OPERATING INSTRUCTIONS
TitroLine® 6000/7000
TITRATOR

Advertisement

loading
Need help?

Need help?

Do you have a question about the SI Analytics TitroLine 6000 and is the answer not in the manual?

Questions and answers

Related Manuals for Xylem SI Analytics TitroLine 6000

Summary of Contents for Xylem SI Analytics TitroLine 6000

  • Page 1 All manuals and user guides at all-guides.com OPERATING INSTRUCTIONS TitroLine® 6000/7000 TITRATOR...
  • Page 2 All manuals and user guides at all-guides.com Wichtige Hinweise: Important notes: Instructions importantes: Instrucciones importantes: Copyright...
  • Page 3 All manuals and user guides at all-guides.com Technical Specifications of the Titrator TitroLine® 6000/7000 ......89 Unpacking and First Operation ................94 ® Working with the Titrator TitroLine 6000/7000 ..........107 Method Parameters ....................121 System settings ..................... 152...
  • Page 4 All manuals and user guides at all-guides.com Data Communication via RS-232- and USB-B interface ........162 Connection of Analytical Balances and Printers ..........164 ® Maintenance and Care of the TitroLine 6000/7000 ..........168 Storage and transportation................... 169 10 Recycling and Disposal..................169 11 Index ........................
  • Page 5 All manuals and user guides at all-guides.com Technical Specifications of the Titrator TitroLine® 6000/7000 1.1 Summary Solutions to be used: General provisions: Guarantee...
  • Page 6 All manuals and user guides at all-guides.com ® 1.2 Specifications Titrator TitroLine 6000/7000 CE sign: Country of origin...
  • Page 7 All manuals and user guides at all-guides.com Display: Power supply: RS-232-C Interface / none 4800 (0 to 15, default: 01) plus, universal USB Interface: Stirrer connection 12V DC out 500mA Housing material: Front keyboard: Housing dimensions: Weight: Ambient conditions:...
  • Page 8 All manuals and user guides at all-guides.com Interchangeable units Dosing accuracy of the Titrator TitroLine 6000/7000 with WA interchangeable units:...
  • Page 9 All manuals and user guides at all-guides.com Chapter 1 – Specifications Titrator TitroLine 6000/7000 1.3 Warning and safety information ® In the case of nonobservance of these provisions the titrator TitroLine 6000/7000 may constitute a danger: electrical accidents of persons or fire hazard. Moreover, in the case of unauthorised ®...

  • Page 10: Unpacking And First Operation

    All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation 2 Unpacking and First Operation 2.1 Unpacking and First Operation of the titrator 2.2 Installing the Z 300 Rod Foot Plate (Optional)
  • Page 11 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation 2.3 Connection and installation of titrator and magnetic stirrer TM 235...
  • Page 12 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation 2.4 Connecting the Titrator - Combination with Accessories and Additional Devices ® 2.4.1 Back panel of the titrator TitroLine 6000/7000 ® 2.4.2 Connection ports of the TitroLine 6000/7000 2.4.3 Connecting a printer...
  • Page 13 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation 2.4.5 Connection of analytical balances ® 2.4.6 Connection of SI Analytics ID electrodes to TitroLine 7000 2.5 Setting the Language of the Country...
  • Page 14 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation...
  • Page 15 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation 2.6 Interchangeable unit WA 2.6.1 Installing the interchangeable unit...
  • Page 16 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation 2.7 Positioning and Replacing an Interchangeable Unit 2.7.1 Placing an interchangeable unit...
  • Page 17 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation 2.7.2 Removing an interchangeable unit ! Please note: Removing the interchangeable unit is only possible as long as the piston is in the lower position (zero position). Possibly, it may be necessary to press the <FILL> key first. ! 2.7.3 Programming the titration unit...
  • Page 18 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation...
  • Page 19 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation 2.8 Initial Filling or Rinsing of the Entire Interchangeable Unit...
  • Page 20 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation...
  • Page 21 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation 2.9 Replacing the Glass Cylinder and the PTFE Piston...
  • Page 22 All manuals and user guides at all-guides.com Chapter 2 - Unpacking and first Operation Warning...

