Parts Guide

Quantity
1
1
4
1
6
Red P LED lights when
OWER
the MRF-100 power supply is
plugged into an active AC
outlet.
The Mounting Plate guides
enable the MRF-100 match-
ing guide to slide and "snap"
into place for mounting on
the wall.
Using the four enclosed screws, you
can choose to fix the mounting plate
to a wall or the back of your compo-
nent cabinet.
Description
MRF-100 Receiver with integrated antenna
Mounting Plate for wall mounting the MRF-100
Screws for wall mounting the mounting plate
9V-300mA Power Supply
Flashers with 10 foot plug in cables.
The MRF-100 Mounting Plate
Red S LED lights when the
TATUS
MRF-100 receives an RF signal
from the Unifier, Automator or
Customizer remote controls.
Front blaster sends Infrared
commands to all A/V compo-
nents in the same cabinet
space.
