  • Page 1 FusionServer XH628 V5 Server Node Technical White Paper Issue Date 2023-02-28 xFusion Digital Technologies Co., Ltd.
  • Page 2 Copyrights © xFusion Digital Technologies Co., Ltd. 2023. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of xFusion Digital Technologies Co., Ltd. Trademarks and Permissions and other xFusion trademarks are trademarks of xFusion Digital Technologies Co., Ltd.

  • Page 3: Table Of Contents

    FusionServer XH628 V5 Server Node Technical White Paper Contents Contents About This Document ......................v 1 Production Introduction ....................7 2 Features ........................... 8 3 Physical Structure ......................11 4 Logical Structure ......................14 5 Hardware Description ....................15 5.1 Front Panel ............................15 5.1.1 Appearance ............................15...
  • Page 4 FusionServer XH628 V5 Server Node Technical White Paper Contents 5.7 Boards ..............................45 5.7.1 Mainboard ............................45 6 Product Specifications ....................47 6.1 Technical Specifications ........................47 6.2 Environmental Specifications .........................50 6.3 Physical Specifications ..........................52 7 Software and Hardware Compatibility ................. 53 8 Safety Instructions......................54 8.1 Security..............................54...

  • Page 5: About This Document

    Technical White Paper About This Document About This Document Purpose This document describes the FusionServer XH628 V5 server node in terms of features, structure, specifications, and component hardware and software compatibility. Intended Audience This document is intended for pre-sales engineers.
  • Page 6 FusionServer XH628 V5 Server Node Technical White Paper About This Document Change History Issue Date Description 2023-02-28 Added A.4 Sensor List. 2022-11-11 Updated 8.1 Security. 2022-08-12 ⚫ Optimized 6.3 Physical Specifications . Added A.1 Node Label. ⚫ 2022-06-25 ⚫ Added a figure that shows how to measure dimensions.

  • Page 7: Production Introduction

    1 Production Introduction Production Introduction The FusionServer XH628 V5 (XH628 V5) is a server node designed for X6800 servers. An X6800 can house up to four XH628 V5 server nodes in a 4U chassis. The XH628 V5 delivers supreme performance and high storage density in limited space through innovative design.

  • Page 8: Features

    FusionServer XH628 V5 Server Node Technical White Paper 2 Features Features Performance and Scalability ® ® ⚫ Powered by two Intel Xeon Scalable Skylake or Cascade Lake processors, the server provides up to 28 cores, 3.8 GHz frequency, a 38.5 MB L3 cache, and two 10.4 GT/s UPI links between the processors, which deliver supreme processing...
  • Page 9 FusionServer XH628 V5 Server Node Technical White Paper 2 Features ⚫ It supports 12 SATA/SAS HDDs or SSDs. The SSDs deliver higher I/O performance than HDDs. An SSD supports approximately 100 times more I/O operations per second (IOPS) than a typical HDD.
  • Page 10 FusionServer XH628 V5 Server Node Technical White Paper 2 Features Energy Efficiency ⚫ The Intel® Xeon® Scalable processors outperform the previous-generation processors while fitting into the same TDP. ⚫ Efficient voltage regulator-down (VRD) power supplies for boards minimize the energy loss from DC/DC power conversion.

  • Page 11: Physical Structure

    FusionServer XH628 V5 Server Node Technical White Paper 3 Physical Structure Physical Structure ⚫ 2 x 2.5" drive configuration Figure 3-1 XH628 V5 physical structure Front drives Front-drive backplane Server node case DIMMs Screw-in RAID controller Mainboard card Processors Heat sinks...
  • Page 12 FusionServer XH628 V5 Server Node Technical White Paper 3 Physical Structure Vertical adapter Horizontal adapter Drives in a drawer 10-drive backplane for the 2-drive backplane for the drive drawer drive drawer Drive drawer enclosure ⚫ XH628 V5 with two HHHL PCIe cards...
  • Page 13 FusionServer XH628 V5 Server Node Technical White Paper 3 Physical Structure Heat sinks Vertical adapter Horizontal adapter Drives in a drawer 10-drive backplane for the drive drawer 2-drive backplane for the Drive drawer enclosure drive drawer 2023-02-28...

  • Page 14: Logical Structure

    FusionServer XH628 V5 Server Node Technical White Paper 4 Logical Structure Logical Structure Figure 4-1 XH628 V5 logical structure ® ® ⚫ The server supports two Intel Xeon Scalable processors. ⚫ The server supports up to 16 memory modules. ⚫...

