FusionServer 2298 V5 Server
Technical White Paper
Issue
03
Date
2022-06-25
xFusion Digital Technologies Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FusionServer 2298 V5 and is the answer not in the manual?

Questions and answers

Related Manuals for Fusion FusionServer 2298 V5

Summary of Contents for Fusion FusionServer 2298 V5

  • Page 1 FusionServer 2298 V5 Server Technical White Paper Issue Date 2022-06-25 xFusion Digital Technologies Co., Ltd.
  • Page 2 Copyrights © xFusion Digital Technologies Co., Ltd. 2022. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of xFusion Digital Technologies Co., Ltd. Trademarks and Permissions and other xFusion trademarks are trademarks of xFusion Digital Technologies Co., Ltd.

  • Page 3: Table Of Contents

    FusionServer 2298 V5 Server Technical White Paper Contents Contents About This Document ........................v 1 Product Introduction ........................7 2 Features ............................8 3 Physical Structure ........................11 4 Logical Structure ......................... 13 5 Hardware Description ........................ 15 5.1 Front Panel .................................. 15 5.1.1 Appearance ................................
  • Page 4 FusionServer 2298 V5 Server Technical White Paper Contents 5.7 I/O Expansion ................................42 5.7.1 PCIe Cards ................................42 5.7.2 PCIe Slots ................................42 5.7.3 PCIe Slot Description .............................. 43 5.8 PSUs ................................... 44 5.9 Fans ..................................... 45 5.10 Boards ..................................47 5.10.1 Mainboard ................................

  • Page 5: About This Document

    FusionServer 2298 V5 Server Technical White Paper About This Document About This Document Purpose This document describes the 2298 V5 rack server in terms of features, structure, specifications, and component hardware and software compatibility. Intended Audience This document is intended for pre-sales engineers.
  • Page 6 FusionServer 2298 V5 Server Technical White Paper About This Document Change History Issue Release Date Change Description 2022-06-25 ⚫ Update 5.5.1 Drive Configuration. ⚫ Added a figure that shows how to measure dimensions. ⚫ Added 5.10.3 PSU Backplane . ⚫...

  • Page 7: Product Introduction

    Technical White Paper 1 Product Introduction Product Introduction FusionServer 2298 V5 (2298 V5) is a new-generation 2U 2-socket rack server designed for Internet, enterprise, and telecom applications. The 2298 V5 applies to distributed storage, big data analysis, software-defined storage, video, backup and archiving, and other storage-intensive cold storage scenarios.

  • Page 8: Features

    FusionServer 2298 V5 Server Technical White Paper 2 Features Features Performance and Scalability ⚫ ® ® Powered by two Intel Xeon Scalable Skylake or Cascade Lake processors, the server provides up to 28 cores, 3.8 GHz frequency, a 38.5 MB L3 cache, and two 10.4 GT/s UPI links between the processors, which deliver supreme processing performance.
  • Page 9 FusionServer 2298 V5 Server Technical White Paper 2 Features Availability and Serviceability ⚫ Carrier-class components with process expertise ensure high system reliability and availability. ⚫ The server supports twenty-four 3.5-inch front SAS/SATA drives and four 2.5-inch rear SAS/SATA/NVMe drives. All the drives are hot-swappable, and the 2.5-inch SAS/SATA drives support RAID1, 10, and 1E.
  • Page 10 FusionServer 2298 V5 Server Technical White Paper 2 Features ⚫ Area-based, Proportional-Integral-Derivative (PID) intelligent fan speed adjustment and intelligent CPU frequency scaling optimize heat dissipation and reduce overall system power consumption. ⚫ The improved thermal design with energy-efficient fans ensures optimal heat dissipation and reduces system power consumption.

  • Page 11: Physical Structure

    FusionServer 2298 V5 Server Technical White Paper 3 Physical Structure Physical Structure Figure 3-1 2298 V5 physical structure Rear drive Rear-drive module PCIe riser module Standard PCIe card PSU backplane Chassis Air duct 1 Upper-layer drive drawer Lower-layer drive drawer...
  • Page 12 FusionServer 2298 V5 Server Technical White Paper 3 Physical Structure OCP 2.0 Mezz card 2022-06-25...

