Summary of Contents for GW Instek ASR-6000 Series
- Page 1 Multi-phase Programmable AC/DC Power Source ASR-6000 Series QUICK START GUIDE ISO-9001 CERTIFIED MANUFACTURER...
- Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company. The information in this manual was correct at the time of printing. However, Good Will continues to improve products and reserves the rights to change specification, equipment, and maintenance procedures at any time without notice.
-
Page 3: Table Of Contents
Table of Contents Table of Contents INTRODUCTION ............. 4 ASR-6000 Series Overview ........4 Appearance ............. 5 SET UP ................13 Input Terminal Connection ........13 Copper Plate Introduction ........13 Single Phase Connection ........14 Delta Connection ........... 15 Y Connection ............ -
Page 4: Introduction
NTRODUCTION ASR-6000 Series Overview Series lineup The ASR-6000 series consists of 2 models, the ASR-6450 and ASR- 6600, differing in capacity. Note that throughout the user manual, the term “ASR-6000” refers to any of the models, unless stated otherwise. 1P Output Condition Model Name Power Rating Max. -
Page 5: Appearance
INTRODUCTION Appearance Front Panel Programmable AC/DC Power Source 6450 Menu Test Preset V-Limit F-Limit IPK-Limit Mode I rms Range On Phase Phase IPK CLR Shift Off Phase ALM CLR Cancel Wave Hardcopy Unlock Local Enter Output Lock : Long Push Item Index Description Power switch button... - Page 6 ASR-6000 Series Quick Guide Cancel key Enter key Irms/IPK-Limit button Lock/Unlock button F/F-Limit button V/V-Limit button Numerical Keypad with additional “Shift + key” shortcut functions (green zone) Air inlet Item Description Power Switch Turn on the mains power USB A Port The USB port is used for data transfers and upgrading software.
- Page 7 INTRODUCTION Menu Key Enters the Main menu or goes back to one of the display modes. Test Key Puts the instrument into the Sequence and Simulation control mode. Preset Key Puts the instrument into Preset mode. Arrow Keys The arrow keys are used to select the digit power of a value that is being edited.
- Page 8 ASR-6000 Series Quick Guide Enter Key Confirms selections and settings. Irms Used for setting the maximum output current. IPK-Limit + Used to set the peak output current limit value. Lock/Unlock Key Used to lock or unlock the front panel keys except output key. Simply press to lock, whilst long press to unlock.
- Page 9 INTRODUCTION On Phase + Sets the on phase for the output voltage. Off Phase + Sets the off phase for the output voltage. Output + Selects between the Sine, Square, Waveform Triangle and ARB 1~16 waveforms (not available for DC-INT, AC+DC-EXT and AC-EXT).
- Page 10 ASR-6000 Series Quick Guide Rear Panel SENSING RS232C EXT I/O L3 N3 OUTPUT AC 0 350V 1 2kHz 500V 500V 3P 1P3W GPIB INPUT 1 /3 200 240V :L-L 47 63Hz 8kVA MAX. :L-N Item Index Description Output terminal AC power input terminal...
- Page 11 INTRODUCTION Item Description Output Terminal Output terminal (M4 screw type, 8 ~ 18 AWG) (Screw torque value:18kgf-cm) AC Power Input AC inlet Terminal (M4 screw type, 8 ~ 18 AWG) (Screw torque value:18kgf-cm) Remote sensing input terminal is Remote Sensing for compensation of load wire Input Terminal voltage drop.
- Page 12 ASR-6000 Series Quick Guide RS232C The RS232C connector for Connector controlling the ASR-6000 remotely. Ethernet LAN The Ethernet port is used for Port remote control. USB B-type Port USB port for controlling the ASR- 6000 remotely. Optional GPIB The optional GPIB connector for Connector controlling the ASR-6000 remotely.