  • Page 15: Hardware Description

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Hardware Description 5.1 Front Panel 5.2 Processors 5.3 Memory 5.4 Storage 5.5 Network 5.6 I/O Expansion 5.7 Boards 5.1 Front Panel 5.1.1 Appearance ⚫ 2 x 2.5" drive configuration...
  • Page 16 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Figure 5-1 Front view Drives Ejector lever Ejector release latch Slide-out label plate (with an SN label) Drive drawer Drive drawer latch Drive drawer handle ⚫ 2 x HHHL PCIe card configuration...

  • Page 17: Indicators And Buttons

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Figure 5-2 Front view Standard PCIe card Ejector lever Ejector release latch Slide-out label plate (with an SN label) Drive drawer Drive drawer latch Drive drawer handle 5.1.2 Indicators and Buttons Indicator and Button Positions ⚫...
  • Page 18 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Figure 5-3 Indicators and buttons on the front panel LOM port indicator Power button/indicator Health status indicator UID button/indicator LOM port indicator Management network port data transmission status indicator...
  • Page 19 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Figure 5-4 Indicators and buttons on the front panel LOM port indicator Power button/indicator Health status indicator UID button/indicator LOM port indicator Management network port data transmission status indicator...
  • Page 20 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Indicator/Butt Silkscreen Description ⚫ Steady green: The device is powered on. Blinking yellow: The iBMC is starting. The ⚫ power button is locked and cannot be pressed. The iBMC is started in about 1 minute, and then the power indicator is steady yellow.

  • Page 21: Ports

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Indicator/Butt Silkscreen Description indicator Connection Off: The network port is not connected. ⚫ status Steady green: The network port is properly ⚫ indicator on connected. management port LINK Network port Off: The network port is not connected.
  • Page 22 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Universal connector port LOM port 1 LOM port 2 Management network port ⚫ 2 x HHHL PCIe card configuration Figure 5-6 Ports on the front panel Universal connector port...

  • Page 23: Installation Positions

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Figure 5-7 Multi-port cable VGA port Two USB ports Serial port One USB port Universal connector port Port Description Table 5-2 Description of ports on the front panel Port...

  • Page 24: Processors

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Figure 5-8 Installation positions The PCIe slots and RAID controller card in the rear chassis are connected to CPU 2 of each XH628 V5. 5.2 Processors ⚫ The server supports two processors.

  • Page 25: Memory

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description 5.3 Memory 5.3.1 DDR4 Memory 5.3.1.1 Memory Identifier You can determine the memory module properties based on the label attached to the memory module. Figure 5-10 Memory identifier Callout...

  • Page 26: Memory Subsystem Architecture

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Callout Description Definition Column Access Strobe (CAS) P: 15 ⚫ latency ⚫ T: 17 DIMM type R: RDIMM ⚫ ⚫ L: LRDIMM 5.3.1.2 Memory Subsystem Architecture The XH628 V5 provides 16 memory slots. Each processor integrates six memory channels.
  • Page 27 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description ⚫ A server must use the same model of DDR4 DIMMs, and all the DIMMs operate at the same speed, which is the smallest value of: ⚫ Memory speed supported by a processor ⚫...

  • Page 28: Dimm Installation Rules

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Parameters Specifications Maximum capacity per DDR4 DIMM (GB) Rated speed (MT/s) 2933 Operating voltage (V) Maximum number of DDR4 DIMMs in a node Maximum DDR4 memory capacity of the node (GB)

  • Page 29: Memory Installation Positions

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description For a multi-processor configuration, each processor must have a valid ◼ memory mirroring configuration. Memory scrubbing mode − ◼ Comply with the general installation guidelines. 5.3.1.5 Memory Installation Positions An XH628 V5 supports a maximum of 16 DDR4 DIMMs.

  • Page 30: Memory Protection Technologies

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description 5.3.1.6 Memory Protection Technologies The following memory protection technologies are supported: ⚫ ⚫ Full mirroring ⚫ Address range mirroring ⚫ SDDC ⚫ SDDC+1 ⚫ Rank sparing mode ⚫ Static virtual lockstep ⚫...

  • Page 31: Drive Numbering

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Specifies the hard drive Drive Management Maximum Drives type. Mode ⚫ Slots 0, Slots 1 support only M.2 SSD a: Only 2.5-inch drives fit into the front slots. If the front panel is configured with 2 ⚫...
  • Page 32 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Table 5-6 Mapping between front drive IDs and physical slots displayed in System Event Logs Front drive Physical Slots Front drive Physical Slots number Displayed in number Displayed in...
  • Page 33 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Drawer Drive Physical Slots Drawer Drive Physical Slots Numbering Displayed in Numbering Displayed in System Event System Event Logs Logs DISK10 Inner DISK11 Inner ⚫ M.2 SSD Figure 5-15 M.2 SSD number...
  • Page 34 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Figure 5-16 M.2 FRU SSD number 2023-02-28...

