Let's Get Started - modway EEI-6353 Assembly Instructions Manual

Let s get started!
Read through all of
the instructions
befor starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1
Leg front
2
Leg back
3
Side panel left
4
Side panel right
5
Back panel
6 Bottom panel
7
Front support
8 Drawer side panel right
9 Drawer side panel left
10 Drawer back panel left
Provided hardware:
Wood dowel Ø8 x 40mm
A
Cam lock Ø15mm
B
Cam bolt M6 x 40mm
C
Handle
D
Screw M4 x 37mm
E
Screw M4 x 16mm
F
Metal bracket
G
Pan head screw
H
M4 x 16mm
Drawer channel
I
(pre assembled)
Leveler (pre assembled)
J
Felt (pre assembled)
k
Missing parts or hardware? Need assistance?
Contact us before returning your items. We're here to help!
Wait!
609.256.9000 . cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x2 11
Drawer back panel right
x2 12
Drawer middle panel left
x1 13
Drawer middle panel right
x1 14
Drawer front
15 Drawer bottom panel
x1
x1
x1
x1
x1
x1
x28
x24
x24
x2
x4
x16
x4
x6
x2
x4
x4
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screw completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screw and bolts to avoid stripping the hardware or
cracking the item.
For vanity and plumbing installation, we suggest hiring a professional
contractor and plumber.
Assemble your item on a flat carpeted area, with plenty of space to work.
this will prevent damage and scratches to your floors or the item while
you're assembling the product.
Keep all components and packaging out of reach of children or animals
to avoid risk of choking or suffocation.
x1
x1
x1
2
x1
x1
14
9
10
What you need:
Phillips head screwdriver.
Phillips
5
7
3
1
6
8
13
12
You may also need:
+ Power Drill
+ Level
+ Silicone Adhesive or caulk
+ Drywall Anchors and Screws
+ Other Wall-Mounting Hardware
4
2
1
11
15
PAGE 2 OF 11
