Welcome to the world of sophisticated, early warning laser/radar
detection. You have purchased one of the most advanced laser/radar
detectors available. The LRD 2200SWS is a complete integrated
laser/radar detector. It responds to the X-, K-, and Ka-SuperWideband
radar guns in use today and also provides 360° detection of the latest
speed monitoring system — the laser gun. The built-in Safety Warning
System (SWS™) is capable of detecting a hazardous warning signal
transmitted on the K-band.
The LRD 2200SWS provides distinct visual and audio alerts to warn you
of the presence of X-, K-, and Ka-SuperWideband radar signals as well as
IR laser signals. You can drive with confidence when you bring along the
LRD 2200SWS.
The LRD 2200SWS employs Super Stalker Technology (SST), a
state-of-the-art electronic system designed to make this radar detector
invisible to all current VG-2 radar detector detectors. The LRD 2200SWS
also uses the new D.R.O. (Dielectric Resonant Oscillator) and E.D.I.T.
(Electronic Data Interference Terminator) circuitry, giving more reliable
performance.
We are certain that you will enjoy the LRD 2200SWS, and to ensure that
you get the most from its features, please read this Operating Guide
carefully before installing and operating the unit.
Feature Highlights
360° Laser Detection
Complete 4-Band Coverage
Super Wideband
K/Ka Priority
Signal Strength Meter
Visual Only Mode
Audio Only Mode
Memory Retention Feature
Introduction
Safety Warning System™
4 Alarm Tones
VG-2 Undetectable
Pulse Detection
Warning Lights
Auto Mute Mode
Self Test
City and Highway Modes
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Uniden LRD2200SWS
Summary of Contents for Uniden LRD2200SWS
-
Page 1: Introduction
The LRD 2200SWS employs Super Stalker Technology (SST), a state-of-the-art electronic system designed to make this radar detector invisible to all current VG-2 radar detector detectors. The LRD 2200SWS also uses the new D.R.O. (Dielectric Resonant Oscillator) and E.D.I.T. (Electronic Data Interference Terminator) circuitry, giving more reliable performance. -
Page 2: Speed Detection Systems
Speed Detection Systems A speed detection device (often called a radar gun) sends out either a microwave signal or beam of light. When this signal reaches its target, part of the signal is reflected or bounced back toward the emitting gun. The time required for the signal to leave the gun, bounce off an object, and return is used to determine a vehicle’s distance and speed. -
Page 3: Laser
Laser The Laser Speed Detection System, also called LIDAR (for Light Detection and Ranging), uses a laser gun that emits infrared light pulses just outside the spectrum of visible light. Each reflected pulse measures the speed of the object coming toward or going away from the laser gun. Unlike radar, the laser gun emits a very narrow beam of light, so it can pinpoint a speeding car within traffic. -
Page 4: Included With Your Radar Detector
Included with Your Radar Detector Windshield Owner’s Guide Clip Printed Straight Power Cord Material Coiled Cigarette Fuses and Adapter Spare Parts If any of these items are missing or damaged, contact your dealer immediately. Be sure to complete and mail the Product Registration Card. -
Page 5: Controls And Functions
DC 12V Power Input — Connect the DC power cord here. Note: Use on a Uniden® supplied power cord or its replacement. D C 1 2 V... - Page 6 LED Display — LEDs display visual alerts, signal strength, and operation mode. On-Off/Volume Control — Turns the power on and adjusts the Audio Alert volume. Speaker — Sounds audio alert. There are four different audio alert tones to distinguish each type of signal received. When you become familiar with all the distinct alert tones, you can operate the LRD 2200SWS just by listening, devoting your full attention to the traffic in front of you.
- Page 7 X K Ka L 1 2 3 4 5 6 X-Band Signal Indicator — A green LED lights and blinks to indicate the presence of an X-band radar signal. The blink rate increases as the radar source gets closer. A distinct audio alert is also heard.