  • Page 13: Logical Structure

    FusionServer 2298 V5 Server Technical White Paper 4 Logical Structure Logical Structure Figure 4-1 2298 V5 logical structure ⚫ ® ® The server supports one or two Intel Xeon Scalable processors. ⚫ The server supports up to 12 memory modules.
  • Page 14 FusionServer 2298 V5 Server Technical White Paper 4 Logical Structure ⚫ The LBG-2 Platform Controller Hub (PCH) supports: − Two 10GE optical LOM ports − Two GE electrical LOM ports − Two SATA or PCIe ports for M.2 SSDs ⚫...

  • Page 15: Hardware Description

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Hardware Description 5.1 Front Panel 5.2 Rear Panel 5.3 Processor 5.4 Memory 5.5 Storage 5.6 Network 5.7 I/O Expansion 5.8 PSUs 5.9 Fans 5.10 Boards 5.1 Front Panel 5.1.1 Appearance...

  • Page 16: Indicators And Buttons

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description slider Upper drive drawer Mounting ear ejector lever Lower drive drawer Slide-out label plate (with an SN label) 5.1.2 Indicators and Buttons Indicator and Button Positions Figure 5-2 Indicators and buttons on the front panel...
  • Page 17 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Indicator and Button Descriptions Table 5-1 Description of indicators and buttons on the front panel Sign Indicator and Description Button Power Power indicator: button/indicator ⚫ Off: The device is not powered on.

  • Page 18: Ports

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Sign Indicator and Description Button NMI, press this button or click the button on the iBMC WebUI. NOTICE ⚫ Press the NMI button only when the OS is abnormal. Do not press this button when the server is operating properly.

  • Page 19: Rear Panel

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description USB 3.0 ports VGA port Port Description Table 5-2 Ports on the front panel Port Type Quantity Description USB port USB 3.0 Used to connect to a USB device. NOTICE...

  • Page 20: Indicators

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description (Optional) OCP 2.0 mezzanine card ⚫ For details about the LOM and OCP 2.0 mezzanine card, see 5.6 Network. ⚫ The preceding figure is for reference only. 5.2.2 Indicators Indicator Positions...
  • Page 21 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Indicator Description ⚫ PSU indicator Off: No power is supplied. ⚫ Blinking green at 1 Hz: − The input is normal, and the server is standby. The input is overvoltage or undervoltage.

  • Page 22: Ports

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description 5.2.3 Ports Port Positions Figure 5-6 Ports on the rear panel Socket for PSU 1 Socket for PSU 2 Serial port Management network port LOM port 1 VGA port LOM port 2 USB 3.0 port...

  • Page 23: Processor

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Tool Type Quantity Description PSUs, ensure that the rated power of the PSUs is greater than that of the server. ⚫ If only one PSU is used, Predicted PSU Status cannot be set to Active/Standby on the iBMC WebUI.

  • Page 24: Memory

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Figure 5-7 Processor positions 5.4 Memory 5.4.1 DDR4 Memory 5.4.1.1 Memory Identifier You can determine the memory module properties based on the label attached to the memory module. Figure 5-8 Memory identifier...

  • Page 25: Memory Subsystem Architecture

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Callout Description Definition ⚫ Capacity of the memory module 8 GB ⚫ 16 GB ⚫ 32 GB ⚫ 64 GB ⚫ 128 GB Number of ranks of the memory ⚫...

  • Page 26: Memory Compatibility

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Memory Channel Memory Slot DIMM110(H) DIMM120(I) DIMM130(J) DIMM140(K) DIMM150(L) 5.4.1.3 Memory Compatibility Observe the following rules when configuring DDR4 DIMMs: ⚫ A server must use the same model of DDR4 DIMMs, and all the DIMMs operate at the same speed, which is the smallest value of: ⚫...