  • Page 23: Working With The Titrator Titroline

    All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000 ® 3 Working with the Titrator TitroLine 6000/7000 3.1 Front Keyboard <Mode>: <EDIT> <ESC>: <ESC <START> <FILL> Chapter 3.4, External PC Keyboard 3.2 Display...
  • Page 24 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000 3.3 Manual controller “mouse“ 3.4 External PC Keyboard Keys Function <ESC <ESC...
  • Page 25 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000 3.5 Menu Structure...
  • Page 26 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000...
  • Page 27 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000 3.6 Main Menu 3.6.1 Automatic Titration...
  • Page 28 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000...
  • Page 29 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000 3.6.2 Calibration (CAL menu)
  • Page 30 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000...
  • Page 31 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000...
  • Page 32 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000 3.6.3 Manual Titration <START>/<F1> Chapter 3.6.1...
  • Page 33 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000 Example: WA 20 interchangeable unit: 3.6.4 Dosage...
  • Page 34 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000...
  • Page 35 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000...
  • Page 36 All manuals and user guides at all-guides.com ® Chapter 3 – Working with the titrator TitroLine 6000/7000 3.6.5 Preparing Solutions...

  • Page 37: Method Parameters

    All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4 Method Parameters 4.1 Method editing and new method Chapter 4.5 4.2 Default methods...
  • Page 38 All manuals and user guides at all-guides.com Chapter 4 Method Parameters Chapter 4.5 4.3 Copy Methods Chapter 4.5 4.4 Delete Methods <Yes>...
  • Page 39 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.5 Print method 4.6 Change Method Parameters Chapters 4.1 4.6.1 Method type...
  • Page 40 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.2 Titration mode 4.6.2.1 Linear titration 4.6.2.2 Dynamic titration...
  • Page 41 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.2.3 End-point titration 4.6.2.4 pH Stat Titration...
  • Page 42 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.3 Result...
  • Page 43 All manuals and user guides at all-guides.com Chapter 4 Method Parameters only total consumption Formula“ Result text...
  • Page 44 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.3.1 Calculation Formula Formula selection...
  • Page 45 All manuals and user guides at all-guides.com Chapter 4 Method Parameters Formula for linear and dynamic Formula for titrations to end- Additional information titration to EQ1 point (EP 1 and EP2)
  • Page 46 All manuals and user guides at all-guides.com Chapter 4 Method Parameters Formela for linear and dynamic Hinweis titration to EQ2...
  • Page 47 All manuals and user guides at all-guides.com Chapter 4 Method Parameters...
  • Page 48 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.3.2 Sample weight and volume (sample quantity)
  • Page 49 All manuals and user guides at all-guides.com Chapter 4 Method Parameters Manual sample weight Automatic sample weight: Fixed sample weight Manual sample volume Fixed sample volume 4.6.3.3 Formula unit Unit...
  • Page 50 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.3.4 Formulae for the Preparation of Solutions W*(100-Fa-Fb)*Fc/Fd - W*(100-Fb) / (100*Fe) +Ff W*(100-Fa-Fb)*(Fd/Fg ) - W*(100-Fb) / (100*Fg) +Ff W*(100-Fa-Fb)*Fc / (100*Fd) Note on volume correction:...
  • Page 51 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.3.5 Decimal digits 4.6.3.6 Statistics...
  • Page 52 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.3.7 Global Memories <Enter/OK> <Ins> “M01” “blank value”...
  • Page 53 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.4 Titration parameters <Titration parameter>...
  • Page 54 All manuals and user guides at all-guides.com Chapter 4 Method Parameters Generally applicable titration parameters <Measured value> <Measuring speed>...
  • Page 55 All manuals and user guides at all-guides.com Chapter 4 Method Parameters norma ”user- defined”...
  • Page 56 All manuals and user guides at all-guides.com Chapter 4 Method Parameters <Initial waiting time> Dynamic control...
  • Page 57 All manuals and user guides at all-guides.com Chapter 4 Method Parameters Attenuation setting...
  • Page 58 All manuals and user guides at all-guides.com Chapter 4 Method Parameters Linear titration Titration direction increase decrease increase decrease Pretitration <Pretitration>...
  • Page 59 All manuals and user guides at all-guides.com Chapter 4 Method Parameters Titration end End value slope value Maximum titration volume...
  • Page 60 All manuals and user guides at all-guides.com Chapter 4 Method Parameters maximum titration volume...
  • Page 61 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.5 ‘End-point titration’ and ‘dead-stop titration’ titration parameters Dead-Stop Titration and Polarisation voltage...
  • Page 62 All manuals and user guides at all-guides.com Chapter 4 Method Parameters ® 4.6.6 Titration parameter pH Stat Titration (only TitroLine 7000)
  • Page 63 All manuals and user guides at all-guides.com Chapter 4 Method Parameters Important: Determination of Enzyme Activity...
  • Page 64 All manuals and user guides at all-guides.com Chapter 4 Method Parameters...
  • Page 65 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.7 Dosing parameter Interchangeable unit Max. dosing speed [ml/min]...
  • Page 66 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.8 Sample identification...
  • Page 67 All manuals and user guides at all-guides.com Chapter 4 Method Parameters 4.6.9 Documentation Method type Short documentation Standard GLP-Documentation documentation...

