- Page 1 HARMONY SERIES Usage and Care Manual Models: HBCC, and HBHC Your Partner in Cool.
-
Page 2: Product Diagram
PRODUCT DIAGRAM Fuse Hot water on/o switch if available Cold water temperature selector dial Water baffler Hot water tap if available Type 304 stainless steel seamless deep drawing body if available Drain valve Blow n body Power cord has a grounded plug TECHNICAL SPECIFICATIONS Cold Water Reservoir... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed to reduce the risk of fire, electric shock, and injury to persons or property. Read all instructions before using any appliance. Do not let hot water touch bare skin. Place the water dispenser away from direct Keep combustible material such as furniture, sunlight and make sure that there is at least 10... -
Page 4: Installation Procedure
UNPACKING THE WATER COOLER After unpacking the water cooler, wipe with a soft cloth. Place the machine on a hard, flat surface. Make certain the unit is level. The unit should not be close to direct sunlight or other sources of heat. It is best to place the water cooler in an area with good air circulation. -
Page 5: Troubleshooting
Main power supply is off. Re-establish main power supply. The unit does not dispense Damaged water dispenser. Contact Aqua Cooler service team. hot and cold water. The water bottle cap is not attached properly Connect properly. There will be a give when the to the connector on the water cooler. -
Page 6: Exploded Diagram
EXPLODED DIAGRAM Your Partner in Cool. -
Page 7: Spare Part List
SPARE PART LIST Description Code Description Code Nut of cold tank SPH1 Support frame 2 SPH16 Insulation foam of cold tank SPH2 Bottom panel SPH17 Handle SPH3 Support frame 1 SPH18 Condenser SPH4 Compressor SPH19 Support of electricity SPH5 Heat preservation sponge SPH20 Fuse SPH6... - Page 8 It excludes compressor relays, overloads and all other components of this appliance. This extended warranty does not include service, repair or labour costs or any pickup and/or freight charges. Aqua Cooler at its sole discretion may replace the cooler with a new or refurbished cooler of a similar age.
- Page 10 Your Partner in Cool. Phone Numbers Address Internet Sales: 1300 278 226 U14, 2-12 Knobel Court www.aquacooler.com.au Service: 1800 278 226 Shailer Park QLD 4128 info@aquacooler.com.au m0002 This document is available digitally on our website at www.aquacooler.com.au/doc/m0002...
