4.5. Relay OutputPositions(out)
Out1 and out2 menus allow positions of the relays. The relay is inactive at Nclose option, active while
reached set point. And also yhe delay is active at Nopen option; it will be inactive while reached set point.
4.6. EnteringConstantValue (const)
Provides accurate display of sensorswith different resolutionsby entering the multiplier value.
By way of example, 0,025 constant value is entered to Const Menu for the 25 micron-sensor or 0,005
constant value for 5 micron-sensor. So when sensor moves 100mm, value of 100 is displayed on the
screen.
In order to set to ContsMenu, pressed to prg button while operating mode and oundto ConstMenu with
using up-down button. When pressed to prg button (While being cons menu), the right-hand digit of
bottom row flashes. Set to wanted value with up-downbutton. Digitmovesto the left while pressedto prg
button. Then pressed to prg button again, this digit flashes. Digit position is set with up-downbutton. You
press again prg button, the digit is continuously flashing. Therefore the constant value is entered in. If you
want to exit without saving,you can backto operating modewith rst button.
.
4.7. Selection OfPoint Position(Point)
Resolution of the value shown on the display is set here. This changeis done by changingposition of the
point on the screen. In order to changed position of the point, pressed to prg button at operating mode
and found point menu with up-downbutton. The point is flashing when pressed to prg button; you can set
position of the point with up-downbutton. Then you can save them with prg button. Return to operating
modewith rst button.
j .j j j j
PRG
. j j j j j j
j j j
j j j
j j j j j j
j .j
PRG
j j .j
j .j
PRG
j j .j
j j j j j
j j j j j
j j j j j
j j j j j
j j j j j
j .j j j
j j j j j
j .j j j