-
Page 8: Installation
Both radar waves and IR laser light will, however, pass through plastic or glass. Before you decide where to put your radar detector, please keep in mind these two important factors: For safety, do not mount the LRD 2200SWS in a location where it will obstruct your driving vision. -
Page 9: Adjusting The Windshield Mounting Clip
Adjusting the Windshield Mounting Clip The metal portion of the bracket locks into the plastic portion at three different positions. These positions can be used for vehicles with different vertical angles of their windshields. The back position can be used for vehicles with windshields that are slanted back. -
Page 10: Connecting The Power
Connecting the Power Direct Connection The LRD 2200SWS is designed to operate on most 12V DC negative ground vehicle electrical systems. The straight power cord provided with the unit has bare wires at one end, and a small connector at the other end. Connect the positive wire to a 12V DC source in your vehicle’s fuse box. -
Page 11: Using The Coiled Cigarette Adapter
Run the power cord from the fuse box to the LRD 2200SWS. Your unit also comes with power cord mounting clips. You can use these clips to attach the power cord to the dashboard or other parts of the vehicle, keeping it neat and out of the way. Use the double-sided foam tape squares to attach each clip. -
Page 12: Replacing The Fuse
When installing the power cord, make sure that: The socket is clean to allow proper contact. The power cord does not block the antenna area on the back of the unit. Your unit also comes with ten power cord mounting clips. You can use these clips to attach the power cord to the window frame or other parts of the vehicle, keeping it neat and out of the way. -
Page 13: Operation
Operation You are now ready to enjoy the convenience and security of your LRD 2200SWS. Please read this section of the Operating Guide carefully to familiarize yourself with the basic operation of this unit. Power On Turn the Volume control to switch on the power. When you power up the LRD 2200SWS, it performs a self-test of all its circuits. -
Page 14: Memory Retention Feature
Memory Retention Feature The Memory Retention Feature retains the LRD 2200SWS’s operational settings in memory for at least 2 days without power. When you turn on the LRD 2200SWS, it will be in the same mode as when you turned it off. Full Warning When the LRD 2200SWS detects a radar, laser, or safety warning signal, it emits a distinct warning tone and the corresponding alert LEDs... -
Page 15: Visual Alert Only Operation
Visual Alert Only Operation You can operate the LRD 2200SWS in Visual Alert Only by setting the Volume control at the minimum position in Full Alert Mode. At this setting you can barely hear the audio alert in a quiet environment. Be sure that the Audio Alert Only indicator is off. -
Page 16: City Operation
City Operation In highly populated areas, you may encounter many devices that use the same frequencies as radar signals, such as motion detectors, automatic doors, and intrusion alarms. These devices may trigger an alert called “falsing.” To filter most of the weaker signals and get the most accurate radar signal recognition, press CITY to turn on the City Mode. -
Page 17: Led Signal Strength Meter In City Mode
LED Signal Strength Meter in City Mode The LED signal strength meter gives you instant information about the strength of the signal being detected. A weak signal causes the first LED to light, but as signal strength increases, more LEDs light. All four LEDs light when full signal strength is received. -
Page 18: Care And Maintenance
Care and Maintenance The LRD 2200SWS is designed to give you years of trouble-free service. There are no user-serviceable parts inside, and, except for the fuse, no maintenance is required. To keep your detector in new condition, follow these important suggestions: Never leave the LRD 2200SWS on the windshield when you park your vehicle. -
Page 19: Troubleshooting
If your LRD 2200SWS does not perform up to expectations, try the suggestions listed below. If you cannot get satisfactory results, call the Uniden Customer Service Center at (800) 297-1023, 8:00 a.m. to 5:00 p.m. Central Time, Monday through Friday. -
Page 20: Specifications
Temperature Range: 360° Laser Detector Receiver Type: Sensor Front End: Detector Type: Receiver Bandwidth: Spectral Response: Alert Hold Time: Radar Detector Receiver Type: Detector Type: Antenna Type: Sensitivity: Frequency of Operation: Specifications are subject to change without notice. Specifications in. (W) x 4 3.5 oz. -
Page 21: Optional Accessories & Replacement Parts
Optional Accessories & Replacement Parts Windshield Printed Material Clip Owner’s Straight Power Cord Guide Coiled Cigarette Fuses and Adapter Spare Parts... - Page 22 ® LRD 2200SWS Operating Guide USZZ01064BA...
- Page 23 Important: The LRD 2200SWS was not designed to help you disobey the law. Safe drivers always obey the posted speed limit and legal driving methods at all times. Federal and Local Regulations The FCC passed the Communications Act in 1934 to give all citizens the right to receive any type of radio transmission.
-
Page 24: Table Of Contents
Laser ..........3 Included with Your Radar Detector......4 Controls and Functions . -
Page 25: One Year Limited Warranty
(E) used in any conjunction with equipment or parts or as part of any system not manufactured by Uniden, or (F) installed or programmed by any- one other than as detailed by the Operating Guide for this product. - Page 26 Covered under one or more of the following U.S. patents: 4,622,553 4,698,632 4,709,407 4,791,420 4,831,498 5,315,302 ® ©1996 Uniden America Corporation. All rights reserved. Printed in the Philippines...