  • Page 27: Dimm Installation Rules

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description ⚫ The maximum number of DIMMs supported by a server varies depending on the CPU type, memory type, rank quantity, and operating voltage. Each memory channel supports a maximum of 8 ranks. The number of DIMMs supported by each channel varies depending on the number of ranks supported by each channel: Number of DIMMs supported by each channel ≤...

  • Page 28: Memory Installation Positions

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description ⚫ Observe the following when configuring DDR4 memory modules in specific operating mode: − Memory sparing mode ◼ Comply with the general installation guidelines. ◼ Each memory channel must have a valid online spare configuration.
  • Page 29 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Figure 5-9 Memory slots Figure 5-10 DDR4 memory installation guidelines (1 processor) 2022-06-25...

  • Page 30: Memory Protection Technologies

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Figure 5-11 DDR4 memory installation guidelines (2 processors) 5.4.1.6 Memory Protection Technologies The following memory protection technologies are supported: ⚫ ⚫ Full mirroring ⚫ Address range mirroring ⚫ SDDC ⚫...

  • Page 31: Storage

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description 5.5 Storage 5.5.1 Drive Configuration Table 5-7 Drive configuration Configuration Maximum Maximum Maximum Drive Number of Number of Number of Management Front Drawer Built-in Rear Drives Mode Drives Drives ⚫...

  • Page 32: Drive Numbering

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Configuration Maximum Maximum Maximum Drive Number of Number of Number of Management Front Drawer Built-in Rear Drives Mode Drives Drives The PCIe RAID controller card must be installed in slot 2 ⚫...
  • Page 33 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Figure 5-12 Drive numbering ⚫ Rear drives Figure 5-13 Drive numbering ⚫ Built-in drives (M.2 SSD-0/1) 2022-06-25...
  • Page 34 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Figure 5-14 Drive numbering 2022-06-25...

  • Page 35: Drive Indicators

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description 5.5.3 Drive Indicators Front Drive Drawer Indicators (3.5-inch SAS/SATA drives) Figure 5-15 Indicators of the front drive drawer Table 5-8 Description of identification indicators of the front drive drawer Drive Identification Indicator (Blue)
  • Page 36 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Activity Indicator Fault Indicator Description (Green) (Yellow) Blinking The drive is being accessed. NOTE The blinking speed indicates the number of I/Os. Steady on The drive is online. Blinking at 8 Hz The drive is faulty.
  • Page 37 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description NVMe Drive Indicators Figure 5-17 NVMe drive indicators ⚫ If the VMD function is enabled and the latest VMD driver is installed, the NVMe drives support surprise hot swap. Table 5-11 NVMe drive indicators (VMD enabled)

  • Page 38: Raid Controller Card

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Activity Indicator Fault Indicator Description (Green) (Yellow) Steady on/Off Steady on The NVMe drive is faulty. M.2 FRU Indicators Figure 5-18 M.2 FRU indicators Table 5-13 M.2 FRU indicator description...

  • Page 39: Network

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description 5.6 Network 5.6.1 LOMs LOMs provide network expansion capabilities. Table 5-14 LOMs supported by the 2298 V5 Chip Port Number Rate Supporte Rates Type Model Type of Ports Negotiati d Rates...
  • Page 40 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description 10GE optical port (LOM port 10GE optical port (LOM port GE electrical port (LOM port GE electrical port (LOM port Indicator Positions Figure 5-20 LOM indicators Connection status Data transmission rate...

  • Page 41: Ocp 2.0 Mezzanine Cards

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Indicator Description ⚫ Connection status Off: The network port is not connected. indicator of a GE ⚫ Steady green: The network port is properly connected. electrical port 5.6.2 OCP 2.0 Mezzanine Cards OCP 2.0 mezzanine cards provide network expansion capabilities.

