- Page 1 PRODUCT GUIDE Network Pro ONE Product Guide Document # WT 9810_i1 Issue date: December 2023 ® is a registered Trademark of AoFrio Ltd. AoFrio Ltd +64 9 477 4500 sales@aofrio.com www.aofrio.com...
- Page 2 User Manager software. To use AoFrio’s Field app as part of the configuration process, the Network Pro ONE needs to be activated to the database that you are working in and registered in the Cloud. If not activated, then it’s possible you won’t be able to see the device in the Field app’s list of...
- Page 3 Important do’s and don’ts: Correct disposal The Network Pro ONE is subject to EU Directive 2012/19/ EU (WEEE) for e-waste. It may also be subject to other national legislation for the safe disposal of e-waste. The Network Pro ONE must not be disposed of in municipal The Network Pro ONE must •...
- Page 4 Introduction The Network Pro ONE is one of the communications devices in the AoFrio Connect IoT system. It provides real-time automated data acquisition for one asset from AoFrio SCS controllers, Monitors and Clicks installed in your assets in the field, adding a cellular connectivity option to the existing portfolio of data acquisition solutions provided by AoFrio.
-
Page 5: How It Works
Network Pro ONE is an advanced communications gateway that collects data from the AoFrio IoT device within your asset and uploads it to the AoFrio Cloud Platform. It connects to the entire suite of AoFrio Connect IoT devices using Bluetooth. It then uploads all the data to the AoFrio Cloud using a cellular data connection. -
Page 6: Key Features
The battery life is approximately 12 hours during which time of manufacture and the data plan is managed by time the Network Pro ONE will continue to operate fully as AoFrio. if it was still connected to its external power supply. - Page 7 AoFrio AC to DC power supply • Hardware (screws, cable ties, tape etc) to mount the Network Pro ONE and AC/DC power supply Product label & QR code The Network Pro ONE product identification label contains product information and a QR code.
-
Page 8: Commissioning & Configuration
If the SIM remains inactive prior to the asset's field installation, it will be activated if the Network Pro ONE is paired with a device using the AoFrio Field app. This may take several days depending on the scenario and timing. - Page 9 Access - Access to Network Pro ONE features inside Report app are controlled by your Role settings within the • AoFrio User Manager app. If your Role type does not include the Network Pro ONE permissions, then you will not have access to the feature.
- Page 10 Report app feature Details / Screenshots Access all the Network 1. In the left-hand menu, click System, then click AoFrio Network Pro ONE. Pro devices in the customer account. 1. In the left-hand menu, click System, then click AoFrio Network Pro.
- Page 11 Details / Screenshots Report app feature Search by Network 1. In the left-hand menu, click System, then click AoFrio Network Pro. serial number, 2. Select a Network Pro serial number to see details for the Network Pro and all customer ID, outlet Connect IoT devices it has connected to.
-
Page 12: Over-The-Air (Ota) Firmware Updates
AoFrio Support staff will only deploy new firmware after comprehensive testing has been completed. Customers may not be notified of new firmware deployments ahead of time. Network Pro ONE will check the AoFrio Cloud every 24 hours for firmware updates and will download any new version of firmware that is available. -
Page 13: Technical Specifications
1m cable • Output 5V DC 2.0A, 2m cable • Input 4.5V – 6.4V DC, 300mA max Network Pro ONE Cellular communications LTE Cat M1 with 2G (GPRS) fallback B1, B2, B3, B4, B5, B8, B12, B13, B18, Cellular bands B19, B20, B25, B28, B39 Bluetooth (BLE 4.1) - Page 14 Network Pro ONE Product Guide WT9810, issue 1, December 2023 www.aofrio.com...
