Echo DPB-5800T Operator's Manual

Backpack blower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operator's
DPB-5800T
This product contains chemicals known to the State of California
to cause cancer, birth defects, or other reproductive harm. Cancer
and Reproductive Harm www.P65Warnings.ca.gov
Read and understand all provided literature before use.
Failure to do so could result in serious injury.
Note: This product complies with CAN ICES-003(B) / NMB-003(B)
99922238094
© 05/2023 ECHO Incorporated
Manual
Backpack
Blower

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPB-5800T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Echo DPB-5800T

Summary of Contents for Echo DPB-5800T

  • Page 1 Cancer and Reproductive Harm www.P65Warnings.ca.gov Read and understand all provided literature before use. Failure to do so could result in serious injury. Note: This product complies with CAN ICES-003(B) / NMB-003(B) 99922238094 © 05/2023 ECHO Incorporated...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DPB-5800T TABLE OF CONTENTS Introduction.........................3 Servicing Information......................3 Parts / Serial Number....................3 Service........................4 ECHO Consumer Product Support................4 Product Registration....................4 Additional Literature....................4 Safety..........................5 For safe use of your product..................5 International Symbols ....................6 Read the Manual ......................6 Clear the Work Area ....................6 Keep a Firm Grip ......................7...

  • Page 3: Introduction

    Scan QR code for more information. For additional literature, including safety manuals where applicable, or questions regarding terms used in this manual, visit: https://www.echo-usa. com/manuals SERVICING INFORMATION Parts / Serial Number...

  • Page 4: Service

    Register your ECHO equipment online at www.echo-usa.com or by filling out the product registration sheet included in this manual. Registering your product confirms warranty coverage and provides a direct link to ECHO if we find it necessary to contact you.

  • Page 5: Safety

    Note: This enclosed message provides tips for use, care and maintenance of the unit. CIRCLE AND SLASH SYMBOL This symbol means the specific action shown is prohibited. Ignoring these prohibitions can result in serious or fatal injury. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 6: International Symbols

    15 m (50 ft.) radius; outside the 15 m (50 ft.) zone, there is still a risk of injury from thrown objects. Bystanders should be encouraged to wear eye protection. If you are approached, stop the unit . 99922238094 © 05/2023 ECHO Incorporated...

  • Page 7: Keep A Firm Grip

    Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. 99922238094 © 05/2023 ECHO Incorporated...
  • Page 8 Prevent unintentional starting. Ensure the switch is in the off position before connecting to power source and/or battery, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the switch on invites accidents. 99922238094 © 05/2023 ECHO Incorporated...
  • Page 9 • Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. 99922238094 © 05/2023 ECHO Incorporated...
  • Page 10 Battery Tool Use and Care ® • Recharge batteries only with ECHO eFORCE 56V battery series chargers. A charger that is suitable for one type of battery may create a risk of fire when used with another battery.

  • Page 11: Environmentally Safe Battery Disposal

    Environmentally Safe Battery Disposal ® 56V battery FOR FREE at Rechargeable Recycle your ECHO eFORCE Battery Recycling Corporation (RBRC) recycling locations. Call 1-800-822- 8837 or visit https://www.call2recycle.org for details. The toxic and corrosive materials below are in the batteries used in this machine: Lithium-Ion, a toxic material.
  • Page 12 DO NOT put these batteries in your regular household trash. • DO NOT incinerate. • DO NOT put them where they will become part of any waste landfill or municipal solid waste stream. • Take them to a certified recycling or disposal center. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 13: Fcc Statement

    ECHO Incorporated will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual. 99922238094...
  • Page 14 Moving parts might not be visible through openings. General Safety Warnings and Instructions for the following ECHO tool: Blower, Shred n Vac, or DPAS unit configured as Blower or Shred n Vac. This section contains the prescribed general safety warnings and instructions for motor-operated electric garden blowers, garden vacuums, and garden blower / vacuum combination contained in UL standards 62841-4-6.
  • Page 15 14. When clearing jammed material or servicing the machine, make sure the power switch is off and the power cord is disconnected. Unexpected actuation of the machine while clearing jammed material or servicing may increase the risk of personal injury. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 16: Description

    Locate the safety label(s) on your unit. Make sure the label(s) is legible and that you understand and follow the instructions on it. If a label cannot be read, a new one can be ordered from your ECHO dealer. Safety label is for example only. Your label my appear slightly different.

  • Page 17: Assembly

    DPB-5800T ASSEMBLY ASSEMBLY Installing the Wire Holder Clip and Hose Clamp Clip wires (7) into slot of both wire holder clips (8). Insert hose clamps (9) into wire holder clips. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 18: Installing The Trigger Handle

    (13) and loosely attach tightening knob (14). Attach swivel pipe to flex pipe. Tighten both hose clamps. Insert throttle cable into wire holder clips, and secure clips. Position trigger handle for comfortable operation and tighten knob. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 19: Installing The Blower Tubes

    Hold swivel pipe and turn main pipe clockwise, engaging positive locking channels, until connection is firm. Do not force connection. Assemble concentrator nozzle (16) to main pipe as in step 1. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 20: Recommended Ambient Temperature

    Charger Usage 39° F (4°C) - 104°F (40°C). Hot batteries in high ambient temperatures require longer charge times . To maximize battery life of batteries being stored more than 3 months, ECHO recommends batteries being stored at 3 green lights on the battery capacity indicator (BCI) and at room temperature.

