REFERENCE OF MATERIALS

For engraving ：
Material
Speed (mm/min)
Plywood
Acrylic
Leather
Electroplated coating
Powder coating
Anodic alumina
Stainless steel
Density board
pebble
Plastic board
Cardboard
For Cutting ：
Material Speed (mm/min)
Plywood 1mm
Plywood 2mm
Plywood 3mm
Plywood 4mm
Plywood 5mm
Plywood 6mm
Plywood 7-8mm
Acrylic 1mm
Acrylic 3mm
Acrylic 6mm
Note:
The energy value is set to 500, and the laser intensity accounts for 50% of the
power.
The energy value is set to 1000, and the proportion of laser intensity to power
is 100%. The larger the energy, the faster the speed can be set.
The above parameters only for reference. Due to the different properties of
the materials, please adjust the parameter values according to the actual
situations.
16
Power (%) Times
6000 50 1
6000 20 1
6000 20 1
1000 100 1
6000 50 1
6000 20 1
3000 100 1
6000 60 1
6000 100 1
6000 40 1
6000 50 1
Power (%) Times
600 100 1
450 100 1
280 100 1
200 100 1
150 100 1
100 100 1
100 100 1—2
500 100 1
200 100 1
100 100 1-2

TEST BEFORE USE

1.
Turn on the machine, and connect it to the computer.
2.
Movement test:
Control the machine to move up, down, left and right on the software, to
check whether the direction and distance are right.(Fig. A01)
3.
Laser emission test:
Software import custom icons, then click to sent out laser(weak laser). Wear
goggles and observe whether the laser module emits blue light.(Fig. A02)
4.
Test the files in the TF card:
Note: laser will generate heat and glare, which may cause harm. Please
follow the instructions to avoid injury.
（ ）
Fig. A01
Set the origin Low laser Strong laser Strong laser
Emit the laser Find edge on outline
1.
After the laser head has been used for a period of time, it is necessary to clean
the lens of the light outlet under the laser head to ensure normal cutting ability
2.
Wiping the lens must be done after the machine is powered off, otherwise
the laser will hurt people
3.
After wiping the lens, please dry it naturally for about 3-5 minutes and wait
for the lens to dry before powering it on, otherwise the light will cause the lens
to break
4.
You can watch the video tutorial by scanning the QR code of the manual
EN
（ ）
Fig. A02
