V7 - LCD MONITOR SERIES
V7 D19W12A
19" Widescreen LCD Monitor
V7 LCD Monitors are designed for business, education, and home computing.
The V7 line of LCD Monitors range from 15" to 22" screens in both traditional 4x3
and the new 16x10 aspect ratio, wide display formats. Either way, the user can
be sure to enjoy bright, vivid images with fast screen response, high contrast
ratio, and wide viewing angles with long-life panels. Whether it is for desktop
publishing, web browsing, playing games, watching movies, or standard office
usage, V7 LCD monitors are the ideal choice.
V7 is a proven technology brand that blends quality and value, as well as
mandatory safety and environmental certifications, all in one package.
Specifications
Model Name
Panel Size
Aspect Ratio
Display Area
Maximum Resolution
Contrast Ratio
Response Time
Brightness
Viewing Angle
Colors
Horizontal Frequency
Vertical Frequency
Video Bandwidth
Signal Inputs
Power Consumption
Power Requirements
Features
Adjustment
Dimensions W x H x D
Monitor w/ Stand
Monitor w/ Packaging
Weight
Monitor
Monitor w/ Packaging
Wall Mountable
Included Materials
Certifications
Warranty
Container Load
The data in this publication is for illustration purposes only and does not necessarily represent standards or specifications which
must be met by V7. Design and specifications are subject to change without prior notice. Trademarks belong to their respective
owners. No responsibility assumed and all liability for damages resulting from use of this information or for any errors or omissions,
are disclaimed. Measurement standards and testing conditions, as per manufacturer definitions, are available on request.
08/25/08
D19W12A-N6
19" Widescreen
16:10
16.2" x 10.1" (410.4 x 256.5 mm)
1440x900
800:1
5ms
300 nits
150°H / 150°V
16.2M
30 – 80KHz
55 – 75KHz
135MHz
Analog VGA & DVI-D
45 watt max
AC 100 – 240V, 50 – 60Hz
Integrated Speakers (2x1W)
Auto set-up, Brightness, Contrast, Phase, H/V
position, Color, Sharpness, OSD position,
Language, Volume, Recall
17.2" x 14.7" x 7.5" (437.4 x 373.8 x 190.7 mm)
19.1" x 13.6" x 4.1" (486 x 345 x 104 mm)
9.3 lbs (4.2 kg)
10.6 lbs (4.8 kg)
VESA 100 x 100 mm
Quick Installation Guide, User Manual CD-ROM,
Power Cable, VGA Cable, Audio Cable
CE, TUV/GS, CSA, FCC, CCC, TCO'03, Energy
Star, RoHS Compliant
3 Years
40' ctn = 2880
www.V7-world.com
