4. DEVICEPROGRAMMING
to the menu and ChangingParameters:
Enter
For switch to programmingmode while device operating mode push( ) button. Firstly "j j j j j j "smenu
will appear on the screen.
j .j j j j j
j j .j j j .j
Switch between programmenuswith Down ( ) and up( ) buttons. PRG button is entered into for
the menuto be changed.Changesare saved with prg( ) button. Return to operating mode with rst ( )
button. If password protection is activated at device, password must be entered. If password is correct,
true messageis displayedonthe bottom line. Also passwordis incorrect, "false" is displayed.
j j j j j j j
j j j j j j j
j j j j j j j
j j j j
PRG
j j j j j
j j j j
j j .j j j j
If Password iscorrect :
If Password isincorrect:
"true".
"false"
4.1. EnteringTheSet Point to Device(Set)
Menu is displayed firstly on the screen as prg button is pressed while operating mode. Menu of Set 2 is
displayed while down button is pressed. The top row shows the name of the menu and bottom row also
(yellow marked) selected value in menucontent. Set 1, set 2allows controlling to out1 andout2 relays.
Move to the desired set point for setting. The rightmost digit starts flashing when prg button is pressed.
Desired point is selected up and down button. Used to prgbutton for Digitsscrolling. Shifted to the left for
one step when each press of the button, If pres the prg button when comingthe rightmost digits, positive
or negative value will be asked.Value is selected by up and down button then saved with prgbutton. If you
do not want to save, you can exitwith esc button.
j .j j j j j j j j j
PRG
j j .j j j .j j j .j
