- Page 1 JURALCO VENETTE ™ RETRACTABLE PLEATED INSECT SCREEN SYSTEMS Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 1 www.juralco.co.nz ph (09) 478 8018 ISSUE 2/19...
- Page 2 Juralco retractable pleated insect screens the ultimate in insect screening solutions. Custom made in a variety of powder-coat colours. Index Pages Covers Section 1 - Venette™ Retractable Pleated Insect Screen - Single + Multiple Doors 3 - 4 General Showing typical component layouts 5 - 7...
- Page 3 Single Door - General Layout Doors Juralco will supply the Pleated Mesh Pack all fully assembled as enclosed below. Also included are1 x Top guide and 1 x U Profile All cut to length and Powdercoated to a colour of your choice.
- Page 4 Section 1 Single Door - General Layout for over 1500mm wide Doors Doors or 800mm wide in a High Wind area. Juralco will supply the Pleated Mesh Pack all fully Assembled. incorporating the extra Items below. Rivet Intermediate Scorpion Tail Tube...
- Page 5 Part No J7468 TRAIN CONNECTOR PVC STRIP U PROFILE Part No JPL/05/00100/0/5 Part No JPL/05/00080 Used to connect cassettes together in multiple cassette applications Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 5 www.juralco.co.nz ph (09) 478 8018...
- Page 6 End Cap (Bottom, fixed end) Part No JPL/05/13070/0/5 U PROFILE Part No JPL/05/00080 PVC Bottom Track 2.5m Part No JPL/05/00050/0/0 End Cap (Bottom, sliding Bar) Part No JPL/05/13050/0/5 Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 6 www.juralco.co.nz ph (09) 478 8018...
-
Page 7: Table Of Contents
BUILD OUT COVER Part No J7469 Corner Stake for Build Out BUILD OUT ANGLE Part No JC298 Part No J7468 Powder coated Black only Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 7 www.juralco.co.nz ph (09) 478 8018... - Page 8 Centre Close Height up to 3000max Close Close Door Open Widths Installation 2000min to 5800max can be reversed for RH or LH 3/1 combo operation Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 8 www.juralco.co.nz ph (09) 478 8018...
- Page 9 Train Connector PVC Strip Fixed Profile Part No JPL/05/00100/0/5 Anchor Plates Then Clip on to Clip on to this section this section. to begin with. Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 9 www.juralco.co.nz ph (09) 478 8018...
-
Page 10: Part No J7468
Attach Top Guide under here Attach Side Profile to inside here Attach Wall Profile and Anchor Plates to inside here Attach Flat Bottom Rail to inside here Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 10 www.juralco.co.nz ph (09) 478 8018... - Page 11 Juralco Venette™ Retractable Pleated Insect Screen System - Single Door Section 1 Installation Doors To watch this Installation video, click or enter the link below https://youtu.be/uBJ58l4ldxo 1 - Top Guide, attach both End Caps 2 - Attach Top Guide to the Ceiling, with suitable SS fasteners.
- Page 12 Train Connector Clips PVC Strips x 2 U Profile Magnetic strips on Door and U profile All other Door Configurations are variations of above Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 12 www.juralco.co.nz ph (09) 478 8018...
-
Page 13: Wire End Tail - Red
Screen damaged - If small, patches are available. If large, replace Screen Due to the products configuration the pleated screen cannot be replaced by itself. The entire screen door must be replaced. Juralco can supply replacement Mesh packs PVC for Magnet SLIDING BAR INCLINATION ADJUSTMENT... - Page 14 Slide the magnet down to insert the end into the groove on the scorpionfish, Top and Bottom Moving from bottom to top press the PVC for Magnet into the sliding bar Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 14 www.juralco.co.nz ph (09) 478 8018...
- Page 15 Screen Door Unit is properly installed. Check the Scorpion Tail retracts properly and does not come apart. ln case the Scorpion Tail comes apart, it can be easily reconnected. Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 15 www.juralco.co.nz ph (09) 478 8018...
