- Page 1 Crestron SRD-ANT-4-PAK Antenna System Installation Guide...
-
Page 2: Important Safety Instructions
This document was prepared and written by the Technical Documentation department at: Important Safety Instructions • Read and Retain Instructions – Read all Instructions before operating equipment and save for future reference. • Outdoor Antenna Grounding – The antenna and coaxial cable connecting to the unit should be properly grounded to provide protection against voltage surges and built-up static charges. -
Page 3: Table Of Contents
Crestron SRD-ANT-4-PAK Contents Antenna System: SRD-ANT-4-PAK Introduction...1 Block Diagram...2 Specifications...2 Included Items ...3 Industry Compliance...4 Installation ...5 Installation Notes ...5 Wall Mounting...5 Pole Mounting ...6 Hookup ...6 Aiming the Antenna...7 Problem Solving...8 Troubleshooting...8 Further Inquiries ...8 Future Updates...9 Appendix: Azimuth and Elevation Pointing Guide...10 Return and Warranty Policies ...13 Merchandise Returns / Repair Service...13 CRESTRON Limited Warranty...13... -
Page 5: Antenna System: Srd-Ant-4-Pak
Crestron SRD-ANT-4-PAK Antenna System: SRD-ANT-4-PAK Introduction The SRD-ANT-4-PAK is a high quality outdoor antenna system designed for use with up to four Crestron SRD-SPL-4 Four-Way Amplified Splitter enables distribution of the antenna signal to four separate tuners while allowing the antenna to be positioned up to 200 feet (cable length) from the tuners using standard RG-6 cable (not included). -
Page 6: Block Diagram
Antenna System Block Diagram NOTE: In this typical layout example, the sum total of all the cable segments between the antenna output and the most distant radio should not exceed 275 feet. Specifications Following are specifications for the SRD-ANT-4-PAK. SRD-ANT-4-PAK Specifications (Continued on following page) 2 •... -
Page 7: Included Items
Crestron SRD-ANT-4-PAK SRD-ANT-4-PAK Specifications (Continued) Included Items The items included in the SRD-ANT-4-PAK are listed in the following table and illustrated on the following page. SRD-ANT-4-PAK Included Items The items included with the SRD-SPL-4 are listed in the following table and are also illustrated on the following page. -
Page 8: Industry Compliance
Antenna System SRD-ANT-4-PAK and SRD-SPL-4 Included Items Industry Compliance As of the date of manufacture, the SRD-ANT-4-PAK has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. 4 • Antenna System: SRD-ANT-4-PAK Crestron SRD-ANT-4-PAK Installation Guide –... -
Page 9: Installation
Crestron SRD-ANT-4-PAK Installation Installation Notes Wall Mounting Attach the wall mount assembly to a flat surface. Use the supplied screws to secure the mount in the position desired (use of the included anchors requires 5/16” holes). Elevation and Azimuth Adjustments Installation Guide –... -
Page 10: Pole Mounting
Antenna System Pole Mounting Attach the antenna to any pole (not larger than two inches in diameter) using the U-bolt and saddle with supplied attaching hardware as shown in the following figures. 2” DirecTV Pole NOTE: For operation in close proximity to high power satellite radio terrestrial repeaters, please use the supplied 20 dB attenuator on the input of the splitter to avoid amplifier overload. -
Page 11: Aiming The Antenna
Crestron SRD-ANT-4-PAK Aiming the Antenna Refer to the documentation supplied with the tuner/radio for information on observing signal strength. Adjust the antenna as required to maximize the signal. XM Reception XM has two satellites located in fixed orbital positions in the southern sky (at 115° W longitude and 85º... -
Page 12: Problem Solving
Antenna System Problem Solving Troubleshooting The table after this paragraph provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. SRD-ANT-4-PAK Installation Troubleshooting Further Inquiries If you cannot locate specific information or have questions after reviewing this guide, please take advantage of Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. -
Page 13: Future Updates
Crestron SRD-ANT-4-PAK Future Updates As Crestron improves functions, adds new features and extends the capabilities of the SRD-ANT-4-PAK, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision. Check the Crestron website periodically for manual update availability and its relevance. -
Page 14: Appendix: Azimuth And Elevation Pointing Guide
Antenna System Appendix: Azimuth and Elevation Pointing Guide The following chart shows the optimum azimuth bearing and elevation pointing angles for locations throughout the US (below) and Canada (starting on page 12). The azimuth has been magnetically corrected. NOTE: Although in many locations it may be possible to receive signals from terrestrial repeaters, it is not recommended to use these signals at fixed locations. - Page 15 Crestron SRD-ANT-4-PAK SIRIUS and XM Satellite Azimuth and Elevation Angle Settings - US (Continued) CITY AZIMUTH ELEVATION AZIMUTH° St Louis 319.7 Billings 76.2 Kalispell 80.8 Winston-Salem 308.2 Minot 106.5 North Platte 33.8 Omaha 349.9 Cherry Hill 297.6 Albuquerque 33.1 Shiprock 41.9 Elco 61.0...
- Page 16 Antenna System SIRIUS and XM Satellite Azimuth and Elevation Angle Settings - Canada CANADA CITY PR AZIMUTH° ELEVATION° AZIMUTH° ELEVATION° AZIMUTH° ELEVATION° Vancouver BC 78.4 Prince Rupert BC 81.4 Calgary AB 89.7 Edmonton AB 129.7 Saskatoon SK 109.0 Toronto ON 287.9 Ottawa ON 282.6 Montreal...
-
Page 17: Return And Warranty Policies
Crestron SRD-ANT-4-PAK Return and Warranty Policies Merchandise Returns / Repair Service 1. No merchandise may be returned for credit, exchange or service without prior authorization from CRESTRON. To obtain warranty service for CRESTRON products, contact an authorized CRESTRON dealer. Only authorized CRESTRON dealers may contact the factory and request an RMA (Return Merchandise Authorization) number. - Page 18 Antenna System Crestron SRD-ANT-4-PAK This page is intentionally left blank. 14 • Antenna System: SRD-ANT-4-PAK Installation Guide – DOC. 6723A...
- Page 19 Crestron SRD-ANT-4-PAK Antenna System This page is intentionally left blank. Antenna System: SRD-ANT-4-PAK • 15 Installation Guide – DOC. 6723A...
- Page 20 Crestron Electronics, Inc. Installation Guide – DOC. 6723A 15 Volvo Drive Rockleigh, NJ 07647 (2021911) Tel: 888.CRESTRON 08.08 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