  • Page 42: I/O Expansion

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Indicator Description Table 5-17 OCP 2.0 mezzanine card indicators Indicator Description Connection status ⚫ Off: The network port is not connected. indicator/Data ⚫ Blinking green: Data is being transmitted. transmission status ⚫...

  • Page 43: Pcie Slot Description

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description PCIe Riser Module Figure 5-23 PCIe riser module 5.7.3 PCIe Slot Description The PCIe slots mapping to a vacant CPU socket are unavailable. Table 5-18 PCIe slot description PCIe PCIe...

  • Page 44: Psus

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description PCIe PCIe Conne Port Root Device Slot Stand ctor Port (B/D/F Slot Width Size (B/D/F ards Width card Slot 1 CPU 1 PCIe Port3A 5D/00/ 5E/00/0 FHHL Slot 2 CPU 1...

  • Page 45: Fans

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description ⚫ When the input voltage ranges from 100 V AC to 127 V AC, the output power decreases to 1000 W. ⚫ Two 1500 W AC Platinum PSUs can serve as 1700 W PSUs.
  • Page 46 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Figure 5-25 Fan module positions 2022-06-25...

  • Page 47: Boards

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description 5.10 Boards 5.10.1 Mainboard Figure 5-26 2298 V5 mainboard UID button/indicator (S1) Management network port + serial port (J13) LOM GE port (J11) TPM/TCM port (TPM CONN/J55) VGA connector (VGA...
  • Page 48 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description (OCP CARD/J5) (REAR BOARD/J186) CPU 1 slimline connector CPU 1 slimline connector (CPU0 PORTA/J181) (CPU0 PORTB/J170) Rear-drive backplane power Rear-drive backplane connector (PWR OUT/J172) management connector (REAR HDD BP/J164) Fan 5 port (FAN4/J143)

  • Page 49: Drive Backplane

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description 5.10.2 Drive Backplane Front Drawer Drive Backplane Figure 5-27 Front drawer drive backplane (BOM 03025YVL) Drive connector (J20) Backplane management signal cable connector (J1) Slimline connector (PORT A) Drive identification indicator...
  • Page 50 FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description Rear-Drive Backplane Figure 5-28 Rear-drive backplane (BOM 03024BPV) Power connector (REAR BP mini-SAS HD connector (Port POWR3/J22) A/J2) Slimline A connector Slimline B connector (SLIMLINE A/J8) (SLIMLINE B/J9) Backplane signal cable...

  • Page 51: Psu Backplane

    FusionServer 2298 V5 Server Technical White Paper 5 Hardware Description 5.10.3 PSU Backplane Figure 5-29 2298 V5 PSU backplane Backplane power connector Backplane power connector (J11) (J10) Backplane power connector Backplane power connector (J9) (J8) Mainboard power connector PSU signal connector (J5)

  • Page 52: Product Specifications

    FusionServer 2298 V5 Server Technical White Paper 6 Product Specifications Product Specifications 6.1 Technical Specifications 6.2 Environmental Specifications 6.3 Physical Specifications 6.1 Technical Specifications Table 6-1 Technical Specifications Component Specifications Form factor 2U rack server ® Chipset Intel C622 Processor Supports one or two processors.
  • Page 53 FusionServer 2298 V5 Server Technical White Paper 6 Product Specifications Component Specifications ⚫ RDIMM and LRDIMM support ⚫ The DDR4 memory modules of different types (RDIMM and LRDIMM) and specifications (capacity, bit width, rank, and height) cannot be used together.
  • Page 54 FusionServer 2298 V5 Server Technical White Paper 6 Product Specifications Component Specifications drive. Network Supports expansion capability of multiple types of networks. ⚫ Supports two 10GE optical ports and two GE electrical − ports via the NIC chip integrated on the mainboard.

