT-BREAKER, FUSES AND RELAYS, ERROR CODES The machine's electrical system is divided into 6 different areas: 1. Main circuit-breaker. 2. Main fuses and relays rear. 3. Fuses front. 4. Fuses ceiling. 5.
  • Page 19: Main Fuses And Relays Rear

    MAIN CIRCUIT-BREAKER, FUSES AND RELAYS, ERROR CODES Main fuses and relays rear. IMPORTANT: Never replace fuses with fuses that have greater ampere values. There is always a reason why a fuse blows. Investigate the cause and remedy the problem before inserting a new fuse.
  • Page 20: Fuses In The Cabinet Roof

    MAIN CIRCUIT-BREAKER, FUSES AND RELAYS, ERROR CODES Fuses in the cabinet roof The fuse box sits on the right side of the cabinet roof. F3-1 15 A Work light front. F3-2 Work light rear. F3-3 10 A Rotating beacon/Strobe light. F3-4 10 A Work light tool.
  • Page 21: Fuses In The Cabin

    MAIN CIRCUIT-BREAKER, FUSES AND RELAYS, ERROR CODES Fuses in the cabin The fuse boxes are located to the right of the driver's seat. 12 V cabin power Fuses F1-7 to F1-8 are connected directly to the battery. All other fuses are activated upon ignition. Top fuses F1-1 15 A...
  • Page 22: Relays Front

    MAIN CIRCUIT-BREAKER, FUSES AND RELAYS, ERROR CODES Relays front R1: Lower cabin relay. R2: Upper cabin relay (roof). R3: Seat switch + PTO Logic rear. The engine will continue to run, even if you rise from the seat when the Rear PTO is active. R4: Start logic: The engine cannot start if the front PTO or rear PTO is activated.
  • Page 23: Pole Trailer Socket Rear

    MAIN CIRCUIT-BREAKER, FUSES AND RELAYS, ERROR CODES 13 pole trailer socket rear The diagram below shows an overview of the 13 pole trailer socket on the rear of the machine Turn signal Left Pin 1 S75 - Water on / off Pin 2 Pin 3 Turn signal right...
  • Page 24: Use Of The Machine - Qr Code

    USE OF THE MACHINE - QR CODE 7. USE OF THE MACHINE - QR CODE The features of the machine are described with videos which you can access by scanning the QR code with your mobile phone or tablet. It is important that you are familiar with the machine before you start driving.
  • Page 25: Additional Equipment

    USE OF THE MACHINE - QR CODE Washer fluid. Brake maintenance and adjustment. Maintain wheels and tires. Lubrication. Daily checks Changing fuses. Relays rear. Relays front. Cleaning the machine. Main circuit-breaker. Diagnoses on display. Additional equipment Towbar.
  • Page 26: Maintenance Data

    MAINTENANCE DATA 8. MAINTENANCE DATA This section contains data regarding maintenance of the machine. Hydraulic oil Standard: Shell Tellus S3 V 46 Optional (Factory only) ELF Biohydran TMP 46 Top up with the type of oil filled from the factory. If you want to refill with another brand, contact the manufacturer in terms of miscibility.
  • Page 27: Technical Data

    TECHNICAL DATA 9. TECHNICAL DATA Model TIMAN 3330 Motor Kubota Number of cylinders Piston displacement Hp/kW 33/24 Cooling system Water cooling (45°C outdoor temperature) Gasoline tank 37 L Transmission Piston pumps Wheel motors 4x Orbital motors Speed 0-27 km/h Work hydraulics...
  • Page 28: Ce Declaration Of Conformity

    Post code and city 6980 Tim Hereby declares that machine type: Timan 3330, with type number 712000X00AAAA (AAAA = serial number) Made in accordance with 2006/42/EU Machinery Directive Using the following harmonized standards: OECD Code 7 or EU 1322/2014, Annex X. Rollover Protection Structure ROPS...
