Attach the Faceguard │ 5
3
2
1. Open the kickstand on the left side of the body so that it can be placed on
flat ground.
2. Plug the connectors on the faceguard into the connectors from the vehicle
body.
REMEMBER: yellow black to yellow black, red black to red black.
And hide connectors into the hole in the vehicle body.
3. Fit the faceguard to the vehicle body.
4. Use a screwdriver to tighten two Ø4X12 screws to secure it.
08
1
4
Attach the Front Wheel &
Handle bar │ 6
1. Insert the front wheel iron pipe through
the hole in the bottom of the front wheel.
And make sure that the limit stopper under
the body fits into the limit slot on the front
wheel fender.
Remove the M5x35 machine screw and
Ø5 nut from the fork tube.
2. Fit the handlebar to the fork
tube on the front wheel
assembly.
3. Align the holes on each
side of the handle bar with the
holes at the front fork. Insert
the M5x35 machine screw.
4. Fasten a Ø5 nut on the opposite
end of the screw to secure the handle
bar to the front fork.
5. Fit a mirror to the each hole on the top of the
handle bar, push until you hear it "click" into
place.
4
2
Limit stopper on the bottom
Limit stopper on the bottom
1
Limit slot on the
Limit slot on the
front wheel fender
front wheel fender
5
3
09
