pagertec Wear and Go User Manual

Watch pager
Hide thumbs

Advertisement

Quick Links

Download this manual
1
Wear and Go Watch Pager
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the Wear and Go and is the answer not in the manual?

Questions and answers

Related Manuals for pagertec Wear and Go

Summary of Contents for pagertec Wear and Go

  • Page 1 Wear and Go Watch Pager USER MANUAL...
  • Page 2 THANK YOU FOR CHOOSING PAGERTEC Thank you for choosing Pagertec as your provider for your wireless paging requirements. We greatly appreciate your confidence in our products. At Pagertec our greatest commitment is providing you with total customer satisfaction. Please take a few minutes to review this manual prior to installing and operating your system.

  • Page 3: Installing The Transmitter

    INSTALLING THE TRANSMITTER The first consideration in the placement of the transmitter is convenience. It should be readily accessible in a central location within the paging area. Pay close attention to nearby obstructions such as walls, pipes, ducts, mirrored glass, or other similar barriers that may weaken or misdirect transmitted signals. Certain materials and construction, especially metal, have the potential to partially or completely block the paging signal.
  • Page 4 Transmitters HOSTESS TRX SERVER TRX NOTE: Your system may be pre-programmed into Regular Paging Mode, F1-F4 Mode, or Pre-Set Messages Mode depending on your request at the time of purchase. REGULAR PAGING MODE (with Hostess TRX): 1. Press the number of the pager you wish to call and press SEND. F1-F4 MODE (with Hostess TRX): 1.
  • Page 5 1. Powering ON and Entering Standby: To turn on pager, press and hold button 1, pager will beep. Once the pager turns on it will show software version, frequency, SN and then enter standby mode as shown in the picture below.
  • Page 6 3. Receiving Messages When your pager receives a new message it will display automatically as shown in the picture below. Delete or Delete All (Sub Menu) After reading the message press on button 4. This will allow you to open a sub menu which will give you the access to escape, delete the message &...
  • Page 7 Main Menu To enter the Main Menu press button and then use button or button to navigate the options you wish to modify. Press button to enter the selected option.
  • Page 8 5. Set Alert Mode Press button or button to scroll through options, and button to confirm your selection. 6. Different Alert Modes Audible Alert Vibrate Only Alert Beep + Vibrate Alert No Message Alert (Silent)
  • Page 9 7. Alert Time The Alert Time setting changes the duration you would like the watch to ring for EX: 1-99 seconds 8. Key Tone The Key Tone is a beep tone that would ring every time you click a side button. ON/OFF...
  • Page 10 9. Powering OFF Pager Use button to confirm you want to TURN OFF your pager. 10. Escape Main Menu Press button on escape to go back to the main menu, or press button to return to previous menu.
  • Page 11 11. Low Battery Indicator and Charging Instructions When your battery is low the battery icon on screen will show empty and the LED light will start flashing RED. Once the pager is connected to the charger a battery Icon will appear. Ensure that your watch is dry and there are no obstructions on the charging pins.
  • Page 12 Onyx Call Button(s) + Wear & Go Watch EASY PAIRING MANUAL...
  • Page 13 Pl!CERTEC 1. Enter Pair & Unpairing Menu Entering the Pair & Unpair menu from the main standby screen: Press and hold buttons together for a couple of seconds and a menu screen will appear as shown below.
  • Page 14 Pl!CERTEC 2. Pairing Select the "Pair Button" option by pressing button on the Wear & Go watch. After selecting the "Pair Button" option you will see the default screen on the Wear & Go watch as shown below.
  • Page 15 Pl!CERTEC Press the key on the Onyx Call Button that you wish to pair to the Wear & Go Watch. When the Wear & Go watch receives the signal from the call button it will show a 4 digit identifier number on the top left side of the display.
  • Page 16 The "Save As" will show the message programmed for the key. Depending on the settings requested when you ordered your equipment you might see different messages. For example, if you requested that key on the Onyx Call Button to have a message installed, then it will display that message on the Wear &...
  • Page 17 Unpairing All Buttons If you use the Unpair All Buttons feature it will remove and unpair all the Onyx call button keys or call buttons that are paired with the Wear & Go watch. Note: If you select this option, you will need to manually pair any call buttons you wish to receive messages from...
  • Page 18 Unpairing Unpairing is used when you wish to remove an Onyx Call Button key from calling a Wear & Go watch. This acts like a forget or disconnect function, in case you do not want the Wear & Go watch to receive a call from a specific Onyx Call Button Key. 1.

  • Page 19: Fcc Compliance And Advisory Statement

    FCC COMPLIANCE AND ADVISORY STATEMENT This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
