- Page 1 Instruction Manual Electric Tilting Braising Pan Luxury Electric Range Series User’s Manual...
- Page 2 Instruction Manual Dear User & Client, Firstly, thanks for purchasing and using our product. All the information and guidelines of this user’s manual comply with certain applicable regulations, which come out from our long-term accumulated knowledge and experience as well as current project development situations.
- Page 3 Instruction Manual Warning ◆ Any self-modification, wrong installation, adjustment or maintenance can lead to property loss or casualty. Please contact the manufacturer for any adjustment or maintenance, and have the work done by a trained & qualified person. ◆ For your safety sake, please keep the machine away from any liquid, gas or other object, which is flammable or explosive.
-
Page 4: Table Of Contents
Instruction Manual Contents 1. Functional Introduction……………………………………...1 2. Structure Schematic Diagram & Working Principle…...…1 3. Basic Features & Parameters…………………………..…3 4. Precautions & Recommendations …………………..……4 5. Working Instructions & Operation Flow……………..……6 6. Routine Inspection ……………………………………..…..6 7. Cleaning & Maintenance………………………………..….7 8. Failure Analysis & Trouble Shooting…………………..….7... -
Page 5: Functional Introduction
Instruction Manual 1. Functional Introduction This product is one of the products of electric series 70 or 90 which remains the orthodox design of the series. Stainless steel made of housing, elegant in appearance and tilting in design, convenient for users to move the food in the pan maximally. The pan is made of stainless steel SS444. - Page 6 Instruction Manual 2.2 Structural & Functional Features： All stainless steel made, never rust. Equipped with water injection function. Heavy-duty heating elements with good heating efficiency. Provided with temperature controlled and constant function, and over-temperature protection function. The pan has tilting, lifting and overturn function, and pan-lifting disconnecting function.
-
Page 7: Basic Features & Parameters
Instruction Manual 3N~220V 3. Basic Features & Parameters Model ZH-TS60 ZH-TS80 Dimension（mm） 700×750×920 800×900×920 Capacity (L) Working Capacity (L) 3N~380V~400V/50HZ 3N~380V~400V/50HZ Power Supply 3N~220V~230V/60HZ 3N~220V~230V/60HZ Power(kW) 1/2” tube 1/2” tube Inlet Specification (mm) -
Page 8: Precautions & Recommendations
Instruction Manual 4. Precautions & Recommendations 4.1 Transportation and Storage During transportation, the machine should be carefully handled and do not put it upside down to prevent from damaging to the shell and inside. The packaged machine should be stored in a ventilated warehouse without corrosive gas. If it needs to be stored in open air temporarily, measurement against raining is needed. - Page 9 Instruction Manual 4.3 Special Notice 1. This product is a commercial machine that needs to be operated by trained cook, not applicable for household use. 2. Do not dismantle or self-modify the machine. Dismantlement and self-modification may cause casualty. 3. After working, turn off the switch. 4.
-
Page 10: Working Instructions & Operation Flow
Instruction Manual 5. Working Instructions & Operation Flow Control panel: As shown in structure schematic diagram, No.1-6 stands for corresponding functional switches respectively. Lift the cover and rotate the inlet valve knob 1 on control panel to inject appropriate amount of water into the pan. Switch on the power switch, at this time, the appliance is energized and the power indicator illuminates. -
Page 11: Cleaning & Maintenance
Instruction Manual 7. Cleaning and Maintenance The device shall be cleaned and maintained every day after working. Remove the grease and residues in drip pan regularly to keep the pan and the appliance surfaces clean. During cleaning, do not scrub the appliance and pan surface with abrasive substance or corrosive detergent, that may damage the appliance performance and appearance.
