Atek ALC 77-C User Manual page 16

Out 08
Out 09
Out 10
While count value is below level of Set-1,Out-1is active and then Out-1
is inactive when on top of it. Out-2is active when on top of SET-2value
and OUT-2isinactive after reaching below the SET-2value. Countvalue
and outswill be reset when comesRESET.
At this mode, TOUT-2shouldbe selected as term. OUT-1is active
duringTOUT-1periodat count value exceedsthe each value of the
SET-1and OUT-1is inactive at the end of TOUT-2period. Count value
and outswill be reset when comesRESET.
TOUTtimes should be selected as HOLD. OUT-1is active until count
value reaches the value of the SET-2and OUT-2isinactive when
reaches. OUT-2isactive until count value reaches the value of the SET-
1 and OUT-1isinactive when reaches.
-1 4 -