- Page 16 Phone: (09) 478 8018 Fax : (09) 478 7883 Check all information carefully before sending this order.Juralco will not commence production until a signed order has been received. Remember, this is a one off custom unit made to your measurements and specifications.
- Page 17 Juralco Venette™ Retractable Pleated Insect Screens Section 2 Vertical Window - General Vertical Window Juralco Venette™ Vertical Window Mesh Kits to suit Window opening sizes Height Range Width Range Width Range 420mm - 1200mm 1201mm - 1800mm 500 - 1000...
- Page 18 Vertical Window - General Vertical Window Juralco will supply the Pleated Mesh Pack all fully assembled as enclosed below Also supplied are 1 x Top Guide and 2 x Side guides All cut to length and Powder Coated to a colour of your choice.
- Page 19 JPM/31-12510-4-5. 1250mm high x 1200mm wide JPM/31-12520-4-5. 1500mm high x 1200mm wide JPM/31-12530-4-5. 1800mm high x 1200mm wide JPM/31-12540-4-5. 1000mm high x 1800mm wide Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 19 www.juralco.co.nz ph (09) 478 8018...
- Page 20 Pile JRF98/10mm Pull bar end cap LH JPM/31-13580-0-5 Attach with Self Tapper Screw C/S SS 6g x 12mm Side Guides Prepunched in this area Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 20 www.juralco.co.nz ph (09) 478 8018...
- Page 21 4 - Place the mesh pack inside the Top Guide frame. Press up to clip into place. 5 - Tape the Mesh Pack to the Top Guide frame Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 21 www.juralco.co.nz ph (09) 478 8018...
- Page 22 ATTENTION: For a correct operation of the screen, don’t tension too much: the tension must be just enough to stop the blind from descending on its own. Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 22 www.juralco.co.nz ph (09) 478 8018...
- Page 23 Phone: (09) 478 8018 Fax : (09) 478 7883 Check all information carefully before sending this order.Juralco will not commence production until a signed order has been received. Remember, this is a one off custom unit made to your measurements and specifications.
- Page 24 Section 3 Horizontal Window - General Horizontal Window Juralco will supply the Pleated Mesh Pack all fully assembled as enclosed below Top Guide internally Also supplied are 1 x Top Guide, 2 x Side guides and 1 x Bottom Track Prepunched All cut to length and Powder Coated to a colour of your choice.
- Page 25 Window opening Heights all 720 to1300mm Window opening Widths 800mm to 3000mm Orders must specify the exact Window opening Height and Width at a square setout. Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 25 www.juralco.co.nz ph (09) 478 8018...
- Page 26 Wheel for End Caps Pull Bar End Caps Top Guide End Caps RH and LH JPM/31 - 13590-0-5 JPM/31-13500-0-5 JPM/09-13520-0-5 JPM/09-13520-0-5 Incl Wheel in place No Wheel Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 26 www.juralco.co.nz ph (09) 478 8018...
- Page 27 Bottom Track, now Vertical. - Remove Outer Tape - Push across and Clip the Non Spring side into the Side Profile Spring Cord carriers This side Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 27 www.juralco.co.nz ph (09) 478 8018...
- Page 28 8 - Replace Magnet strip, after adjustments. (A small Roller may be necessary) 9 - Clean up the area, leave tidy and clear. Wipe surfaces clean Issue 2/19 Juralco Venette™ Retractable Pleated, Insect Screen Systems Page 28 www.juralco.co.nz ph (09) 478 8018...
- Page 29 Phone: (09) 478 8018 Fax : (09) 478 7883 Check all information carefully before sending this order.Juralco will not commence production until a signed order has been received. Remember, this is a one off custom unit made to your measurements and specifications.
- Page 30 Juralco Venette™ Retractable Pleated, Insect Screens - Powder Coating Care and Maintenance Powder Coating Installation Care Warning re use of solvents: - In some cases strong solvents are recommended for thinning various types of paints and also for cleaning up mastics and sealants.
