JURALCO SOLEIA AWNING SYSTEM Issue 10-23 v2 Issue 8/15 Juralco Soleia Awning System Juralco Glass Pool Gate System Page 1 Page 1 www.juralco.co.nz ph (09) 478 8018 ISSUE 8/15 www.juralco.co.nz ph (09) 478 8018 ISSUE 10-23 v2...
Page 2
General Description - The Juralco Soleia Awning system is available as a single unit up to 5.92m wide, with a max 4.0m arm extension. - Typical applications include Decks, Bars, Shops, Terraces, or anywhere needing protection from the sun, or light rain.
Page 3
Also Duralloy and Duratec . ® ® ® Juralco Powder coated prices are for Duralloy Plus and Duralloy (same pricing). Duratec prices on application. The following specs apply to Building Exteriors. - Dulux Duralloy Plus ® powder coating systems are suitable for properties greater than 10m from high tide level.
Page 4
Juralco Soleia Awning System - Extrusions 60.5 HEADBOX FINISHING PROFILE JPA/403 9280/5.8 HEADBOX TOP PROFILE HEADBOX JPA/403 9250/4 FRONT PROFILE JPA/403 9250/5.8 JPA/403 9252/4 JPA/403 9252/5.8 106.7 124.5 HEADBOX UNDERFACE PROFILE JPA/403 9251/5.8 78/80 dia ROLLER TUBE, 78/80mm dia JDA/110 74/4 JDA/110 74/5.82...
Page 5
Juralco Soleia Awning System - Components Roller Tube End Cap Round Face Mount Plate Soffit Mount Plate JPA/403 9287 JPA/403 9297 JDA/403 1327 80mm dia 12mm dia shaft Soleia Arm Sets FranciaTec Arms JPA/BRAS2000 2000mm Projection JPA/BRAS2500 2500mm Projection JPA/BRAS3000...
Page 6
4 - The 230w connection can be at either end (specify on Order Form) 5 - Ex factory each Soleia Awning is supplied with a 1 Channel remote, (unless specified otherwise) all set up to operate the Awning as...
Page 7
Juralco Soleia Awning System - Motor Controls Volo Wind Sensor 15kph Limit set at factory Remote Control (set limits available 5,10,15,30,45kph) Wireless Controls Motor fully tested TTBus and Limits set at factory Wireless Remote Control Yellow Portable Wireless Transmitters Label...
Page 8
Juralco Soleia Awning System - Face Fix and Soffit Fix 251.0 Juralco Soleia Awning Face Fix 267.0 128.0 Soffit Mount Bracket 38.0 70.0 Juralco Soleia Awning Soffit Fix Issue 10-23 v2 Juralco Soleia Awning System Page 8 www.juralco.co.nz ph (09) 478 8018...
Page 9
Juralco Soleia Awning System - Cross Section Soffit Mount Bracket (if needed) Juralco Soleia Awning Headbox Finishing Profile Part no JPA/4039280 Roller Tube and Tubular Motor Headbox Top Profile Part no JPA/4039250 Mounting Brackets Headbox 200mm Front Profile Part no JPA/4039252...
Page 10
Juralco Soleia Awning System - Mounting Brackets Attach Hole dimensions M8 Clamp M8 Clamp screw holes screw holes JPA/4039287 FACE MOUNTING PLATE 200mm Attach Hole dimensions M12 x 35 SS C/s M12 C/s tapped holes machine screw JPA/4039297 SOFFIT MOUNT BRACKET 200mm Soffit Bracket and...
Page 11
Juralco Soleia Awning System - Installation - Size, Type and Bracket selection Width - 3 x 200mm Mounting Brackets - Standard Arm Supports Projection 3 x Soffit Brackets (if needed) 3 x Mounting Brackets - 4 x 200mm Mounting Brackets...
Page 12
Juralco Soleia Awning System - Installation - Setouts Package 1 - Be very careful opening the package. It is large and heavy. Best done on a table if possible - Be careful with knives, not scratch the Soffit Brackets surface of the awning.
Page 13
Juralco Soleia Awning System - Installation - Setouts Mounting Brackets, Height setout 1 - The installation height of the awning must allow a passage under the bar, at full extension. 1800 mm min (2100 recommended). For a Soffit Mount 45 minimum...
Page 14
Juralco Soleia Awning System - Installation Attach Bolts, studs 1 - Max Fastener dimension, proud of wall or packers is 20mm 2 - Table of maximum forces applied to each anchor: Fc (in daN) (FYI 1daN ≈ 1kg) Make sure that the tensile load Fr of the wall meets the condition Fr ≥ 2xFc Force Fc (in daN - dekaNewtons).
Page 15
Juralco Soleia Awning System - Installation Mounting to Wall 1 - Present your Awning from 2 - Engage upper groove 3 - Rotate downwards to clip in below the Mounting Brackets. in the Wall bracket. at bottom Fit the Headbox by pressing upwards...
Page 16
Juralco Soleia Awning System - Installation - Awning Slope Adjust Setting the Inclination 450 mm 1- Roll the blind up to about 450 mm from the wall, this allows to enter the access Screw A, to release the function and facilitate the tilt adjustment.
Page 17
Juralco Soleia Awning System - Installation - Final Final adjustments. 1 -Fix the Headbox Bottom Cover by clipping in at front first then raising and clipping in rear. 2 - Attach supplied clips to the mounting Brackets. Then fix the Headbox Top Cover by clipping in at front first then dropping and clipping in rear.
Page 18
AW # Customer Contact Order No Date Juralco Juralco Juralco Select/Enter Dimensions below. Enter details/selections into all boxes. Then scan and send to sales@juralco.co.nz Unsuitable for use in Strong Wind Areas Soleia Awning Available Select Widths Enter Overall Projections Projection...
Page 19
Juralco Soleia Awning System - FACTORY Assemble Remove the Front Profile WARNING : Leave Bracelets on the Arms to keep them Closed. 1 - FOLDING ARMS; disengage the front arm from the Front Profile. Keep the Bracelet in place and tie back to the Headbox bottom cover brackets.
Page 20
Juralco Soleia Awning System - FACTORY Assemble Assembling Fabric 1 - Roller Tube - Wrap the fabric so that it hangs about 1m from the ground. Important: Guide the fabric onto the Roller tube so that it stays smooth and does not wrinkle.
Page 21
Juralco Soleia Awning System - FACTORY Assemble Installing the Aligning Cams 1 - Position the 2 x Aligning cams (supplied as accessories) on the Front Profile. One cam in front of each upper arm joint at 80 mm ± 10 mm from the end of the arm support.
Page 22
Juralco Soleia Awning System - Powder Coating Care and Maintenance Powder Coating Installation Care Warning re use of solvents: - In some cases strong solvents are recommended for thinning various types of paints and also for cleaning up mastics and sealants.
