- Page 1 MAXIMUS SERIES Usage and Care Manual Models: XMCC, XMCCF Your Partner in Cool.
-
Page 2: Product Diagram
PRODUCT DIAGRAM 935mm 785mm 310mm TECHNICAL SPECIFICATIONS Water Reservoir Cold 14 L Housing Material Plastic with stainless steel side panels and corner peices Refrigeration Uses R134A refrigerant 1/4” quick-connect tube fitting Water Connections Water Inlet Thermostat Control The thermostat is factory set Capacity Cold 6.5 L/h... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed to reduce the risk of fire, electric shock, and injury to persons or property. Read all instructions before using any appliance. Do not let hot water touch bare skin. Place the water dispenser away from direct Keep combustible material such as furniture, sunlight and make sure that there is at least 10... -
Page 4: Installation Procedure
UNPACKING THE WATER COOLER After unpacking the water cooler, wipe with a soft cloth. Place the machine on a hard, flat surface. Make certain the unit is level. The unit should not be close to direct sunlight or other sources of heat. It is best to place the water cooler in an area with good air circulation. -
Page 5: Troubleshooting
Over consumption of cold water in a short Wait for 15 minutes while the water cools and time. try again. System malfunction. Contact Aqua Cooler service team. The ventilation around the unit is insufficient. Ensure sufficient ventilation space around the unit. Unit does not dispense cold water. -
Page 6: Exploded Diagram
EXPLODED DIAGRAM Your Partner in Cool. -
Page 7: Spare Part List
SPARE PART LIST Description Code Description Code Bi-metal bracket SPN1 Wire condesner SPN32 Compbase SPN2 Staple SPN33 Base cold container SPN3 Cold water thermostat SPN34 Side panel (right) SPN4 Hot water switch SPN35 Cold water container SPN5 Cartridge fuse SPN36 Control panel SPN6 Fuse holder... - Page 8 Your Partner in Cool. Phone Numbers Address Internet Sales: 1300 278 226 U14, 2-12 Knobel Court www.aquacooler.com.au Service: 1800 278 226 Shailer Park QLD 4128 info@aquacooler.com.au m0003 This document is available digitally on our website at www.aquacooler.com.au/doc/m0003...
