- Page 1 USER MANUAL SCS Click Document # WT9758_i1 Issue date: March 2023 ® is a registered Trademark of AoFrio Ltd AoFrio Ltd. P:+64 9 477 4500 E:sales@aofrio.com www.aofrio.com...
- Page 2 SCS CLICK (where such a relationship may exist), no liability, responsibility or risk is accepted in determining if the SCS CLICK is fit for purpose for any particular application. no liability, responsibility, or risk is accepted by AoFrio for the correct operational function of any particular installation or configuration.
- Page 3 Warnings continued Correct disposal The SCS Click must not be The SCS CLICK is subject to EU Directive 2012/19/EU (WEEE) for e- disposed of in municipal waste. It may also be subject to other national legislation for the safe collections; it must be disposal of e-waste.
- Page 4 Introduction The SCS CLICK is a Bluetooth LE transmission adaptor designed for providing radio connectivity to existing refrigeration controllers in the market. It adds functionality such as telemetry connectivity, asset tracking, and proximity-based marketing to existing coolers. A unique feature is a mobile app that gives authorized Service Technicians full wireless access to...
- Page 5 Remove the two screws holding the RJ45 cover in place with PZ1 screwdriver and remove cover Step 2 Push SCS Click fully into the RJ45 socket. Ensure it makes a Click sound, and the retaining feature is clicked into place.
-
Page 6: Installation
Installation EMS55 Setup process To set up EMS55 – follow these seven steps: Step 1 Press the top left button (“a“) and the device will be setup for the password. Step 2 Enter the password by pressing the buttons on the controller in the following order. - Page 7 Installation Step 5 Press the Top Left (“a“) button once. The display will continue alternating between displaying “ddP’ and “00”. Step 6 Hold the Top right (“b“) button until “01” is displayed. The display will now alternate between displaying “ddP’ and “01”. Step 7 Wait for 20-30 secs for the Elstat to timeout.
- Page 8 Area inside the outlet where the cooler is located, showing enough of the surroundings to • understand the cooler’s in-store position 2. Turn on the Field app on your mobile device or phone. 3. Connect the Field app to the SCS Click. 4. Set the following details: Model Number (Used for recording purposes) •...
- Page 9 Graphical User Interfaces (GUI) The AoFrio SCS Connect Track App provides a wireless connection to the SCS Click from mobile devices fitted with Bluetooth® LE. This gives users and technicians an unprecedented level of visibility and control. Note: Screen shots shown are indicative only. Different devices have different screen ratios, sizes, and resolutions.
- Page 10 Step 2 When you first run “Connect Field”, you will be requested to enter an activation code. Contact your User Manager or AoFrio to receive your activation code (You must be connected to the internet at the time of activation).
- Page 11 Install and authenticate the app Step 4 You can see which databases you are activated against from the “Settings” screen. You can be activated to more than one database at the same time. Simply select “ACTIVATE ANOTHER DATABASE”, and enter the new databases unique activation code, as in Step 2.
-
Page 12: Home Screen
Home Screen The Home Screen shows a graphic representation of the current state of the refrigeration unit being controlled. Fridge Status Main menu... - Page 13 Add your cooler to the Field app Step 1 Open the Field app menu and click SCS SETUP. Step 2 (Optional) Click LOAD FILE to upload a manufacturer parameter file. Select the file from the dropdown list then click Step 3 To set the MANUFACTURER, select the cooler manufacturer from the dropdown list then click...
- Page 14 Add your cooler to the Field app Step 4 To set the COOLER OWNER, click EDIT in the matching field and select the cooler owner from the dropdown list. Click SAVE to confirm and click OK to accept. Step 5 To add an ASSET NUMBER, add the number manually, or scan the asset number barcode using the phone’s camera.
-
Page 15: Show On Map
Add your cooler to the Field app Step 7 (Optional) To add the Manufacturer Serial Number, click EDIT and add the number manually, or scan the Asset number barcode using the phone’s camera. Click SAVE to confirm and click OK to accept. Step 8 To add an installation address, click INSTALL ADDRESS and continue with the following... - Page 16 Add your cooler to the Field app Step 10 (Optional) If the Google address is not correct, enter the address manually in the text box then drag the yellow marker around the map screen to position the cooler’s exact location. Double tap the map screen to fix the cooler’s exact location with a yellow marker.
- Page 17 Add your cooler to the Field app Step 13 Enter CUSTOMER ID manually or scan the barcode number using the phone’s camera. (Optional) Enter the SALES ROUTE and TECH ROUTE. Click in the field below ORG UNIT and select your organisation position from the dropdown list.
- Page 18 Once you are happy with the information you have entered, open the menu and click DISCONNECT to complete the process. Note: It is important to complete the disconnect step to ensure that all asset data is properly stored in the SCS Click.
-
Page 19: Upgrade Firmware
Upgrade Firmware Firmware can be updated from either the mobile or desktop app. The steps are the same for both. Screenshots used are from the mobile app, but look the same on the desktop app. Firmware update screen... -
Page 20: Firmware Update Process
Firmware update process Step 1 When you see a FIRMWARE UPDATE notification, click CLOUD STORE. Step 2 Select the file you want to update from the dropdown list and click DOWNLOAD. Note: If you see SCS CLICK_OTA, these are Main micro files. Step 3: Click START SCAN then select the SCS CLICK device to upgrade. -
Page 21: Technical Specifications
Android with BT 4.0 and OS 4.4.3 or above iPhone 4S or later iPAD 3rd Gen or later iPAD mini Physical Dimensions SCS Click Overall Dimensions: 10.8mm (H) x 11.7mm (W) x 17.6mm (D) Weight 2g (0.07oZ) Activity Indicators LED Indicator... - Page 22 Technical specifications Compliance and approvals Fire Rating UL94-V0 Electrical Insulation Rating Class II (when correctly installed) Compliance** cUL, FCC and CE-RED Ingress Protection IP 40 (weather protection provided by EMS) Immunity: EN6100-6-2, EN 301 489-1, EN301 489-17 Emissions: EN55014-1 , EN301 489-17 , EN300 328 V1.8.1 EN50371 FCC Part 15B and 15C EN 300 328...
-
Page 23: Fcc Declaration
FCC Declaration CLASS B DEVICE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. - Page 24 FCC Declaration RSS-102 Statement This equipment complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment. Cet équipement est conforme à l’exposition aux rayonnements Industry Canada limites établies pour un environnement non contrôlé.
- Page 25 SCS Click user manual WT9758_i1 Issue date: March 2023 www.aofrio.com...