  • Page 35: Drive Indicators

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description 5.4.3 Drive indicators SAS/SATA Drive Indicator Figure 5-17 SAS/SATA drive indicator (2 x 2.5-inch front drive) Table 5-8 SAS/SATA drive indicator (2 x 2.5-inch front drive) description Activity Indicator...
  • Page 36 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Drive Drawer Indicator Figure 5-18 Drive drawer Indicator (example: front 2 x 2.5-inch configuration) Table 5-9 Drive drawer Indicator (example: front 2 x 2.5-inch configuration) Drive drawer Drive drawer...

  • Page 37: Raid Controller Card

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description M.2 FRU Indicators Figure 5-19 M.2 FRU indicators Table 5-10 M.2 FRU indicator description Indicator Description M.2 FRU fault indicator Off: The M.2 FRU is running properly. ⚫ ⚫...
  • Page 38 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Chip Numb Rate Supported Rates Not Port Type Type Model er of Negotiatio Rates Supported Ports n Mode X722 10GE Auto-negoti 10,000 10 Mbit/s, optical ation Mbit/s 100 Mbit/s,...
  • Page 39 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description 10GE optical port (LOM 10GE optical port (LOM port 1) port 2) GE electrical port (LOM GE electrical port (LOM port 3) port 4) Figure 5-21 LOM ports (2 x HHHL PCIe cards)
  • Page 40 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Indicator Positions Figure 5-22 LOM indicators (2 x 2.5" drive configuration) Connection status Data transmission rate indicator/Data transmission indicator for a 10GE optical status indicator for a 10GE port...
  • Page 41 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Figure 5-23 LOM indicators (2 x HHHL PCIe cards) Connection status Data transmission rate indicator/Data transmission indicator for a 10GE optical status indicator for a 10GE port optical port...

  • Page 42: I/O Expansion

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Indicator Description indicator Steady green: The network port is properly connected. ⚫ GE electrical port Off: Inactive. ⚫ transmission status Steady yellow: Active, but no data is being transmitted.
  • Page 43 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Figure 5-24 PCIe slots (2 standard HHHL PCIe cards) ⚫ Rear panel Figure 5-25 shows the mapping between PCIe slots and server nodes (7, 5, 3, and 1 from left to right).

  • Page 44: Pcie Slot Description

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description 5.6.3 PCIe Slot Description Table 5-13 PCIe slot description PCIe PCIe Connec Port B/D/F Slot Slot Standa Width Size Width RAID CPU 2 PCIe Port1A 85/00/0 controll er card...

  • Page 45: Boards

    FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description 5.7 Boards 5.7.1 Mainboard Figure 5-26 XH628 V5 mainboard PCIe slot 1 2.5" drive backplane DIMM050 connector connector DIMM040 connector DIMM030 connector DIMM031 connector CPU 1 DIMM150 connector DIMM140 connector...
  • Page 46 FusionServer XH628 V5 Server Node Technical White Paper 5 Hardware Description Signal connector Guide sleeve Signal connector Signal connector Signal connector Power connector Power connector a: The port is reserved. 2023-02-28...

  • Page 47: Product Specifications

    FusionServer XH628 V5 Server Node Technical White Paper 6 Product Specifications Product Specifications 6.1 Technical Specifications 6.2 Environmental Specifications 6.3 Physical Specifications 6.1 Technical Specifications Table 6-1 Technical specifications Components Specifications Form factor 4U4 server node ® Chipset Intel C622 Supports two processors.
  • Page 48 FusionServer XH628 V5 Server Node Technical White Paper 6 Product Specifications Components Specifications RDIMM and LRDIMM support ⚫ ⚫ The DDR4 memory modules of different types (RDIMM and LRDIMM) and specifications (capacity, bit width, rank, and height) cannot be used together.
  • Page 49 FusionServer XH628 V5 Server Node Technical White Paper 6 Product Specifications Components Specifications Network Supports LOM. ⚫ Supports two 10GE optical ports and two GE electrical ports via the NIC chip integrated on the mainboard. The LOM ports support NC-SI, WOL, and PXE.

