- Page 1 SWARCO SW2224 Manual SW2224 LOOP DETECTOR WITH ASTRA-SWISS-SPECIFICATION SW2224_BE_10...
-
Page 2: Table Of Contents
Language service interface ................... 27 7.2.2 Baud rate data bus ......................27 7.2.3 Detector flags ......................... 27 7.2.4 LED turn-off time......................27 www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 2/39... - Page 3 Pin assignment service interface (DSUB 9-pole, plug) ............36 Dimensions ..........................36 Requirements for the usage according to regulations ............37 EC Conformity ........................38 www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 3/39...
-
Page 4: Introduction
1 Introduction In this chapter you will find preliminary remarks about the usage of the SW2224, as well as explanations about the structure of this manual and the usage of symbols. 1.1 About this manual On the following pages you will learn how to install and operate the device in an appropriate way. -
Page 5: Label
1.3 Label The SW2224 is provided with a quality label and serial number. You will need the indications when talking with the customer service, e. g. ordering accessories or spare parts. Note here the serial number and name of the device in order to have them available when... -
Page 6: Safety Instructions
Any violations will lead to the termination of conformity and the manufacturer’s warranty. The user will subsequently bear the risk. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 6/39... -
Page 7: Product Description
2 Product description General The SW2224 is a classification detector operating with two induction loops per lane according to ASTRA-SWISS-specifications. The SW2224 classifies the vehicles into the ASTRA-SWISS-classes SWISS10, SSSVZ vehicle classes or car-similar / HGV-similar). When using ASTRA-SWISS loops, the classification meets the definitions of ASTRA. - Page 8 The configured parameters are stored in a non-volatile memory (EEPROM). ATTENTION The loop detector SW2224 is solely designed for use by qualified personnel trained in dealing with traffic detection equipment. Improper use of the SW2224 may result in unpredictable behavior of the systems controlled by the detector.
-
Page 9: Overview Of The Essential Product Characteristics
Traffic data acquisition and vehicle classification with single loops for 4 lanes 1 Without speed and length measurement, no recognition of driving direction (not possible for CD9234) www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 9/39... -
Page 10: Installation Of The Sw2224
3 Installation of the SW2224 Installation and start-up of the unit The SW2224 is designed for installation in 19" racks with plug connectors according to DIN41612 (type F or C). Wire the racks according to the terminal assignment in the appendix. -
Page 11: Parameterizing The Traffic Data Acquisition
Detection of wrong way drivers, directional logic (only if necessary): see chapter 7.1.5 • Length correction (only if necessary): see chapter 7.1.4 • www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 11/39... - Page 12 (see chapter 6.3). An exact evaluation of speeds can only be done by means of a calibrated speed reference (e.g. laser / radar gun). www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 12/39...
-
Page 13: Operating The Sw2224 With Loopmaster
4 Operating the SW2224 with LoopMaster General The SW2224 is operated via service interface on the front by means of the LoopMaster operating program installed on a PC or laptop computer. The detector is connected directly with the COM port of the PC or alternatively via USB port and standard COM-USB adapter. - Page 14 LC22: 2 loop systems with 2 double loops each Opposite to detectors for traffic light systems, the SW2224 is normally used as double loop detector, i.e. in order to function a loop system with 2 inductive loops arranged successively is necessary.
-
Page 15: Display And Operating Elements At The Front Panel
The reception and transmission processes of the RS485 data bus interface are indicated at the RXD and TXD LEDs for the reception and transmission direction of the SW2224 . The FCT LED flashes with a frequency of 1 Hz during normal operation of the detector. With activation of MASTER-SLAVE synchronization, the flashing frequency during normal operation is reduced to 0.5 Hz. - Page 16 In the standard Version of the des SW2224 (2 double loop systems K1 / K2 and K3 / K4), the parameter frequency range can additionally be adjusted at the DIP switch on the front. For most applications this is the only adjustment to be made and there are no further adjustments necessary e.g.
-
Page 17: Alignment And Error Diagnosis
There must be no extended vehicle passages during the alignment. If a convoy of vehicles passes during alignment, the SW2224 attempts to adjust to the gaps between the vehicles. There are no vehicle detections possible during the alignment. After the alignment, the channel is always in an "undetected"... - Page 18 After troubleshooting, an alignment of all channels or a reset of the SW2224 with subsequent alignment of all channels can be initiated using the pushbutton on the front panel in order to restore correct functionality.
-
Page 19: Automatic Calibration And Control Of Vehicle Detection
Automatic calibration and control of vehicle detection The SW2224 is delivered with standard parameter values optimized for the permitted loop and feeder cable configurations. In order to further optimize the single vehicle detection, important characteristic values e.g. norm value and switch-on threshold resp. sensitivity for the connected loop / feeder cable configuration are permanently and automatically evaluated and stored non-volatile in the EEPROM. - Page 20 3 this is 1.45 % and 1.55 % as norm values of the two loops. Further reasons for bigger differences are different installation depths, number of windings or loop dimensions. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 20/39...
