- Page 1 OPERATOR´S MANUAL SP501BP 5 Gallon Backpack Manual Sprayer SERIAL NUMBER 509MS0000001 - 509MS9999999 Cancer and Reproductive Harm www.P65Warnings.ca.gov Read and understand all provided literature before use. Failure to do so could result in seriouly injury. 99922205760 © 09/2022 ECHO Incorporated...
- Page 2 INDEX SP501BP INDEX Introduction……………......3 Operation……………...... 9 Safety information………...... 4, 5 Maintenance……………....9 2.1 Personal protective equipment 5.1 Maintenance guide 2.2 Safety Instructions Troubleshooting guide……………. 10 General Information…………....7 Product Registration….....11,12 3.1 Main components Warranty.......... 13 3.2 Technical data 3.3 Chemical compatibility 3.4 Assembly...
- Page 3 Servicing Information Parts / Serial Number Genuine Shindaiwa Parts and Assemblies for you Shindaiwa products are available only from an Authorized Shindaiwa Dealer. When you do need to buy parts always have the Model Number and Serial Number of the unit with you.
- Page 4 SAFETY INFORMATION SP501BP 2. SAFETY INFORMATION Manual Safety Symbols and Important Information Throughout this manual and the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. The following and explanation of those symbols and key words and what they mean to you.
-
Page 5: Safety Information
SAFETY INFORMATION SP501BP 2.1 PROTECTION EQUIPMENT -Industrial gloves -Safety glasses -Closed toe footwear -Coverall -Safety mask • Read this manual carefully before operating the equipment. • Incorrect handling by unqualified persons may cause serious accidents. • Do not make modifications or adaptations because they can compromise your equipment and put your safety and that of a third party at risk. -
Page 6: Safety Instructions
SAFETY INFORMATION SP501BP SAFETY INSTRUCTIONS WARNING DANGER Carrefully read and understand the Operator’s Manual supplied with this unit priror to filling, using and/or cleaning this sprayer. DO NOT use flammable liquids in the sprayer. They can ignite and explode. Always wear splash goggles and all required protective gear and clothing when filling, using, cleaning, or performing maintenance on the sprayer failure to follow all instructions can result in fire, explosion, and serious injury. -
Page 7: General Information
GENERAL INFORMATION SP501BP • Do not drop a tank that has been pressurized. If tank is dropped, inspect immediately. Consult chemical manufacturer’s instructions for other important safety information. • Never attempt to pressurize the unit by any other method than with the pump module provided. Never over-pressurize the unit. -
Page 8: Chemical Compatibility
GENERAL INFORMATION SP501BP 3.3 CHEMICAL COMPATIBILITY CHEMICAL/SOLVENT SP501BP CHEMICAL/SOLVENT SP501BP Acetone Lacquer Solvents Asphalt Latex Paint Benzene Methyl ethyl ketone Bleach Solution up to 15% Naptha Boric Acid Ridomill Round Up Denatured Alcohol Diesel Fuel Sulfuric Acid Enamel Paint Toluene... -
Page 9: Operation And Maintenance
To ensure good performance use original Place the sprayer on your back and pressurize tank by pumping approximately 25 times. “Shindaiwa” replacement parts You will need to pump once each 3 or 4 seconds to maintain the desired spraying pressure. -
Page 10: Troubleshooting Guide
TROUBLESHOOTING GUIDE SP501BP 5.1 MAINTENANCE GUIDE Below are instructions for maintaining your sprayer: Rinse with clean water externally and internally, to avoid risk of contamination. To keep your sprayer in good condition it is recommended to change the following parts when servicing your sprayer:... -
Page 11: Product Registration
Thank you for choosing Shindaiwa Equipment Please go to http://www.shindaiwa-usa.com to register your new product on-line. It’s FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Incorporated. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration. - Page 12 PRODUCT REGISTRATION SP501BP 99922205760 © 09/2022 ECHO Incorporated...
-
Page 13: Warranty
ECHO INCORPORATED'S RESPONSIBILITY ECHO Incorporated’s Limited Warranty, provides to the original purchaser that this ECHO or Shindaiwa product is free from defects in material and workmanship. Under normal use and maintenance from date of purchase, ECHO Incorporated agrees to repair or replace at ECHO Incorporated's discretion, any defective product free of charge at any authorized ECHO or Shindaiwa servicing dealer (as applicable) within listed below application time periods, limitations and exclusions. - Page 14 Standards. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD compliant and JASO M345FD registered oil, will void the two-stroke engine limited warranty. ECHO and Shindaiwa branded oils meet the ISO-L-EGD and JASO M345FD Standard. Emission related parts are covered for 5 years homeowner use or 2 years commercial use regardless of two-stroke oil used, per the statement listed in the EPA or California Emission Defect Warranty Explanation.
-
Page 15: Disclaimer Of Implied Warranties
It is a dealer’s and/or customer’s responsibility to complete and return the warranty registration card supplied with your product or by visiting www.echo-usa.com or www. shindaiwa-usa.com. Your receipt of purchase including date, model and serial number must be maintained and presented to an authorized servicing dealer for warranty service. - Page 16 509MS0000001 - 509MS9999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 www.echo-usa.com 09/2022-V02...