  • Page 21: Battery Charging

    ASSEMBLY Battery Charging Note: See separate operator’s manuals packaged with battery and charger. ® • Use only with ECHO eFORCE 56V battery series batteries and chargers. • Keep charger and battery away from damp conditions and all liquids. • Do not operate the charger on an easily combustible surface (e.g. paper, textiles) or in an environment with a high risk of fire.
  • Page 22 Two green lights indicate that the battery has 25-54% charge. • Three green lights indicate that the battery has 55-79% charge. • Four green lights indicate that the battery has 80-100% charge. Unplug charger AC cord from the wall outlet. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 23: Installing And Removing The Batteries

    If the battery or charger is damaged, replace the battery or the charger. • Stop the machine and wait until the motor stops before you install or remove the battery. • Read and understand the instructions in the battery and charger manual. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 24: Removing The Batteries

    Remove batteries from the machine. Adjusting the Harness Fit the backpack on your back. Pull the ends of the straps down to tighten the harness. Connect the horizontal chest strap. Pull the end of the chest strap to tighten. 99922238094 © 05/2023 ECHO Incorporated...
  • Page 25 Lift the tabs of the adjusters to loosen the straps. Lock the quick-release fastener by pushing it together. Squeeze the hooks to open the quick-release fastener. Backpack should fit snugly on your back for comfort and safety 99922238094 © 05/2023 ECHO Incorporated...

  • Page 26: Operating Blower

    Additional speed may be necessary to clean grass and leaves from a lawn or flower bed. Higher speed may be necessary to move gravel, dirt, snow, bottles or cans from a driveway, street, parking lot or stadium. 99922238094 © 05/2023 ECHO Incorporated...
  • Page 27 Contacting blower pipe tip on abrasive surfaces can create sharp cutting edges and can result in personal injury if touched. Do not scrape or drag blower pipe tip when operating or transporting unit. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 28: Maintenance

    If you are unsure or are not equipped with the necessary tools, we recommend that you take your unit to a ECHO Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the Dealer do it, each maintenance task has been graded.

  • Page 29: Skill Levels

    Time intervals shown are maximum. Actual use and your experience will determine the frequency of required maintenance. If you continuously use vegetable based chain oil, inspect and do maintenance often. When you find anything wrong, ask your ECHO dealer for repair. 99922238094...

  • Page 30: Cleaning Battery And Battery Compartment

    Authorized ECHO Dealer The motor is defective. The air does not flow through the The air inlet or tube Remove the blockage. tube when you start outlet has a blockage. the machine. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 31: Storage

    If battery is stored for longer than six months, charge it to 100% capacity. Charger Remove battery from charger. Disconnect charger from power supply. Store in a dry, dust-free place, out of the reach of children. 99922238094 © 05/2023 ECHO Incorporated...

  • Page 32: Specifications

    Charger input voltage 120V AC 60Hz ® eFORCE Charger model ECHO 56V battery series charger Charge Time See Battery Operator's Manual *with (2) 5.0 Ah batteries in Turbo and without concentrator nozzle / **with concentrator nozzle 99922238094 © 05/2023 ECHO Incorporated...

  • Page 33: Product Registration

    If you do not have access to the Internet, you can complete the form below and mail to: ECHO Incorporated, Product Registration, PO Box 1139, Lake Zurich, IL 60047. 99922238094 © 05/2023 ECHO Incorporated...
  • Page 34 PRODUCT REGISTRATION DPB-5800T 99922238094 © 05/2023 ECHO Incorporated...

  • Page 35: Warranty

    ECHO dealer within the warranty period. The expense of delivering the product to the service center for warranty work and the expense of returning it back to the owner after repair or replacement will be paid by the owner. ECHO Incorporated’s, responsibility in respect to claims is limited to making the...
  • Page 36 ECHO Incorporated, does not assume or authorize anyone to assume for them any other obligation. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. ECHO Incorporated, assumes no responsibility for incidental, consequential, or other...
  • Page 37 DPB-5800T WARRANTY This warranty applies to all ECHO brand 56 Volt outdoor products manufactured by or for ECHO Incorporated, and sold in the United States and Canada. To locate your nearest authorized ECHO dealer, visit www.ECHO-usa.com or dial 1-800-432-ECHO (3246).
  • Page 38 NOTES DPB-5800T NOTES 99922238094 © 05/2023 ECHO Incorporated...
  • Page 39 DPB-5800T NOTES 99922238094 © 05/2023 ECHO Incorporated...
  • Page 40 430BPB000001 - 430BPB999999 431BPB000001 - 431BPB999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 www.echo-usa.com...