  • Page 68: System Settings

    All manuals and user guides at all-guides.com Chapter 5 - System Settings 5 System settings Chapter 2.5 5.1 Calibration settings...
  • Page 69 All manuals and user guides at all-guides.com Chapter 5 - System Settings...
  • Page 70 All manuals and user guides at all-guides.com Chapter 5 - System Settings 5.2 Interchangeable Unit - Reagents...
  • Page 71 All manuals and user guides at all-guides.com Chapter 5 - System Settings...
  • Page 72 All manuals and user guides at all-guides.com Chapter 5 - System Settings 5.3 RS232 Settings...
  • Page 73 All manuals and user guides at all-guides.com Chapter 5 - System Settings...
  • Page 74 All manuals and user guides at all-guides.com Chapter 5 - System Settings 5.4 Date and Time 5.5 Password 5.6 RESET Please note: connected USB storage medium (this will be possible with a higher update!).
  • Page 75 All manuals and user guides at all-guides.com Chapter 5 - System Settings 5.7 Printer 5.8 Device Information 5.9 System Tone...
  • Page 76 All manuals and user guides at all-guides.com Chapter 5 - System Settings 5.10 Software Update...
  • Page 77 All manuals and user guides at all-guides.com Chapter 5 - System Settings Important:...

  • Page 78: Data Communication Via Rs-232- And Usb-B Interface

    All manuals and user guides at all-guides.com Chapter 6 Data Communication via RS-232 and USB-B interface 6 Data Communication via RS-232- and USB-B interface 6.1 General Information PIN-No. Meaning / Description 6.2 Chaining multiple devices —“Daisy Chain Concept“ Chapter 5.3 6.3 Instruction Set for RS-Communication Every...
  • Page 79 All manuals and user guides at all-guides.com Chapter 6 Data Communication via RS-232 and USB-B interface Command Description Reply “text...

  • Page 80: Connection Of Analytical Balances And Printers

    All manuals and user guides at all-guides.com Chapter 7 – Connection of Analytical Balances and Printers 7 Connection of Analytical Balances and Printers Connection of Analytical Balances 7.1.1 Balance TZ-Number...
  • Page 81 All manuals and user guides at all-guides.com Chapter 7 – Connection of Analytical Balances and Printers 7.2 Balance data editor <F5/balance symbol >...
  • Page 82 All manuals and user guides at all-guides.com Chapter 7 – Connection of Analytical Balances and Printers 7.3 Connection of Printers ® Connection of Autosampler (only TitroLine 7000 7.4.1 Connection of sample changer TW alpha plus TZ 3087...
  • Page 83 All manuals and user guides at all-guides.com Chapter 7 – Connection of Analytical Balances and Printers 7.4.2 Connection of sample changer TW 7400 TZ 3987 ® 7.5 Using software TitriSoft (only TitroLine 7000) 7.5.1 General 7.5.2 TitriSoft 3.0 7.5.3 TitriSoft 2.75...

  • Page 84: Maintenance And Care Of The Titroline

    All manuals and user guides at all-guides.com Chapter 8 – Maintenance and Care ® 8 Maintenance and Care of the TitroLine 6000/7000 Heavy strain: Normal strain: Interrupted use...

  • Page 85: Storage And Transportation

    All manuals and user guides at all-guides.com Kapitel 8 Lagerung und Transport Kapitel 7 Wartung und Pflege des Titrators Kapitel 7 Wartung und Pflege des Titrators Chapter 9 – Storage and Transportation Please note: Storage and transportation 10 Recycling and Disposal Please note:...
  • Page 86 All manuals and user guides at all-guides.com Chapter 11 – Index 11 Index...
  • Page 87 All manuals and user guides at all-guides.com...
  • Page 88 All manuals and user guides at all-guides.com ® Typ / type / type / tipo TitroLine 6000/7000 Bescheinigung des Herstellers Supplier’s Certificate Certificat du fournisseur Certificado del fabricante SI Analytics GmbH...

This manual is also suitable for:

Si analytics titroline 7000
