Owner's Manual & Assembly Instructions
AG01
Model No.
697.68102 B1
714430817
Storage Area: 115 Sq. Ft.
10,7 m
BUILDING DIMENSIONS * Size rounded o to the nearest foot
*Approx.
Base
Size
Size
10' x 12'
121" X 143 1/4"
3,0 m x 3,6 m 307,3 cm x 363,9 cm
EH1012 C1
WL1012Z
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
645 Cu. Ft.
18,3 m
2
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
123 1/4" 145 3/4"
313,1 cm
370,2 cm
WL1012
EH1012EU C1 WL1012EU B1
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Height
Width
72 7/8"
118 1/4" 140 1/2"
185,1 cm
300,4 cm
EH1012BS C1
B1
Depth
Height
71 5/8"
356,9 cm 181,9 cm
Door
Opening
Width
Height
55 1/2"
60"
141,0 cm 152,4 cm
Advertisement
Related Manuals for Arrow Storage Products EH1012
Summary of Contents for Arrow Storage Products EH1012
- Page 1 Owner's Manual & Assembly Instructions AG01 WL1012 EH1012BS C1 EH1012 C1 Model No. EH1012EU C1 WL1012EU B1 697.68102 B1 WL1012Z Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests.
- Page 3 BEFORE YOU BEGIN..Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.
- Page 4 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
- Page 5 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
- Page 6 CARE & MAINTENANCE..Finish: For long lasting nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
- Page 7 ACCESSORIES..FLOOR FRAME KITS ROOF STRENGTHENING (heavy snow load) KITS Extra roof beams and gable braces designed for added protection against heavy snow accumulation. Increases the strength of your roof. BEFORE AFTER ANCHOR KITS Model No. AK4 MODELS FB47410, FB5465, FB106-A Anchor Kit contains heavy-duty steel FB109-A and FB1014-A augers, 60' (18 m) of steel cable and...
- Page 8 ORDERING ACCESSORIES..02/13 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is o ering them to you on a direct basis. There are two ways to order Arrow Storage Building Accessories: Option 1 Option 2...
- Page 9 Base AQ09 The Base For Your Building No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an e ective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
- Page 10 Anchoring Anchoring Down The Building It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
- Page 11 Hardware SV11 Remove from bag of screws and save for the last step 65900A #10Bx1/2" (13 mm) 65923 65004 65103 Black Screw (8) #8-32x3/8" (10 mm) #8Ax5/16" (8 mm) #8-32 Hex Nut (175) (Packed with Screws) Bolt (175) Screw (402) 65109 66646 #8-32 Acorn Nut (4)
- Page 12 Parts List SV12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 6000 Right Gable 6001 Left Gable 10497 Horizontal Door Brace 6529 Roof Panel 6640 Right Roof Panel 6641 Left Roof Panel 10475 Right and Left Doors 9369 Door Jamb 9373...
- Page 13 Assembly by Key No. SV13...
- Page 14 8934 Ramp (1) Step 1 Parts Needed For 9367 Front Floor Frame (2) Floor Frame Assemblies 8936 Rear Floor Frame (2) SV14 10392 Side Floor Frame (4) The front oor frame is made up of three pieces. The side floor frames 9367 and the rear floor frame are made up of two pieces.
- Page 15 5986 Rear Wall Angle (2) Step 2 Parts Needed For 10389 Rear Wall Channel (2) Frame Assemblies 10390 Side Wall Channel (4) SV15 10393 Side Wall Angle (4) The main frame pieces reinforce the walls. These pieces will later be Rear Wall Channel 10389 installed in the center and at the top...
- Page 16 Step 3 Parts Needed For 10397 Roof Beam (8) Roof Beam Assemblies SV16 The roof beams join the two gables and support the roof panels. The 10397 main roof beam is made up of four pieces overlapped back to back at the center.
- Page 17 Step 4 Parts Needed For 6403 Door Track Splice (1) Door Track Assembly 9366 Door Track (2) NOTE: The door track assembly supports the Door Track Splice (painted part) sliding doors and reinforces the front wall. It is made up of three pieces. 6403 Using the door track splice, (painted), join the door track...
- Page 18 Step 5 Front Floor Assembly (1) Parts Needed For Side Floor Assembly (2) Floor Frame Rear Floor Assembly (1) SW18 RIGHT REAR 10392 Assemble the four corners of the oor frame using two screws at STEP 8936 each corner as shown. At the front corners fasten bolts through from the bottom with nuts on top.
- Page 19 Step 6 Parts Needed For 6515 Wall Panel (2) 9373 Front Wall Panel (2) Corners 6514 Corner Panel (4) SR19 NOTE Narrow The remainder of the building assembly Side requires many hours and more than one 6514 person. Do not continue beyond this Wide Side point if you do not have enough time to complete the assembly today.
