Specifications - Unitech HT660 Specifications

System
OS Microsoft WinCE.NET 5.0 Professional
CPU Intel PXA255, running up to 300MHz
SDRAM 64 MB
Flash ROM 64MB
SD Slot Support SD/MMC Memory Card up to 1GB
Display
QVGA 240 x 320 color 2.7" TFT LCD display with touch screen and
backlight
Keypad
36 key keypad with numeric key, alpha key and function key, ESC, ENT,
Backspace, and cursor key, trigger key and other symbol key
Input Device
Keypad, Touch Screen, Full Alphanumeric Software Keyboard and Bar Code
Scanner
Laser Bar code Scanner
Scan rate 104 scans/sec. ± 12 scans/sec. (bi-directional)
o o
Scan Angle 47 ±3 default / 35
Decode Zone Typical
4.0 mils 1.0 in. - 5.5 in. / 2.45 cm- 13.97 cm
5.5 mils 1.25 in. - 8 in. / 3.18 cm- 20.32 cm
7.5 mils 1.5 in. - 13.25 in. / 3.81 cm- 33.66 cm
10 mils 1.5 in. - 17.5 in. / 3.81cm- 44.45cm
UPC 100% 1.5 in. - 23.5 in. / 3.81cm- 59.69cm
15 mils 1.5 in. - 29.5 in. / 3.81 cm- 74.93cm
20 mils 1.75 in. - 35.5 in. / 4.45 cm- 90.17cm
40 mils * - 40 in. / *- 101.6 cm
40.0 mils * - 55 in. / *- 139.7 cm
* Dependent on width of bar code
Symbologies
UPC-A/E, EAN-8/13, Codabar, Code 39,
Code 39 full ASCI, Code 93,Code 32,
Interleaved & Std. 2 of 5, EAN 128, Code 11,
Delta, MSI/Plessey,Code 128, Toshiba.
RS 232 Full duplex asynchronous communication
USB 1.1 1.1 Client
Bluetooth Class II
Wireless LAN 802.11b/g
Modem
product
design
award
2006
o o
±3 reduced

Specifications

Electrical
Sources 1. 100-240V 5V/ 3A DC external adapter
2. Rechargeable Li-Ion battery pack @ 3.7V 1950mAh
3. Rechargeable Backup battery @3.7V 120mAH
Consumption Standby: 90~100mA
Suspend: 2~5mA
Battery Life Up to 12 hours, depending on configuration and application
Charging 4 hours via charging cable or docking station
Enclosure
Dimension 199.5mm(L)x79mm(H)x39.6mm(W)
Weight 360g with battery pack
Environment
o o
Operating Temp 32 F to 122 F (0
o o
Storage Temp -4 F to 158 F (-20
Relative Humidity 5% to 95% (non-condensing)
IP Rating 54
Drop 1.5M
Docking Station
RS232/USB Cradle (With spare battery charging function)
Modem Cradle (With spare battery charging function)
Charging 4 hours
Power input AC Adapter 5V DC@3A
Accessories
USB Cable for charging & communication
RS232 Cable for charging & communication
Power Supply
Hand Strap
Stylus
Holster
Gun Grip (optional)
Software
Microsoft Visual Studio (C ++ , C ##
Unitech HT600 SDK
MCL Client (Optional Model)
MCL Designer (Optional)
MCL Net (Optional)
Oracle Database Lite
Regulatory Approvals
CB, CE, FCC, BSMI, VCCI, CCC,TELEC, RoHS Compliant
o o
C to 50 C)
o o
C to 70 C)
and VB.NET)
