Crestron SRD-ANT-8-PAK Antenna System: SRD-ANT-8-PAK Introduction The SRD-ANT-8-PAK is a high quality outdoor antenna system designed for use with up to eight Crestron two SRD-SPL-4 Four-Way Amplified Splitters enables distribution of the antenna signal to eight separate tuners while allowing the antenna to be positioned up to 310 feet (cable length) from the tuners, using standard RG-6 cable (not included).
Antenna System Block Diagram NOTE: In this typical layout example, the sum total of all the cable segments between the line amplifier output and the most distant radio should not exceed 310 feet. Specifications Following are specifications for the SRD-ANT-8-PAK. SRD-ANT-8-PAK Specifications (Continued on following page) 2 •...
Page 7
Crestron SRD-ANT-8-PAK SRD-ANT-8-PAK Specifications (Continued) 1. Specification is achieved with supplied 20 dB attenuator. 2. Depth is measured from the interface connector to the high point of the convex antenna cover. 3. Wall mount dimensions include the antenna mounting bracket. Installation Guide –...
Antenna System Included Items The items included with the SRD-ANT-8-PAK are listed in the following table and illustrated on the following page. SRD-ANT-8-PAK Included Items The items included with the SRD-AMP-1, SRD-SPL-4, and SRD-CPL-4, are listed in the following tables. SRD-AMP-1 Included Items SRD-SPL-4 Included Items SRD-CPL-4 Included Items...
Crestron SRD-ANT-8-PAK SRD-ANT-8-PAK, SRD-SPL-4, SRD-CPL-4, and SRD-AMP-1 Included Items Industry Compliance As of the date of manufacture, the SRD-ANT-8-PAK has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. Installation Guide – DOC. 6724A Antenna System Antenna System: SRD-ANT-8-PAK •...
Antenna System Installation Installation Notes Wall Mounting Attach the wall mount assembly to a flat surface. Use the supplied screws to secure the mount in the position desired (use of the included anchors requires 5/16” holes). Elevation and Azimuth Adjustments 6 •...
Crestron SRD-ANT-8-PAK Pole Mounting Attach the antenna to any pole (not larger than two inches in diameter) using the U-bolt and saddle with supplied attaching hardware as shown in the following figures. 2” DirecTV Pole NOTE: For operation in close proximity to high power satellite radio terrestrial repeaters, please use the supplied 20 dB power-passing attenuator on the input of the splitters to avoid amplifier overload.
Antenna System Aiming the Antenna Refer to the documentation supplied with the tuner/radio for information on observing signal strength. Adjust the antenna as required to maximize the signal. XM Reception XM has two satellites located in fixed orbital positions in the southern sky (at 115° W longitude and 85º...
Page 13
Crestron SRD-ANT-8-PAK Antenna System SIRIUS Antenna Aiming Areas, North America Antenna System: SRD-ANT-8-PAK • 9 Installation Guide – DOC. 6724A...
Antenna System Problem Solving Troubleshooting The table after this paragraph provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. SRD-ANT-8-PAK Installation Troubleshooting Further Inquiries If you cannot locate specific information or have questions after reviewing this guide, please take advantage of Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876].
Page 15
Crestron SRD-ANT-8-PAK updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision. Check the Crestron website periodically for manual update availability and its relevance. Updates are identified as an “Addendum” in the Download column. Installation Guide –...
Antenna System Appendix: Azimuth and Elevation Pointing Guide The following chart shows the optimum azimuth bearing and elevation pointing angles for locations throughout the US (below) and Canada (starting on page 14). The azimuth has been magnetically corrected. NOTE: Although in many locations it may be possible to receive signals from terrestrial repeaters, it is not recommended to use these signals at fixed locations.
Page 17
Crestron SRD-ANT-8-PAK SIRIUS and XM Satellite Azimuth and Elevation Angle Settings - US (Continued) CITY AZIMUTH ELEVATION AZIMUTH° St Louis 319.7 Billings 76.2 Kalispell 80.8 Winston-Salem 308.2 Minot 106.5 North Platte 33.8 Omaha 349.9 Cherry Hill 297.6 Albuquerque 33.1 Shiprock 41.9 Elco 61.0...
Page 18
Antenna System SIRIUS and XM Satellite Azimuth and Elevation Angle Settings - Canada CANADA CITY PR AZIMUTH° ELEVATION° AZIMUTH° ELEVATION° AZIMUTH° ELEVATION° Vancouver BC 78.4 Prince Rupert BC 81.4 Calgary AB 89.7 Edmonton AB 129.7 Saskatoon SK 109.0 Toronto ON 287.9 Ottawa ON 282.6 Montreal...
Crestron SRD-ANT-8-PAK Return and Warranty Policies Merchandise Returns / Repair Service 1. No merchandise may be returned for credit, exchange or service without prior authorization from CRESTRON. To obtain warranty service for CRESTRON products, contact an authorized CRESTRON dealer. Only authorized CRESTRON dealers may contact the factory and request an RMA (Return Merchandise Authorization) number.
Page 20
Crestron Electronics, Inc. Installation Guide – DOC. 6724A 15 Volvo Drive Rockleigh, NJ 07647 (2021914) Tel: 888.CRESTRON 08.08 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