- Page 20 Step 7 Parts Needed For Rear Wall Channel Assembly (1) Mid Frames Side Wall Channel Assembly (2) SR20 The mid frame pieces give rigidity to the side and rear walls. Fasten the rear wall channel across the middle of the rear wall using screws.
- Page 21 Step 8 Door Track Assembly (1) Parts Needed For Rear Wall Angle Assembly (1) Top Frames Side Wall Angle Assembly (2) SQ21 The top frame pieces give rigidity to the walls and provide a surface for attaching the gables which support the roof.
- Page 22 Step 9 Parts Needed For 6515 Wall Panel (8) Wall Panels SR22 STEP Each wall panel has a crimped rib on one side. The crimped rib should go under the rib of the panel that follows it. Crimped Rib STEP Underneath Locate all of the wall panels and 6515...
- Page 23 Step 10 Parts Needed For 9369 Door Jamb (2) Front Channel/Door Jamb 9365 Front Wall Channel (2) SO23 The door jambs reinforce the door opening and provide an attractive 9365 trim. Follow these steps for both door jambs. Fasten the front wall channels STEP in their positions between the end of the side wall channel and the corner...
- Page 24 Step 11 Parts Needed For 6000 Right Gable (2) 6001 Left Gable (2) Gable Assemblies 5971 Roof Beam Bracket (4) SQ24 The gables go on top of the front and rear walls to support the roof beams. NOTE The gables are packed nested together and might be mistaken as one piece.
- Page 25 Step 12 Parts Needed For Left Gable Assemblies (2) Right Gable Assemblies (2) Gables/Braces 6635 Gable Brace (2) SQ25 Lift and fasten a right and left gable, under angle at corner, to the door track and rear wall angle with screws. Hint: On the front gable, leave out 2 screws closest to center gable leg.
- Page 26 Step 13 Parts Needed For Main Roof Beam Assembly (1) Roof Beams Single Roof Beam Assemblies (2) SQ26 Spread the two halves of the double roof beam and fasten to the gable brace of the front gable. STEP Fasten the other end of the double roof beam to the gable brace of the rear gable.
- Page 27 Step 14 Parts Needed For 6640 Right Roof Panel (1) Right Roof Panel SQ27 Installing the roof panels is best done with a step ladder. Begin Installing roof panels at the back right corner of the building. Each screw and bolt in the roof requires a washer.
- Page 28 Step 15 Parts Needed For 6641 Left Roof Panel (1) 6529 Roof Panel (2) Roof Assembly 6869 Ridge Cap (1) SQ28 Install a left roof panel at the left Screws To rear corner of the roof. Roof Beam Install two roof panels in the sequence shown on previous page.
- Page 29 Step 16 Parts Needed For 6529 Roof Panel (2) Roof Assembly 6868 Ridge Cap (1) SQ29 Install two roof panels as you unroll the weather stripping tape, and press it down, install the second ridge cap 6868 overlapping the rst ridge cap.
- Page 30 6529 Roof Panel (2) Step 17 Parts Needed For 6641 Left Roof Panel (1) Roof Assembly 6869 Ridge Cap (1) SQ30 6640 Right Roof Panel (1) Install two roof panels, left roof panel, ridge cap 6869 and right roof panel on the front of the roof as before.
- Page 31 Step 18 Parts Needed For 6015 Side Roof Trim (4) Roof Trim 6014 Side Roof Trim (2) SQ31 Attach the side roof trim pieces to the lower end of the roof panels on each side of the building using screws at each panel overlap. NOTE A single screw fastens both trim pieces at the overlap.
- Page 32 3719 Door Handle Brace (2) Step 19 Parts Needed For 10475 Right and Left Doors (2) Door Assembly 10497 Horizontal Door Brace (4) SO32 6278 Vertical Door Brace (2) The steps on this page tell how to assemble the right door. You will per- form exactly the same procedures for the left door.
- Page 33 Step 20 Parts Needed For Right Door Assembly (1) Door Installation & Adjustment Left Door Assembly (1) SQ33 Horizontal Door Brace Gable From inside the building, put the Door Track bottom of the right door assembly Door Slide (on your left when you are inside the building) behind door jamb into the front frame track.
- Page 34 Anchoring and Floor Frame XA34 Anchoring Anchor your building at this time. Floor Frame If you have purchased a Floor Frame Kit you need to install it at this time.
- Page 35 SOME FACTS ABOUT RUST XA35 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
- Page 36 WL1012 EH1012BS C1 EH1012 C1 EH1012EU C1 WL1012EU B1 697.68102 B1 WL1012Z AG36 714430817...