-
Page 13: Set Up
SET UP ET UP Input Terminal Connection Basically, the input terminal, which is located in Background the rear panel of ASR unit, can be connected through 3 methods: Single Phase, Delta and Y Connection. Depending on varied input connections, use the corresponding cooper plates and power cords for connection. -
Page 14: Single Phase Connection
ASR-6000 Series Quick Guide Single Phase Connection 1. Assemble the two Steps copper plates specific for Single phase input connection with the AC input terminals. The first plate is for L1, L2 and L3 terminals, while the other plate is for N1, N2 and N3 terminals. -
Page 15: Delta Connection
SET UP Delta Connection 1. Assemble the three Steps copper plates specific for Delta input connection with the AC input terminals. The 1 plate is for N3 and L1 terminals. The second plate is for L3 and N2 terminals, while the 3 plate is for L2 and N1 terminals. -
Page 16: Y Connection
ASR-6000 Series Quick Guide Y Connection 1. Assemble the copper Steps plate specific for Y input connection with the AC input terminals. The copper plate is for N1, N2 and N3 terminals. 2. Connect the AC power cords to the AC input terminals. -
Page 17: Output Terminal Connection
SET UP Output Terminal Connection The output terminal can output power in three Background mode: 1P2W, 1P3W and 3P4W. Select applicable output mode, via panel configurations, in accordance with varied applications. Be aware of dangerous voltages. Ensure that the WARNING power to the instrument is disabled before handling the power supply output terminals. - Page 18 ASR-6000 Series Quick Guide 3. Connect the output wires to the AC output terminals as follows: Red Line (L) Black Neutral (N) The input & output terminals necessitate Note connectivity through ring-type connectors. For the specific installation on protective lid of output terminal, please refer to User Manual.
-
Page 19: 1P3W Output Connection
SET UP 1P3W Output Connection 1. Disconnect the unit from the mains power Steps socket and turn the power switch off. 2. Connect the output wires to the AC output terminals as follows: Yellow Line (L1) Green Line (L2) ... -
Page 20: 3P4W Output Connection
ASR-6000 Series Quick Guide 3P4W Output Connection 1. Disconnect the unit from the mains power Steps socket and turn the power switch off. 2. Connect the output wires to the AC output terminals as follows: Yellow Line (L1) ... -
Page 21: Miscellaneous
Firmware Update The ASR series firmware can be upgraded using Background the USB A port on the front panel. See your local distributor or the GW Instek website for the latest firmware information. Ensure the DUT is not connected. Note ... - Page 22 ASR-6000 Series Quick Guide 4. Key in the password when prompted and then press Enter. The password is “5004”. 5. Go to Item 1, Update Firmware and press Enter. Update Firmware Exit [F4] 6. Wait for the unit to update. Upon completion...
-
Page 23: Specifications
MISCELLANEOUS Specifications The specifications apply when the ASR-6000 is powered on for at least 30 minutes. Electrical specifications Model ASR-6450 ASR-6600 Input ratings Single-phase Power type Three-phase, Delta or Y connection selectable Voltage range 200 Vac to 240 Vac ±10 % phase voltage (Delta: L-L, Y: L-N) Frequency range 47 Hz to 63 Hz Power factor... - Page 24 ASR-6000 Series Quick Guide EN 61000-3-2/-3-12 (Class A, Group 1) EN 61000-3-3/-3-11 (Class A, Group 1) EN 61000-4-2/-4-3/-4-4/-4-5/-4-6/-4-8/-4-11/-4-34 (Class A, Group 1) EN 55011 (Class A, Group1) Safety EN 61010-1 Vibration, Shock and Transportation ISTA 2A Test Procedure Integrity Environment...
-
Page 25: Information Of Name Order
MISCELLANEOUS Information of Name Order The name order of ASR-6000 series has its rules in definition for each character by order. Refer to the following contents for details. The definitions below describe the meanings behind Background each group of alphanumeric characters, in varied colors, of naming code for ASR series models. -
Page 26: Asr-6000 Dimensions
ASR-6000 Series Quick Guide ASR-6000 Dimensions ASR-6450/6600 Scale = mm... -
Page 27: Declaration Of Conformity
MISCELLANEOUS Declaration of Conformity GOOD WILL INSTRUMENT CO., LTD. declare that the below mentioned product satisfies all the technical relations application to the product within the scope of council: Directive: EMC; LVD; WEEE; RoHS The product is in conformity with the following standards or other normative documents: ◎...
