- Page 1 MAXIMUS SERIES Usage and Care Manual Models: XMCC, XMCCF Your Partner in Cool.
-
Page 2: Product Diagram
PRODUCT DIAGRAM 935mm 785mm 785mm 175mm 935mm 935mm 785mm 785mm 310mm 310mm 785mm 310mm 310mm 310mm TECHNICAL SPECIFICATIONS Water Reservoir Cold 14 L Housing Material Plastic with powder-coated steel side panels and corner peices. Refrigeration Uses R134A refrigerant 1/4” push-fit connectors Water Connections Water Inlet Thermostat Control... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed to reduce the risk of fire, electric shock and injury to persons or property. Read all instructions before using any appliance. Keep combustible material such as furniture, Do not use this product to dispense anything bedding, pillows, clothes and/or papers away other than water. -
Page 4: Installation Procedure
UNPACKING THE WATER COOLER After unpacking the water cooler, wipe with a soft cloth. Check the unit for evidence of rough handling. Place the machine on a hard, flat surface. Make certain the unit is level. The unit should not be close to sources of heat otherwise performance may be affected. -
Page 5: Troubleshooting
• Aqua Cooler recommends the water cooler is cleaned every 3 to 6 months. • Ensure there is no blockage in the condenser or in the back of the unit. • If customers require the unit’s spare parts information, please contact the Aqua Cooler Service Department for further assistance. -
Page 6: Exploded Diagram
EXPLODED DIAGRAM Your Partner in Cool. -
Page 7: Spare Part List
SPARE PART LIST Description Code Description Code Top cover SPMAX1 Cold water outlet lock nut SPMAX21 Gas filter cap SPMAX2 Gasket SPMAX22 Cold tank cover SPMAX3 Seal rings SPMAX23 Float switch SPMAX4 Temperature tube SPMAX24 Water baffle SPMAX5 Left sheet metal SPMAX25 Evaporator SPMAX6... - Page 8 It excludes compressor relays, overloads and all other components of this appliance. This extended warranty does not include service, repair or labour costs or any pickup and/or freight charges. Aqua Cooler at its sole discretion may replace the cooler with a new or refurbished cooler of a similar age.
- Page 9 MARKS Spec No. WMTS 105 SAI GLOBAL WMK26317 (Lic. No.) The appliance is comply with applicable ACMA regulatory arrangements (Regulatory Compliance Mark) and WaterMark WMTS 105.
- Page 11 Your Partner in Cool.
- Page 12 Your Partner in Cool. Phone Numbers Address Internet Sales: 1300 278 226 U14, 2-12 Knobel Court www.aquacooler.com.au Service: 1800 278 226 Shailer Park QLD 4128 info@aquacooler.com.au...
