- Page 1 JURALCO FELICIA AWNING SYSTEM Issue 10-23 v2 Juralco Felicia Awning System ISSUE 10-23 v2 www.juralco.co.nz ph (09) 478 8018...
- Page 2 General Description - The Juralco Felicia Awning system is available as a single unit up to 5.9mt wide, with a max 3.5mt awning extension. - Typical applications include Decks, Bars, Shops, Terraces, or anywhere needing protection from the sun, or light rain.
- Page 3 Juralco Felicia Awning System - General Arrangement General Arrangement Fixings 1 - Cover and HomePlus nameplate 2 - Aluminum Fixing Bracket Operating Mechanism 3 - Head Box End Cap with Arm mounting 12 - Gearbox (for manual operation option) 4 - Aluminium Fixing Plate...
- Page 4 Juralco Felicia Awning System - General Components General Components FIXING BRACKET in heavy wall cast aluminium Powder coated in a colour of your choice Used in pairs and fixed directly onto the facings at both ends of the awning. They house the spindles for the casing and can be used for either wall or ceiling mounting.
- Page 5 Juralco Felicia Awning System - Components Roller Tube End Cap Stile Plug JFA/4090689 SJ037 80mm dia For Motor limit stop adjust and wiring access 12mm dia hole Fixing Bracket Set Head Box End Caps incl Cover with H+ logo RH + LH Set...
- Page 6 Juralco Felicia Awning System - Components Folding Arms Gearbox Handle Gearbox Handle Clip, Pt No JDA 4026500 Arm Set = 1 x RH, 1 x LH JDA/4039708 - 1500mm (Single Wire) Small Arm JDA/4039716 - 2000mm (Single Wire) JDA/4030431 - 1200mm...
- Page 7 Juralco Felicia Awning System - In Line Motors and Controls Tubular Motors Tubular Motors JNICE ERA M 3017 and 5012 JNICE ERA PLUS 3017 and 5012 Tubular Motors 45mm dia Tubular Motors 45mm dia Push Button Limit switches Easily set Mechanical...
- Page 8 Juralco Felicia Awning System - In Line Motors and Controls One switch per Single Motor only. Manual Control Use relays if more than single Motor HPM Rotary Connections at Motor Motor fully tested Switch Controls and Limits set at factory...
- Page 9 Juralco Felicia Awning System - Awning Retraction Wind Settings Wind Speed Adjustment - Awning Retraction settings At the factory, the intervention threshold to is set at level 3 and to change it you must take the following steps 01. Keep the n key pressed and wait for the motor to perform 2 movements. Upon completion, release the key.
- Page 10 Juralco Felicia Awning System - Measuring Measuring This Table for Low and Medium Wind Zones Face Fix For High Wind Zones please consult Juralco Widths, Up to Applies to Face Fix only Projection 2000 2500 3000 3500 4000 4500 5000 5500 5920 ü...
- Page 11 Juralco Felicia Awning System - Measuring Measuring This Table for Low and Medium Wind Zones Ceiling Fix For High Wind Zones please consult Juralco Widths, Up to Applies to Ceiling Fix only Projection 2000 2500 3000 3500 4000 4500 5000 5500 5920 ü...
- Page 12 Juralco Felicia Awning System - Installation Tools Contents, Awning Package Awning Roll, Head Box, Tools Needed. Arms, and Front Profile. Manual gearbox or inline motor - Stepladder - Drill, extension cable - Screwdrivers - Selection of SS screws - Tape measure...
- Page 13 Juralco Felicia Awning System - Installation Recommended Hole Sizes. - Wood - For M12 SS coach screws - 8 - 9mm hole Stud Setout - Concrete, Brick - For M12SS Studs - 12.5mm Hole 50 minimum Fixing Brackets Slot CL...
- Page 14 Juralco Felicia Awning System - Under Soffit Installation Soffit Fixing Bracket Option 1 Part No JFA/SFBRKT Roofing Roofing Gutter Gutter Felicia Awning Soffit Joists Spacer JVB 125 + EPDM Washer Spacer JVB 125 Soffit +PVC layer HomePlus Felicia Awning Soffit Bracket...
- Page 15 Juralco Felicia Awning System - Installation Lift Awning to Fixing Brackets - Loosen one bracket a little and slide along to give a say 4-5mm gap, to make the headbox install easier. - Carefully present the Headbox/End caps to the Fixed Brackets...
- Page 16 AW # Customer Contact Order No Date Juralco Juralco Juralco Select/Enter Dimensions below. Enter details/selections into all boxes. Then scan and send to sales@juralco.co.nz Unsuitable for use in Strong Wind Areas Felicia Awning Available Select Widths Enter Overall Projections Projection...
- Page 17 - These are new exemptions dated Dec 2010 While every effort has been made to ensure that this information is correct at time of writing, it is provided for guidance only and Juralco will accept no liability for, nor warrants the accuracy of this guidance. It is the sole responsibility of the of the purchaser to confirm current status of consent requirements with the relevant territorial authority before purchase and installation.
- Page 18 Juralco Felicia Awning System - Powder Coating Care and Maintenance Powder Coating Installation Care Warning re use of solvents: - In some cases strong solvents are recommended for thinning various types of paints and also for cleaning up mastics and sealants.
