4.8. EnteringOffsetValue (offset)
Offset value can be entered usingthis menu to device. Returned to entered offset value when pressed to
rst button or signalcomesfrom Zinput. If offset value is zeroand reset button is pressed,zerowill write on
the screen. Found offset menu with up-downbutton and pressed to prg button then bottom row choice
flashes. Set to value with up-downbutton and each press of the button moves to the left in a digit. Then
you can save them.
4.9. ResetWith Button (rstbtn)
Thismenu allows becomingactive RST button on the front panel. While RST button is active, the value of
the on-screenwill be reset when pressed up-downbutton for two times at operating mode or return to
offset value. In order to open RST button, pressed to prg button at operating mode. Found Tot rst menu
with up-downbutton and pressed to prg button then one of reset/no reset choice at bottom row flashes.
Change to option with up-downbutton and save choice with prg button then return to operation mode
with rst button
.
4.10. ResetWith External ZSignal(rst inpt)
Resetting at device screen can be done with by applied from outside external an encoder Z signal or a
switch when external Z input is be activated. While you make active the Z input, select the edge you will
make reset on. You can select one of rising and falling edges. If you donʼt want to use Z input, select to
noreset option. In order to activate to Z input, pressed to prg button at operating mode and found rst inpt
menu with up-downbutton.
down button. Thensave it by prgbutton.
j .j
.
j j j
j .j
.
j j j
When prg button is pressed, options will flash
j .j
PRG
.
j j j
-8-
j j j j j j
.
j j j j
j j j j j j
j j j j j
and made the selection with up-
