SET UP TTS-20 PRO SET UP TTS-20 PRO

Adjustment of timing belt

Adjustment of timing belt
Side timing belt adjustment:
Lock the timing belt fixing screws on one side, pull the
timing belt tight on the other side and then lock the side
screws.
X-axis timing belt adjustment:
Check that the timing belt is hung on the X-axis motor

Adjust the focus

Laser Module
Fixed-thickness plate
Engraving material
06
wrench
Engraving/cutting height
Fixed-thickness plate

MACHINE WIRING

X-axis motor cable
Y1 motor X-axis limit cable
Y2 motor pair wiring Y-axis limit
(At the bottom)
After the wire is connected, please try to push the machine
to move and check whether the wire will interfere with the
movement of the machine.
EN
Y2 motor
Laser module wiring
07
