1 Overview
Name No.
IO0 12
IO1 13
NC 15
IO10 16
NC 17
IO4 18
IO5 19
IO6 20
IO7 21
IO8 22
IO9 23
NC 24
NC 25
IO18 26
IO19 27
NC 28
NC 29
RXD0 30
TXD0 31
NC 32
NC 33
NC 34
NC 35
Espressif Systems
Table 2 – cont'd from previous page
Type Function
I/O/T GPIO0, ADC1_CH0, XTAL_32K_P
I/O/T GPIO1, ADC1_CH1, XTAL_32K_N
— NC
I/O/T GPIO10, FSPICS0
— NC
I/O/T GPIO4, ADC1_CH4, FSPIHD, MTMS
I/O/T GPIO5, ADC2_CH0, FSPIWP, MTDI
I/O/T GPIO6, FSPICLK, MTCK
I/O/T GPIO7, FSPID, MTDO
I/O/T GPIO8
I/O/T GPIO9
— NC
— NC
I/O/T GPIO18
I/O/T GPIO19
— NC
— NC
I/O/T GPIO20, U0RXD,
I/O/T GPIO21, U0TXD
— NC
— NC
— NC
— NC