  • Page 55: Environmental Specifications

    FusionServer 2298 V5 Server Technical White Paper 6 Product Specifications Component Specifications NOTE ⚫ SM750 is not supported by servers running the Windows Server 2019 or Windows Server 2019 Hyper-V operating systems that are in secure boot mode. ⚫ The integrated video card can provide the maximum display resolution (1920 x 1200) only after the video card driver matching the operating system version is installed.
  • Page 56 FusionServer 2298 V5 Server Technical White Paper 6 Product Specifications Category Specifications ⚫ Maximum change rate: 20%/h ≥ 110 cubic feet per minute (CFM) Air volume ≤3050m Operating altitude ⚫ When the server configuration complies with ASHRAE Classes A1 and A2 and the altitude is above 900 m (2952.76 ft), the highest operating temperature decreases by...

  • Page 57: Physical Specifications

    FusionServer 2298 V5 Server Technical White Paper 6 Product Specifications ⚫ 3 months in power-off state with data stored ⚫ Maximum preservation duration of HDDs: ⚫ 6 months in unpacked/packed and powered-off state ⚫ The maximum preservation duration is determined according to the preservation specifications provided by drive vendors.
  • Page 58 FusionServer 2298 V5 Server Technical White Paper 6 Product Specifications Item Description Fully-equipped drives: 24 x 3.5" front drives + 4 x 2.5" rear drives + 2 x M.2 SSDs ⚫ Packaging materials: 5 kg (11.02 lb) Energy consumption The power consumption parameters vary with server configurations, including the configurations complying with energy-related products (ErP) requirements.

  • Page 59: Software And Hardware Compatibility

    FusionServer 2298 V5 Server Technical White Paper 7 Software and Hardware Compatibility Software and Hardware Compatibility Use the Compatibility Checker to obtain information about the operating systems and hardware supported. ⚫ If incompatible components are used, the device may be abnormal. This fault is beyond the scope of technical support and warranty.

  • Page 60: Safety Instructions

    FusionServer 2298 V5 Server Technical White Paper 8 Safety Instructions Safety Instructions 8.1 Security 8.2 Maintenance and Warranty 8.1 Security General Statement ⚫ Comply with local laws and regulations when installing devices. These Safety Instructions are only a supplement. ⚫...
  • Page 61 FusionServer 2298 V5 Server Technical White Paper 8 Safety Instructions Figure 8-1 Safety work wear ⚫ Before touching a device, wear ESD clothing and gloves (or wrist strap), and remove any conductive objects (such as watches and jewelry). Figure 8-2 shows conductive objects that must be removed before you touch a device.
  • Page 62 FusionServer 2298 V5 Server Technical White Paper 8 Safety Instructions Figure 8-3 Wearing an ESD wrist strap ⚫ Exercise caution when using tools. ⚫ If the installation position of the device is higher than the shoulders of the installation personnel, use a vehicle such as a lift to facilitate installation. Prevent the equipment from falling down and causing personal injury or damage to the equipment.

  • Page 63: Maintenance And Warranty

    FusionServer 2298 V5 Server Technical White Paper 8 Safety Instructions transported is always kept upright. Take necessary precautions to prevent collisions, corrosion, package damage, damp conditions and pollution. ⚫ Transport the equipment in its original packaging. ⚫ If the original packaging is unavailable, package heavy, bulky parts (such as chassis and blades) and fragile parts (such as PCIe GPUs and SSDs) separately.

  • Page 64: System Management

    FusionServer 2298 V5 Server Technical White Paper 9 System Management System Management The server uses the next-generation Intelligent Baseboard Management Controller (iBMC) to implement remote server management. The iBMC complies with IPMI 2.0 and provides highly reliable hardware monitoring and management.
  • Page 65 FusionServer 2298 V5 Server Technical White Paper 9 System Management Specifications Description Setting of boot device Supports out-of-band configuration for the boot device. Alarm management Supports alarm management and reports alarms using the SNMP trap, SMTP, and syslog service to ensure 24/7 operating.

