- Page 1 Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye protection, gloves and a respirator when operating this unit. SHINDAIWA OWNER’S/OPERATOR’S MANUAL SP415 BACK PACK SPRAYER Part Number 80836 Rev. 1/04...
-
Page 2: Specifications
Introduction This manual contains information for the proper assembly, operation and care of your SP415 sprayer. Carefully read and follow the instructions contained in this manual before operat- ing your sprayer. Pump Chamber Packing Ring Lever Wand Nozzle LOCATED ON THE BOTTOM Specifications Net Weight ... -
Page 3: Assembling The Spray Wand
Assembling the Spray Wand Wand Screw Push the wand into the trigger valve and secure with screw cap. Hand tighten to prevent leakage. CAUTION! Do not overtighten! Adjusting the Shoulder Straps Tightening 1. Place the sprayer on your back with the staps loosened. -
Page 4: Safety Precautions
Safety Precautions Carefully read the labels on chemical containers prior to use. Chemicals are classified in four categories of toxicity: ■ Category I, High Toxicity, Red label ■ Category II, Moderate Toxicity, Yellow label ■ Category III, Low Toxicity, Blue label ■... -
Page 5: Optional Accessories
761882 Spray hood is used for nonselec- tive herbicides when spraying under windy conditions. Comes with Kematal 110-DEF-06 deflector fan nozzle and parts to assemble spray hood to your existing Shindaiwa spray wand. 902296 Brass spray boom (27.5") for use with agrochemicals and foliar fertilizers applied to row crops. -
Page 6: Maintenance
Maintenance Cleaning the Sprayer After finishing the spray application, empty the sprayer and wash all equipment in an approved decontamination area. Pump the lever with the trigger valve disconnected until the discharge runs clear WARNING! Remove all chemicals and wash before storing the sprayer. - Page 7 Owner’s Responsibilities The owner of the sprayer must demonstrate reasonable care in the use, maintenance, and storage of this Shindaiwa product. If a warrantable failure should occur, the owner must deliver the product to an authorized Shindaiwa servicing dealer for correction.
- Page 8 Illustrated Parts List (SP415) After s/n 198698C4...
- Page 9 Illustrated Parts List (SP415) Part Number ItemDescription 568774 Spray Wand Assembly 568782 Trigger Valve Assembly 909192 Trigger Valve Handle 920470 Hose Ferrule 909283 Trigger Valve Body 105239 Trigger Valve Needle Assembly 568972 Trigger 996058 Valve Cap 568873 Wand Tube/Elbow Assembly 909309 Cone Packing 915744...
- Page 10 Illustrated Parts List (SP415) Before s/n 198697L3 Item Part No. Description 214486 Pumping Rod Ass’y 925800 Spray Wand Holder Set 942136 Chamber Cover 120303 Gasket Holder 552703 Gasket 120055 Ring ORI-36 942235 Chamber Body 568717 Strap Assembly (includes Items 10 and 15) 214619 Agitator 568725...
- Page 11 NOTES:...
- Page 12 Shindaiwa Inc. 11975 S.W. Herman Road Tualatin, Oregon 97062 Telephone: 503 692-3070 Fax: 503 692-6696 www.shindaiwa.com 2004 Shindaiwa, Inc. Part Number 80836 Revision 2/04 Shindaiwa is a registered trademark of Shindaiwa, Inc. Specifications subject to change without notice. Printed in Brazil...
