SHINDAIWA OWNER'S/OPERATOR'S MANUAL
SP518 BACK PACK SPRAYER
WARNING!
Minimize the risk of injury to
yourself and others! Read this
manual and familiarize yourself with
the contents. Always wear eye
protection, gloves and a respirator
when operating this unit.
Part Number 80702 Rev. 4/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 80702 and is the answer not in the manual?

Questions and answers

Related Manuals for Shindaiwa 80702

Summary of Contents for Shindaiwa 80702

  • Page 1 SP518 BACK PACK SPRAYER WARNING! Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye protection, gloves and a respirator when operating this unit. Part Number 80702 Rev. 4/02...

  • Page 2: Specifications

    Introduction Prepare to Assemble Unpack the following This manual contains information for the proper assembly, operation and care of your SP518 sprayer. Carefully read and items shipped in your sprayer box: follow the instructions contained in this manual before operat- ing your sprayer.
  • Page 3 Owner’s Responsibilities The owner of the sprayer must demonstrate reasonable care in the use, maintenance, and storage of this Shindaiwa product. If a warrantable failure should occur, the owner must deliver the product to an authorized Shindaiwa servicing dealer for correction.
  • Page 4 Changing Lever Operating Side NOTE: The operating lever may be mounted on the left or right side of the sprayer tank depending on operator preference. Hitch Pin Washer Pump Chamber Connecting Agitator Shaft Retainer Pump Lever Shaft Washer Tank Base Shoulder Strap Hitch Pin...

  • Page 5: Safety Precautions

    Illustrated Parts List (SP518) Safety Precautions WATER EARTH Calibrating the Sprayer (Requires optional flow calibrator bottle, P/N 646901) Carefully read the labels on chemical containers prior to use. Chemicals are classified in four 1. Hold the wand at categories of toxicity: the working ■...

  • Page 6: Optional Accessories

    0.17 gpm @ 45 psi. 325787 Blue 0.18 gpm @ 45 psi. * Denotes nozzles included in the SP518 Note: All Shindaiwa sprayers come with the red adjustable standard repair kit. cone nozzle P/N 015024 installed as standard equipment. Maintenance Cleaning the Sprayer...