  • Page 66: Certifications

    FusionServer 2298 V5 Server Technical White Paper 10 Certifications Certifications Country/Region Certification Standards Europe WEEE 2012/19/EU Europe REACH EC NO. 1907/2006 Europe Safety: EN 62368-1:2014+A11:2017 EMC: EN 55032:2015+A11:2020 CISPR 32:2015+A1:2019 EN IEC 61000-3-2:2019+A1:2021 EN 61000-3-3:2013+A1:2019 EN 55035:2017+A11:2020 CISPR 35:2016 EN 55024:2010+A1:2015 CISPR 24:2010+A1:2015 ETSI EN 300 386 V1.6.1:2012...
  • Page 67 FusionServer 2298 V5 Server Technical White Paper 10 Certifications Country/Region Certification Standards CISPR 35:2016 EN 55024:2010+A1:2015 CISPR 24:2010+A1:2015 ETSI EN 300 386 V1.6.1:2012 ETSI EN 300 386 V2.1.1:2016 RoHS: BS EN IEC 63000:2018 ErP: Commission Regulation(EU) 424/2019 FCC PART 15...

  • Page 68: A Appendix

    FusionServer 2298 V5 Server Technical White Paper A Appendix Appendix A.1 Chassis Label The label information and location are for reference only. For details, see the actual product. A.1.1 On the Front Top Figure A-1 Chassis head label Nameplate Certificate...
  • Page 69 FusionServer 2298 V5 Server Technical White Paper A Appendix device. A.1.1.1 Nameplate Figure A-2 Nameplate example Table A-1 Nameplate description Description Server Model For details, see A.4 Nameplate . Device names Power Supply Requirements Vendor Information Authentication ID A.1.1.2 Certificate...
  • Page 70 FusionServer 2298 V5 Server Technical White Paper A Appendix Table A-2 Certificate of conformity description Description Order NOTE For details, see Figure A-4 and Table A-3. QC inspector Production date No. Barcode Figure A-4 Sample certificate number Table A-3 Certificate No. Description Description "P", fixed...
  • Page 71 FusionServer 2298 V5 Server Technical White Paper A Appendix Description ⚫ Letters A to H indicate 10 to 17:00. ⚫ Letters J to N indicate 18 to 22:00. ⚫ Letters P to Q indicate 23 to 24:00. Serial number (2 digits) Manufacturing serial number (5 digits).
  • Page 72 FusionServer 2298 V5 Server Technical White Paper A Appendix A.1.2 Chassis Tail Label Figure A-6 Chassis tail label For details about the warning label, see Server Security Information. A.1.3 Chassis Internal Label Figure A-7 Chassis internal label ⚫ The quick guide is located on the inside of the chassis cover. It describes how to remove the mainboard components, important components of the chassis, precautions, and QR codes of technical resources.
  • Page 73 FusionServer 2298 V5 Server Technical White Paper A Appendix Figure A-8 Example SN Table A-5 SN description Description ESN ID (two characters), which can only be 21. Material ID (eight characters), that is, the processing code. Vendor code (two characters), that is, the code of the processing place.
  • Page 74 FusionServer 2298 V5 Server Technical White Paper A Appendix A.4 Nameplate Certified Model Usage Restrictions H22S-05 Global A.5 RAS Features The server supports a variety of Reliability, Availability, and Serviceability (RAS) features. You can configure these features for better performance.
  • Page 75 FusionServer 2298 V5 Server Technical White Paper A Appendix Module Feature Description Reporting mechanism to improve server serviceability. Intel UPI Link Level Retry Provides a retry mechanism to improve the reliability of UPI links. Intel UPI Protocol Protection Provides cyclic redundancy check (CRC)
  • Page 76 FusionServer 2298 V5 Server Technical White Paper A Appendix A.6 Sensor List Sensor Description Component Inlet Temp Air inlet temperature Left mounting ear Outlet Temp Air outlet temperature Mainboard PCH Temp PCH bridge temperature Mainboard CPUN Core Rem CPU core temperature...
  • Page 77 FusionServer 2298 V5 Server Technical White Paper A Appendix Sensor Description Component number. The value is 1 or 2. CPUN VCCIO CPU VCCIO voltage Mainboard N indicates the CPU number. The value is 1 or 2. CPUN VMCP CPU VMCP voltage...
  • Page 78 FusionServer 2298 V5 Server Technical White Paper A Appendix Sensor Description Component number. The value is 1 or 2. CPUN Prochot CPU Prochot CPUN N indicates the CPU number. The value is 1 or 2. System Error System suspension or Mainboard restart.
  • Page 79 FusionServer 2298 V5 Server Technical White Paper A Appendix Sensor Description Component Riser1 Card Entity presence Riser card SAS Cable Entity presence SAS cable on the mainboard FANN Presence Fan presence Fan moduleN N indicates the fan module number. The value ranges from 1 to 5.
  • Page 80 FusionServer 2298 V5 Server Technical White Paper A Appendix Sensor Description Component PS$ Inlet Temp PSU air inlet temperature PSUs OCP1 OP Temp OCP 2.0 mezzanine card OCP 2.0 mezzanine card optical module temperature optical module temperature OCP1 Temp OCP 2.0 mezzanine card OCP 2.0 mezzanine card...

