Assembly Instructions
& User's Manual
Rustic Outdoor Fireplace
Item#: 175273
Model#: SRLF370AB
Please keep this instruction manual for future reference
Warning:
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR
OPERATE THIS PRODUCT.
Adult assembly required.
Keep screws and parts out of reach of children.
Customer Service: (888) 909-3888, 7:30am to 4:30pm,
Monday thru Friday Pacific Standard Time
--------------------------------------OR-------------------------------------
Customer Service: (888) 922-2336 7:00 am to 12:00 am CST (daily)
Live Chat at: www.academy.com
Email: customerservice@academy.com
(Made in China)
Advertisement
Related Manuals for Mosaic SRLF370AB
Summary of Contents for Mosaic SRLF370AB
- Page 1 Assembly Instructions & User's Manual Rustic Outdoor Fireplace Item#: 175273 Model#: SRLF370AB Please keep this instruction manual for future reference Warning: READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Adult assembly required. Keep screws and parts out of reach of children.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ................1 Warnings..................2 Parts and Hardware ................ 4 Assembly Instructions ..............Product Use or Instructions ..............9 Care and Maintenance............... Warranty Information................. REMINDER BEFORE ASSEMBLY Verify that all parts are included with your fireplace BEFORE you begin assembly by checking the Parts and Hardware List. -
Page 3: Warnings
Warnings WARNING For Outdoor Use Only (outside any enclosure) WARNING 1. Improper installation, adjustment, alteration, service, or maintenance may result in property damage, injury or death. 2. Read the installation, operation, maintenance instructions thoroughly before installing or servicing this equipment. 3. - Page 4 Warnings 14. DO NOT store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance. 15. DO NOT store or use an LP gas cylinder within 10 feet (3.05 m) of this fireplace while it is in operation. 16.
-
Page 5: Parts And Hardware
Parts and Hardware TOOLS REQUIRED (Not included): Phillips screwdriver Page 4 of 10... - Page 6 Parts List Part # Description Picture Top Lid Side Panel Front Panel Back Panel Log Rack Fire Bowl Base Fire Hook Hardware Picture Hardware # Description M6 x12 Screw M6 Nut Page 5 of 10...
-
Page 7: Assembly Instructions
Assembly Instructions NOTE: Assemble the fireplace on a non-abrasive, level surface. If missing parts please contact customer service. Step 1 Attach the top lid (A) to the top (B) with (4) M6 x 12 screws (AA) as illustrated. Hardware Used M6 x 12 Screw Step 2 Attach two side panels (C) to the front... - Page 8 Assembly Instructions Step 3 Place the top assembly upside down, then attach the panel assembly to the top assembly with (4) M6 x 12 screws (AA) as illustrated. Hardware Used M6 x 12 Screw Step 4 Place the top and panel assembly upright, then attach it to the base (H) with (8) M6 x 12 screws (AA) and (8) M6 nuts (BB) as illustrated.
- Page 9 Assembly Instructions Step 5 Assembly completed. Page 8 of 10...
-
Page 10: Product Use Or Instructions
Product Use or Instructions Lighting 1. Make sure there is only a small amount of ash in the bottom of the bowl. 2. Place a layer of dry kindling or a natural fire-starter onto the center of the charcoal grid. 3. -
Page 11: Warranty Information
Warranty Information The appliance has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one year (1) from the date of purchase. A replacement for any defective part will be supplied free of charge for installation by the consumer.
