28" Wolfgang Fire pit
FSMVPT6026
Please keep this instruction manual for future reference
Customer Service: (888) 922-2336
7:00 am to 12:00 am CST (daily)
Live Chat at: www.academy.com
Email: customerservice@academy.com
----------------------OR--------------------
Customer Service: 855-600-9294
9:00 am to 5:00pm EST Monday-Friday
Email: customercare@china-yayi.com
(Made in China)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mosaic Wolfgang FSMVPT6026
Summary of Contents for Mosaic Wolfgang FSMVPT6026
- Page 1 AA PD 3/22/17 Assembly Instructions & User’s Manual 28" Wolfgang Fire pit FSMVPT6026 Please keep this instruction manual for future reference Customer Service: (888) 922-2336 7:00 am to 12:00 am CST (daily) Live Chat at: www.academy.com Email: customerservice@academy.com ----------------------OR-------------------- Customer Service: 855-600-9294 9:00 am to 5:00pm EST Monday-Friday Email: customercare@china-yayi.com (Made in China)
- Page 2 Table of Contents Warnings………………………………………………………………..…2 Tools and Parts…………………………………………………………...2 Assembly Instructions…………………………………………………..3 Care and Maintenance……………………………………………...……5 Warranty Information………………………………………....5 Note: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list and hardware contents. If any part is missing or damaged do not attempt to assemble the unit.
- Page 3 Warnings WARNING For Outdoor Use Only. Wear gloves during assembly WARNING Improper installation, adjustment, alteration or maintenance may result in property damage or injury. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury or death.
- Page 4 Warnings Do NOT use this fire pit near automobiles, trucks, vans or recreational vehicles. Do NOT use in an explosive atmosphere. Keep outdoor area clean and free from combustible materials, gasoline and other flammable liquids. Do NOT use this fire pit under and overhead or near any unprotected combustible constructions.
- Page 5 Tools Required (Not Included) Phillips screwdriver Adjustable open end wrench Parts List Lift Handle Mesh Screen Wood Grate Fire Bowl Connection Ring Stand Fire Poker Hardware M6 Nut M6 x 15 Bolt M6 x 10 Bolt Page 4 of 8...
- Page 6 Assembly Instructions Step 1: Connect the lift handle (A) to the mesh screen (B), using one M6 nut (AA). Step 2: Connect the stand (F) to the fire bowl (D), using eight M6 bolts (BB) and M6 nuts (AA) . Do not tight the bolt at this step.
- Page 7 Assembly Instructions Step 3: Connect the connection ring (E) to the stands (F), using M6 bolts (CC). Tight all bolts after each bolt in right holes. Step 4: Place the wood grate (C ) and mesh screen (B) on the fire bowl. Place the fire poker (G) near the fire pit.
- Page 8 Care and Maintenance Lighting 1. Make sure there is only a small amount of ash in the bottom of the bowl. 2. Place a layer of dry kindling or a natural fire-starter onto the center of the grate. 3. Place above that a layer of dry seasoned hardwood that is put to lengths no more than 3/4 the diameter of the bowl.
- Page 9 Warranty Information This product has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one year from the date of purchase. A replacement for any defective part will be supplied free of charge for installation by the consumer.