  • Page 81: B Glossary

    FusionServer 2298 V5 Server Technical White Paper B Glossary Glossary B.1 A-E ejector lever A part on the panel of a device used to facilitate installation or removal of the device. Ethernet A baseband local area network (LAN) architecture developed by Xerox Corporation by partnering with Intel and DEC.
  • Page 82 FusionServer 2298 V5 Server Technical White Paper B Glossary B.3 K-O A hardware device that provides public keyboard, video and mouse (KVM). B.4 P-T panel An external component (including but not limited to ejector levers, indicators, and ports) on the front or rear of the server.
  • Page 83 FusionServer 2298 V5 Server Technical White Paper B Glossary B.5 U-Z A unit defined in International Electrotechnical Commission (IEC) 60297-1 to measure the height of a cabinet or chassis. 1 U = 44.45 mm UltraPath A point-to-point processor interconnect developed by Intel.

  • Page 84: C Acronyms And Abbreviations

    FusionServer 2298 V5 Server Technical White Paper C Acronyms and Abbreviations Acronyms and Abbreviations C.1 A-E alternating current Advanced Encryption Standard New Instruction Set Address Resolution Protocol Advanced Vector Extensions backup battery unit BIOS Basic Input/Output System calendar day Conformite Europeenne...
  • Page 85 FusionServer 2298 V5 Server Technical White Paper C Acronyms and Abbreviations DDR3 Double Data Rate 3 DDR4 Double Data Rate 4 DDDC double device data correction DEMT Dynamic Energy Management Technology DIMM dual in-line memory module DRAM dynamic random-access memory...
  • Page 86 FusionServer 2298 V5 Server Technical White Paper C Acronyms and Abbreviations high availability hard disk drive high-performance computing HTTP Hypertext Transfer Protocol HTTPS Hypertext Transfer Protocol Secure iBMC intelligent baseboard management controller Industry Canada ICMP Internet Control Message Protocol Internet Data Center...
  • Page 87 FusionServer 2298 V5 Server Technical White Paper C Acronyms and Abbreviations LAN on motherboard media access control module management controller next business day NC-SI Network Controller Sideband Interface C.4 P-T PCIe Peripheral Component Interconnect Express power distribution unit physical layer...
  • Page 88 FusionServer 2298 V5 Server Technical White Paper C Acronyms and Abbreviations REACH Registration Evaluation and Authorization of Chemicals RJ45 registered jack 45 RoHS Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Serial Attached Small Computer System Interface...
  • Page 89 FusionServer 2298 V5 Server Technical White Paper C Acronyms and Abbreviations TFTP Trivial File Transfer Protocol TCP offload engine trusted platform module C.5 U-Z UDIMM unbuffered dual in-line memory module UEFI Unified Extensible Firmware Interface unit identification light Underwriter Laboratories Inc.