-
Page 21: Parameters And Functionality
• are settings which apply to the entire device (refer to section 7.2) In addition to the user-adjustable parameters, the SW2224 also provides diagnostic data, which can be displayed in the LoopMaster. These values cannot be directly modified but result from the parameters (e.g. frequency from configured frequency range), are determined during operation (e.g. - Page 22 (see also chapter 6.2). The oscillator of the SW2224 is designed in such way that, when using loops with inductan- ces within the recommended range, all frequency ranges can be used (see chapter 8.1).
- Page 23 “frequency not adjustable“ in the LoopMaster and shown at the ERR LED and by the channel LED blinking three times. The problem can be solved by reducing the frequency level. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 23/39...
-
Page 24: Loop Type And Loop Distance
7.1.3 Loop type and loop distance The parameter loop type is of great importance for the classification. The SW2224 uses separate classification algorithms for each loop type resp. loop length because identical vehicles generate different vehicle patterns with different loop lengths. Thus, for each loop length a separate vehicle pattern database is used in order to reach a very high classification accuracy. -
Page 25: Detection Of Wrong Way Drivers
(e.g. classification and speed measurement). Therefore, the sensitivity cannot be changed. The SW2224 has an automatic sensitivity adjustment and very short measurement times in order to ensure optimum single vehicle detection also at high speeds. -
Page 26: Hold Time
This function is deactivated with the value 0. On activating the function "Automatic alignment case of error", a new alignment attempt is cyclically (1 min) initiated. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 26/39... -
Page 27: Noise Threshold
After the LED turn-off time has elapsed, the LEDs are switched off. Briefly pressing the pushbutton or communicating via the service interface reactivates the LEDs. The value 0 deactivates the turn-off function. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 27/39... -
Page 28: Significance Of The Channel Diagnostic Values
The extended channel flags are a supplement to the channels flags described in chapter 7.1.9. At the moment there are no adjustable flags defined for the SW2224, therefore, these flags are diagnosis value and cannot be changed. In the standard version of the SW2224 (double loop system), this configuration is displayed as “Double loop function (v, l , dir.): On“... -
Page 29: Inductance
Due to the exceeded hold time, an alignment was performed for the channel and the counter for hold time exceedance was increased. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 29/39... -
Page 30: Significance Of The Device Diagnostic Values
This diagnosis value indicates the positions of the DIP-switches provided at the front panel. For further information about the function of the switches see chapter 5. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 30/39... -
Page 31: Reset Counter, Reset Cause
The MASTER-SLAVE function is a device parameter and is to be found in the corresponding LoopMaster parameter window. The setting is transmitted to the detector by the command "Write to device..." and by selecting a channel. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 31/39... -
Page 32: Notes Concerning The Data Bus Function
With lower baud rates (e.g. in default setting 9600 baud) and with short data bus lengths (e.g. within a rack), usually no termination is necessary. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 32/39... -
Page 33: Appendix
At installation: > 1GΩ (without feeder cable) During operation: Values as low as approx. 1 MΩ are permitted, value must be constant www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 33/39... -
Page 34: Technical Data Of Switching Outputs
Not potential free potential free 2 This is only an overvoltage protection! Additional measures (coarse protection) must be provided! (see chapter 3.2) www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 34/39... -
Page 35: Pin Assignment Multipoint Connector (Din41612 Type F And C)
Synchronization 1 resp. 2: Only direct connection to pins Synchronization 1 resp. 2 of further identical detector types is permitted. No additional wiring permitted. Maximum length approx. 1 m. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 35/39... -
Page 36: Pin Assignment Service Interface (Dsub 9-Pole, Plug)
Dimensions 4 / 8 TE 174 mm SW2224 CH1 2 3 4 RS232 Measurements are subject to manufacturer’s tolerances www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 36/39... -
Page 37: Requirements For The Usage According To Regulations
For the installation of the inductive loops the regulations of and the documentation ASTRA “Loop Installation TLS” by SWARCO TRAFFIC SYSTEMS GMBH apply. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 37/39... -
Page 38: Ec Conformity
EC Conformity www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 38/39... - Page 39 Niederkircher Straße 16 D-54294 Trier www.swarco.com/sts © 2023 Alle Rechte vorbehalten Thank you for choosing a SWARCO TRAFFIC SYSTEMS GMBH quality product. www.swarco.com SWARCO TRAFFIC SYSTEMS GMBH, Niederkircher Straße 16, D-54294 Trier, Germany T. +49-651-81002-0, F. +49-651-81002-999, E. detection@swarco.de 39/39...