  • Page 50: Environmental Specifications

    FusionServer XH628 V5 Server Node Technical White Paper 6 Product Specifications Components Specifications is provided. System management ⚫ Supports UEFI. Supports iBMC. ⚫ ⚫ Supports NC-SI. Supports integration with third-party management ⚫ systems. Security features ⚫ Power-on password Administrator password ⚫...
  • Page 51 FusionServer XH628 V5 Server Node Technical White Paper 6 Product Specifications Category Specifications highest operating temperature is subject to the XH628 V5. Relative humidity (RH, ⚫ Operating humidity: 5% to 85% non-condensing) Storage humidity (within three months): 8% to 85% ⚫...

  • Page 52: Physical Specifications

    FusionServer XH628 V5 Server Node Technical White Paper 6 Product Specifications The maximum preservation duration is determined according to the preservation ⚫ specifications provided by drive vendors. For details, see the manuals provided by drive vendors. 6.3 Physical Specifications Table 6-3 Physical specifications...

  • Page 53: Software And Hardware Compatibility

    FusionServer XH628 V5 Server Node Technical White Paper 7 Software and Hardware Compatibility Software and Hardware Compatibility Use the Compatibility Checker to obtain information about the operating systems and hardware supported. ⚫ If incompatible components are used, the device may be abnormal. This fault is beyond the scope of technical support and warranty.

  • Page 54: Safety Instructions

    FusionServer XH628 V5 Server Node Technical White Paper 8 Safety Instructions Safety Instructions 8.1 Security 8.2 Maintenance and Warranty 8.1 Security General Statement ⚫ Comply with local laws and regulations when installing devices. These Safety Instructions are only a supplement.
  • Page 55 FusionServer XH628 V5 Server Node Technical White Paper 8 Safety Instructions ⚫ Do not carry the weight that is over the maximum load per person allowed by local laws or regulations. Before moving or installing equipment, check the maximum equipment weight and arrange required personnel.
  • Page 56 FusionServer XH628 V5 Server Node Technical White Paper 8 Safety Instructions Figure 8-3 Wearing an ESD wrist strap ⚫ Exercise caution when using tools. ⚫ If the installation position of the device is higher than the shoulders of the installation personnel, use a vehicle such as a lift to facilitate installation. Prevent the equipment from falling down and causing personal injury or damage to the equipment.

  • Page 57: Maintenance And Warranty

    FusionServer XH628 V5 Server Node Technical White Paper 8 Safety Instructions equipment being transported is always kept upright. Take necessary precautions to prevent collisions, corrosion, package damage, damp conditions and pollution. ⚫ Transport the equipment in its original packaging. ⚫...

  • Page 58: System Management

    FusionServer XH628 V5 Server Node Technical White Paper 9 System Management System Management The server uses the next-generation Intelligent Baseboard Management Controller (iBMC) to implement remote server management. The iBMC complies with IPMI 2.0 and provides highly reliable hardware monitoring and management.
  • Page 59 FusionServer XH628 V5 Server Node Technical White Paper 9 System Management Specifications Description Setting of boot device Supports out-of-band configuration for the boot device. Alarm management Supports alarm management and reports alarms using the SNMP trap, SMTP, and syslog service to ensure 24/7 operating.

  • Page 60: A Appendix

    FusionServer XH628 V5 Server Node Technical White Paper A Appendix Appendix A.1 Node Label Figure A-1 Position of the XH628 V5 label Table A-1 XH628 V5 Label description Description Serial number of the server node. For details, see A.2 Product SN.
  • Page 61 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Figure A-2 Example SN Table A-2 SN description Description ESN ID (two characters), which can only be 21. Material ID (eight characters), that is, the processing code. Vendor code (two characters), that is, the code of the processing place.
  • Page 62 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Module Feature Description Corrected Machine Check Corrects error-triggered interrupts. Interrupt (CMCI) Memory Failed DIMM Isolation Identifies faulty DIMMs to facilitate isolation and replacement of the faulty DIMMs. Memory Thermal Throttling...
  • Page 63 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Module Feature Description Socket disable for FRB Isolates a faulty socket during the BIOS (Fault Resilient Boot) startup process to improve system reliability. Architected Error Records With the features such as eMCA, the...
  • Page 64 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Sensor Description Component controller card PCH Temp PCH bridge temperature Mainboard CPU1 Core Rem CPU core temperature CPU 1 CPU2 Core Rem CPU core temperature CPU 2 CPU1 DTS CPU DTS value...
  • Page 65 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Sensor Description Component SYS 12V_1 Mainboard 12 V voltage Mainboard SYS 12V_2 Mainboard 12 V voltage Mainboard CPU1 VCore 1.8 V CPU voltage Mainboard CPU2 VCore 1.8 V CPU voltage...
  • Page 66 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Sensor Description Component FAN4 R Speed Fan speed Fan module 4 4 indicates the fan module number. FAN5 F Speed Fan speed Fan module 5 5 indicates the fan module number.
  • Page 67 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Sensor Description Component PS1 Status PSU fault status 1 indicates the PSU number. PS2 Presence PSU presence status 2 indicates the PSU number. PS2 Status PSU fault status 2 indicates the PSU number.
  • Page 68 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Sensor Description Component Boot Error Boot error Watchdog2 Watchdog Mngmnt Health Management subsystem health status DISK0 Inner Drive status Drive DISK1 Inner Drive status Drive DISK2 Inner Drive status Drive...
  • Page 69 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Sensor Description Component number. FAN3 R Presence Fan presence Fan module 3 3 indicates the fan module number. FAN4 F Presence Fan presence Fan module 4 4 indicates the fan module number.
  • Page 70 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Sensor Description Component number. FAN5 F Status Fan fault status Fan module 5 5 indicates the fan module number. FAN5 R Status Fan fault status Fan module 5 5 indicates the fan module number.
  • Page 71 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Sensor Description Component 030 indicates the DIMM slot number. DIMM031 DIMM status DIMM 031 indicates the DIMM slot number. DIMM040 DIMM status DIMM 040 indicates the DIMM slot number. DIMM050...
  • Page 72 FusionServer XH628 V5 Server Node Technical White Paper A Appendix Sensor Description Component HDD Backplane Hardware presence Drive backplane Front HDD BP Hardware presence Drive backplane Port# Link Down Network port link status Mainboard Eth Heartbeat Heartbeat status Mainboard RAID PCIE ERR...

  • Page 73: B Glossary

    FusionServer XH628 V5 Server Node Technical White Paper B Glossary Glossary B.1 A-E ejector lever A part on the panel of a device used to facilitate installation or removal of the device. Ethernet A baseband local area network (LAN) architecture developed by Xerox Corporation by partnering with Intel and DEC.
  • Page 74 FusionServer XH628 V5 Server Node Technical White Paper B Glossary B.3 K-O A hardware device that provides public keyboard, video and mouse (KVM). B.4 P-T panel An external component (including but not limited to ejector levers, indicators, and ports) on the front or rear of the server.
  • Page 75 FusionServer XH628 V5 Server Node Technical White Paper B Glossary B.5 U-Z A unit defined in International Electrotechnical Commission (IEC) 60297-1 to measure the height of a cabinet or chassis. 1 U = 44.45 mm UltraPath A point-to-point processor interconnect developed by Interconnect (UPI) Intel.

  • Page 76: C Acronyms And Abbreviations

    FusionServer XH628 V5 Server Node Technical White Paper C Acronyms and Abbreviations Acronyms and Abbreviations C.1 A-E alternating current Advanced Encryption Standard New Instruction Set Address Resolution Protocol Advanced Vector Extensions backup battery unit BIOS Basic Input/Output System calendar day...
  • Page 77 FusionServer XH628 V5 Server Node Technical White Paper C Acronyms and Abbreviations DDR3 Double Data Rate 3 DDR4 Double Data Rate 4 DDDC double device data correction DEMT Dynamic Energy Management Technology DIMM dual in-line memory module DRAM dynamic random-access memory...
  • Page 78 FusionServer XH628 V5 Server Node Technical White Paper C Acronyms and Abbreviations high availability hard disk drive high-performance computing HTTP Hypertext Transfer Protocol HTTPS Hypertext Transfer Protocol Secure iBMC intelligent baseboard management controller Industry Canada ICMP Internet Control Message Protocol...
  • Page 79 FusionServer XH628 V5 Server Node Technical White Paper C Acronyms and Abbreviations LAN on motherboard media access control module management controller next business day NC-SI Network Controller Sideband Interface C.4 P-T PCIe Peripheral Component Interconnect Express power distribution unit physical layer...
  • Page 80 FusionServer XH628 V5 Server Node Technical White Paper C Acronyms and Abbreviations RJ45 registered jack 45 RoHS Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Serial Attached Small Computer System Interface SATA Serial Advanced Technology Attachment...
  • Page 81 FusionServer XH628 V5 Server Node Technical White Paper C Acronyms and Abbreviations TCP offload engine trusted platform module C.5 U-Z UDIMM unbuffered dual in-line memory module UEFI Unified Extensible Firmware Interface unit identification light Underwriter Laboratories Inc. Universal Serial Bus...
